Kohler Underscore K-5714-XH2G Manuel utilisateur

Features

•122 airjets release thousands of bubbles that surround, support,

and massage the body.

•Variable-speed blower lets you adjust massage intensity to 18

levels.

•Zones of Control™feature allows you to target airjet massage

to back, midsection, or feet.

•8 hydromassage jets can be individually adjusted for water flow

and direction.

•Variable-speed pump for adjusting massage intensity.

•Built-in heater.

•Lighted keypads.

•Sloping backrest provides comfort.

•Oval-shaped basin offers a graceful and spacious bathing

experience. Codes/Standards

ASME A112.19.7/CSA B45.10

•Slotted overflow allows for deep soaking. CSA B45.5/IAPMO Z124

•Immediate and manual purge cycles remove residual water

from air channels after use.

ASTM E162

ASTM E662

UL 1795

•Requires K-7271 or K-7272 Clearflo slotted overflow bath drain

(sold separately). CSA C22.2 No. 218.2

•Center drain.

KOHLER®Plastic Baths and Receptors

Lifetime Limited Warranty

Material

•Acrylic KOHLER®Hydrotherapy Components

Five-Year Limited Warranty

Hydrotherapy

•BubbleMassage See website for detailed warranty information.

•Whirlpool

Installation Available Colors/Finishes

•Drop-in or under-mount.

Color tiles intended for reference only.

•Requires 240V hard-wire electrical service.

Additional Hydrotherapy Options DescriptionCodeColor

White0

•Soaking Bath - 5713-0

Biscuit96

•Soaking Bath + Bask heated surface - 5713-W1

•BubbleMassage air bath - 5714-G Almond47

•BubbleMassage air bath + chromatherapy - 5714-GCR DuneNY

•VibrAcoustic + BubbleMassage air bath - 5714-GVB Ice™Grey95

•VibrAcoustic + BubbleMassage air bath + Bask heated surface

+ chromatherapy - 5714-GVBCW SandbarG9

Mexican Sand™33

•BubbleMassage air bath + Bask heated surface - 5714-GW

CashmereK4

•Whirlpool + heater - 5714-H2

•VibrAcoustic - 5714-VB Thunder™Grey58

•VibrAcoustic + chromatherapy - 5714-VBC Black Black™7

•VibrAcoustic + chromatherapy + Bask heated surface -

5714-VBCW

•VibrAcoustic + Bask heated surface - 5714-VBW

•Whirlpool + BubbleMassage air bath - 5714-XH2G

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-7-2019 11:41 - US/CA

Underscore®Oval

5' BubbleMassage™Whirlpool Bath

K-5714-XH2G

Notes

Required Electrical Service Measure your actual product for rough-in details.

One dedicated circuit required, protected with Class A

Ground-Fault Circuit-Interrupter (GFCI). Outside North America,

this device may be known as a Residual Current Device (RCD).

Install this product according to the installation

instructions.

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

240 V, 20 A, 50/60 HzBlower, Pump:

Technical Information

All product dimensions are nominal. Kit is required for under-mount installations (sold

separately).

Drop-in, Under-mountInstallation:

CenterDrain location: The pump base extends beyond the edge of the

rim. Modify the framing as needed.

43" x 25-5/8" (1093 mm x 651 mm)Basin area, bottom:

55-9/16" x 28-3/8" (1411 mm x 720 mm)Basin area, top: IMPORTANT! Dry fit the drain assembly prior to

installing the bath. The bath cannot be installed

with all drain components attached.

160 lbs (72.6 kg)Weight:

53.9 lbs/ft²(263.2 kg/m²)Minimum floor load:

If installing a rim-mount faucet, make sure there

is no interference above or below the deck before

drilling any holes.

16-5/16" (415 mm)Water depth:

72.017 gal (272.6 L)Water capacity:

Drop-in, 1268438-7, required, includedTemplate:

Blower: 240 V, 3 A, 50/60 Hz

Pump: 240 V, 11 A, 50/60 Hz, 1500 W

Electrical component

rating:

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-7-2019 11:41 - US/CA

Underscore®Oval

5' BubbleMassage™Whirlpool Bath

K-5714-XH2G
