Kolcraft Contours Options Manuel utilisateur
©2007 Kolcraft®Enterprises, Inc. S71-T 7/07
Contours™Options™4 Wheeler Stroller Instruction Sheet
Hoja de instrucciones de la carriola Contours™Options™de 4 ruedas
Feuille d’instructions pour la poussette à 4 roues Contours™Options™
2
Avoid serious injury from falling or sliding out. Always use Restraint
System. Your child's safety depends on you. Proper stroller use cannot be
assured unless you follow these instructions. DO NOT USE STROLLER
UNTIL YOU READ AND UNDERSTAND THESE INSTRUCTIONS.
IMPORTANT SAFETY INFORMATION:
How to Keep Your Child Safe While Using this Stroller
•Adult Assembly Required.
•NEVER LEAVE YOUR CHILD UNATTENDED WHILE IN STROLLER.
Accidents can happen quickly while your back is turned. You must
always keep your child in view while your child is in the stroller,
even when sleeping. Do not use this product as a bed. Your child
may become tangled in straps or pads and suffocate.
•Always use restraint systemto keep child fromstanding up or
falling out of the stroller. Do not use product without full 5 point
harness restraint. Removing the shoulder straps will not
adequately restrain child.
•Always lock the stroller open before allowing your child in or near
the stroller.This prevents injuries caused by stroller collapsing.
•
Onlyuse this stroller with children who weigh less than 40 lbs. (18.14
kg)or are less than 40” (1 meter)tall.
Use by larger children may
damage the stroller, or cause a hazardous, unstable condition to
exist.
•Use this stroller in the reclined position until child can sit up
unassisted.
•Always set the wheel brakes when stroller is not moving, especially
on an incline.This prevents the stroller from rolling away.
•Always fasten the canopyonto the seat back when using the
stroller in the reclined position.
What to Avoid While Using this Stroller
•Always balance the weight of the stroller evenly. To prevent the
stroller from becoming unstable or tipping:
• Do not place parcels or accessory items on the stroller canopy,
seat, or over the handle.
• Do not put more than 10 lbs. (4.54 kg) in the basket.
• Do not allow children to play with or hang onto the stroller.
•Never use this stroller on stairways or escalators.
•DO NOT lift by tray.
•Make sure children are clear of any moving parts if you adjust the
stroller, otherwise they may be injured.
WARNING
Continued on next page
•This is not an exercise stroller! Do not use this product while
running, jogging, in-line skating or participating in other athletic
activities.
•DO NOT put child in basket.
•Take care when folding and unfolding to prevent finger pinching.
• Product may become unstable if a parcel bag, other than the one
recommended by the manufacturer is used.
•DO NOT allow children to climb into stroller unassisted. Stroller
may tip over and injure child.
• Only use replacement parts supplied by the manufacturer.
How to Use this Stroller with Your Infant Car Seat
•AVOID SERIOUS INJURY FROM FALLS:
• DO NOT place carseat in stroller seat. Car seat will not be secure.
• DO NOT use seat and infant car seat adapter at the same time.
• This product is only to be used with certain Infant Car Seats. See
below for list of compatible Infant Car Seats.
• When using this product with your Infant Car Seat, infant must
always be secured in the car seat with the car seat harness.
• To ensure your Infant Car Seat is properly installed on the stroller,
make sure it is:
• Facing the person pushing the stroller.
• Tightly secure to the stroller with the car seat adapter’s restraint
straps.
• If at any time your Infant Car Seat does not secure properly to the
stroller, or if you have questions about assembly or use of the
stroller, Do Not use this product. Call Kolcraft at 1-800-453-7673.
•Make sure the stroller is fullyunfolded and the car seat adapter is
securelylatched before attaching your Infant Car Seat. This
prevents finger pinching and injuries caused by stroller collapsing.
•Onlytransport infants that are within the size and weight
limitations of your Infant Car Seat, as described in the instruction
manual provided by the Infant Car Seat manufacturer.
•THE FOLLOWING INFANT CAR SEATS CAN BE USED IN CAR
SEAT ADAPTER:
3
•Baby Trend®Latch-Loc
•Baby Trend® Flex-Loc
•Britax® Handle with Care®
•
Chicco®Key Fit
•
Combi®Tyro™
•Combi®Connection™
•
Cosco®Arriva®Series
•
Cosco®Designer 22®
Series
•
Cosco®Eddie Bauer®Opus® 35®
•
Cosco®
Eddie Bauer
®
Caress
•
Cosco®First Ride DX
•
Cosco®Turn-A-Bout®
•
Evenflo®Cozy Carry™
•
Evenflo®Discovery™
•Evenflo
®
EmbraceTM
•
Evenflo®On-My-Way™
•
Evenflo®Portabout™
•
Graco®Snug Ride™ Series
•
Graco® Safe Seat™
•
Peg Perego®Primo Viaggio
•
Peg Perego®SIP
•
Safety 1st®Designer® 22™
•
Safety 1st®Starter™
Continued on next page
Parts List
Stroller Frame
Rear Wheels
(2)
Brake Assembly
Right (with ★)
Front Tray
Seat
Infant Car Seat Adapter
Washers
(2)
Cotter
Pins (2) Hub Caps
(2)
Cup Holder
(select models)
Front Wheel
Assembly Right
(with ▲)
Rear Axle
Brake Assembly
Left (with ▲)
Canopy
4
•If your Infant Car Seat is not one of the models listed above, DO
NOT use your infant car seat with this stroller.Other Infant Car
Seat models will not fit properlyand may result in serious injuryto
your child.
•
DO NOT USE THE FOLLOWING CAR SEATS WITH THIS STROLLER!
This list is not inclusive.
Baby Trend®, Britax®, Century®, Chicco®, Combi®, Cosco®, EvenFlo®, Gerry®,
Fisher Price®, Graco®, Peg Perego®and Safety 1st®are trademarks of their
respective owners. They are not associated with Kolcraft Enterprises, Inc.
and no approval by them is to be implied.
•Britax®Baby Safe™
•Britax®Companion
•Century®535/580/590 Series
•Century®Assura®Series
•Century®Avanta™Series
•
Century®Vanté™5
•Century
®
Smart FitTM Series
•
Cosco®TLC
•
Cosco®Dream Ride®
•
Eddie Bauer® Caress
•
Fisher Price®Stay in View™
•All Gerry
®
Infant Car Seats
•Kolcraft
®
Secura
•Kolcraft
®
Infant Rider
®
Front Wheel
Assembly Left
(with ★)
5
How to Assemble Your Stroller
To Open Stroller
Remove any cardboard inserts or plastic
ties used to protect the product during
shipment.
Release the locking latch.
NOTE: Keep hands/fingers away from
side locks when unfolding the handle!
Place one hand on the foam grip
located on the basket (A) and the other
on the side lock (B). Gently pull apart to
seperate.
Rotate handle back until side locks and
frame click into place. Push down on
basket tube with hand or foot to confirm
the lower frame is locked.
NOTE: You can tell if lower frame is in
locked position by looking at the square
window in the lower frame lock. If a red
tab appears in that window, the lower
frame is locked.
To Test for use: First pull up and then
push down on handle to make sure it is
fully engaged.
2
3
2 & 3
1
B
A
Pull Apart
Locking Latch
Pull Apart
4
5
4
Side Locks
Lower Frame
Lock Tab
Push Down
Lower Frame
Lock
5
7
6
3
4
7
5
3 & 4
6
To Assemble Rear Wheels
1
1 & 2
There is a LEFT and RIGHT brake
assembly. Be sure to assemble them
onto the correct rear leg tube. LEFT
from RIGHT will be identified as shown.
Each brake assembly will have either a
triangle or a star on the bottom of the
part.
• TRIANGLE = “▲” LEFT
• STAR = ”★“ RIGHT
Position brake assembly as shown, with
the brake lever pointing towards the
stroller handle. Push brake assembly
completely onto rear leg tube.
Remove and discard protective foam
sleeves from ends of axle. Insert axle
into outside hole of brake assembly and
slide it through frame.
Slide a rear wheel onto the axle then
slide a washer onto the axle.
Fit straight part of cotter pin through
hole on axle as shown.
Assemble other rear wheel to axle with
washer and cotter pin.
Line up each of the 4 tabs of the hub
cap with the 4 slots in the wheel and
snap hub cap into place. Repeat for
second side.
2
▲★
7
To Assemble Front Wheels
1Lay stroller back on handle.
Position front wheel assembly as shown.
NOTE: There is a LEFT and RIGHT front
wheel assembly. Be sure to assemble
them onto the correct leg tube.
• TRIANGLE = “▲” RIGHT
• STAR = ”★“ LEFT
Push front wheel assembly onto front leg
tube until spring loaded button clicks
into place.
NOTE: Make sure that spring loaded
buttons pop through frame. If your
spring loaded button becomes out of
place, take pliers and feed button into
hole. If spring loaded buttons DO NOT
pop through, front wheel assembly could
fall off during use.
Repeat for other side.
4
3
Align both sides of adjustable footrest
mechanism with seat tube frame as
shown.
Push adjustable footrest mechanism
onto seat tube until spring loaded
button clicks into place.
NOTE: Make sure that spring loaded
buttons pop through frame. If your
spring loaded button becomes out of
place, take pliers and feed button into
hole.
1
1
To Assemble Adjustable Footrest Mechansism to Seat
Spring Loaded Button
2
2
Push Together
2
2 & 3
Spring
Loaded
Buttons
▲
★
★▲
To Attach Front Tray
Release Button
CAUTION
To prevent injury to your child, take
care when inserting tray into frame.
Align tray into holes located on seat
frame.
Snap tab in place until a click is heard.
Repeat for second side.
TO ROTATE OR REMOVE TRAY: Push
in release button located near side
housing and pull tray out. Repeat on
other side, to remove tray completely.
1
3
2
1 & 2
8
To Attach Seat
1
2
3
3 & 4
4
WARNING
DO NOT Place car seat in stroller
seat. Car seat will not be secure.
5
Seat Housing Slot
Seat Post
Seat Lock Tab
Release Button
4 & 5
Place stroller upright with all 4 wheels on
the ground.
Pick up seat by seat frame and place
seat in either forward or reverse position.
Align posts with seat housing slots as
shown.
Press seat down until a "click" is heard
on both sides. Pull up on seat to make
sure it is secured to stroller frame.
NOTE: You can tell if seat is locked in
place by looking at square window on
side of seat housing slot. If a red tab
appears in that window, seat is locked.
To reverse seat, push in release buttons
located on both sides of seat frame, lift
up and reverse seat direction.
9
To Attach Canopy
1
1
To Attach Parent Cup Holder (select models)
Align cup holder hole with posts on
handle and snap onto handle.
TO REMOVE, Hold cup holder and pull
upward from the bottom. Cup holder is
top rack dishwasher safe.
1
WARNING
DO NOT place more than 3 lbs. (1.36 kg)
in this tray to avoid tipping!
1
Post
Insert canopy posts into slots onto seat
frame as shown.
Infant neck roll is to be used with newborns
who can not hold up their head. It should be
used only when the seat is reclined. It can be
removed when a child can hold their head up
unassisted.
When using the infant neck roll, be sure that
the shoulder restraint straps are fed through
the holes on either side. Restraint must
always be used with the infant neck roll.
1
1
To Install Infant Neck Roll
10
To Secure Child In Stroller
Lock both foot brakes to keep stroller
from rolling.
Place child in stroller.
Hook shoulder straps to waist belt.
To fasten restraint system buckles -
push together. Be sure both buckles
are fastened to secure child safely.
To unsnap restraint system buckles -
press tabs to release.
For proper fit, adjust shoulder straps
and waist band as shown.
1
3
WARNING
Avoid serious injury from falling or sliding
out. Always use restraint system. Do not
use product without full 5-point Harness
Restraint. Removing the shoulder straps
will not adequately restrain child.
2
3
4
5
6
4
6
Adjust Restraint
System Harness
How to Properly Use Your New Stroller
To Operate Brakes
1Push levers on both rear wheels down to
lock.
Pull levers up to unlock.
2
Unlock
Lock
Autres manuels pour Contours Options
5
Table des matières
Langues :
Autres manuels Kolcraft Poussette
Kolcraft
Kolcraft Jeep Cherokee Sport S51J-T-R5 Manuel utilisateur
Kolcraft
Kolcraft Jeep Cherokee Sport Series Manuel utilisateur
Kolcraft
Kolcraft Jeep S47J-R7 Manuel utilisateur
Kolcraft
Kolcraft Jeep Overland Limited Manuel utilisateur
Kolcraft
Kolcraft Jeep Wrangler All-Weather Umbrella Stroller Manuel utilisateur
Kolcraft
Kolcraft Jeep Wrangler Manuel utilisateur
Kolcraft
Kolcraft SPRINT X Manuel utilisateur
Kolcraft
Kolcraft Jeep Traveler Tandem Manuel utilisateur
Kolcraft
Kolcraft OPTIMA S82-R2 Manuel utilisateur
Kolcraft
Kolcraft Jeep Cherokee Sport Series Manuel utilisateur
Kolcraft
Kolcraft Lite sport Manuel utilisateur
Kolcraft
Kolcraft Contours Options Manuel utilisateur
Kolcraft
Kolcraft travel about S51-T Manuel utilisateur
Kolcraft
Kolcraft CONTOURS S67-T-R1 12/10 Manuel utilisateur
Kolcraft
Kolcraft Umbrella Stroller Manuel utilisateur
Kolcraft
Kolcraft Jeep Wrangler All-Weather Umbrella Stroller Manuel utilisateur
Kolcraft
Kolcraft Contours Options Manuel utilisateur
Kolcraft
Kolcraft Jeep Liberty S45J-R7 Manuel utilisateur
Kolcraft
Kolcraft Jeep Wrangler Manuel utilisateur
Kolcraft
Kolcraft Jeep S45J-T Manuel utilisateur
