Memoirs®

60" x 33-3/4" alcove BubbleMassage™air bath

K-724-G0

Features

•43 airjets release thousands of bubbles that surround,

support, and massage the body

•Variable-speed blower lets you adjust massage intensity to

18 levels

•Zones of Control™feature allows you to target massage to

back, midsection, or feet

•Lighted keypad control

•Integral apron

•Safeguard®slip-resistant surface provides excellent traction

underfoot

•Automatic and manual purge cycles remove residual water

from air channels after use

•Coordinates with other products in the Memoirs collection

•Integral lumbar support

Material

•KOHLER®enameled cast iron

Hydrotherapy

•BubbleMassage™

•Built-in 300W heater

Installation

•Right drain

•Alcove

•Integral flange

Required Products/Accessories

K-T37391 Rotary-turn bath drain trim

K-T37392 Rotary-turn bath drain trim

K-37383 Rough-in cable bath drain, PVC, 30" cable with

tubing

K-78438 30" cable bath drain

K-37385 rough-in cable drain, PVC, 45” cable

K-78439 45" cable bath drain

Recommended Products/Accessories

K-1491 Bath/Whirlpool Pillow

K-1601 Bath/whirlpool footstop, removable

K-7259 Brass toe tap bath drain

K-706000-D3 Frameless Sliding Bath Door

K-706000-L 62" H sliding bath door with 1/4"-thick glass

K-706004-D3 Frameless Sliding Bath Door

K-706004-L Frameless Sliding Bath Door

K-702200-6L 58" H sliding bath door with 1/4"-thick glass

K-31796 Above-the-floor bath drain kit

K-31798 Bath drain kit

Codes/Standards

ASME A112.19.1/CSA B45.2

ASME A112.19.7/CSA B45.10

ASTM F462

UL 1795

CSA C22.2 No. 218.2

ADA

ICC/ANSI A117.1

KOHLER®Enameled Cast Iron Bath

and Shower Base Lifetime Limited

WarrantyKOHLER®Hydrotherapy

Components Five-Year Limited

Warranty

See website for detailed warranty information.

Available Colors/Finishes

Color tiles intended for reference only.

Color Code Description

0 White

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-17-2023 00:54 - US/CA

Memoirs®

60" x 33-3/4" alcove BubbleMassage™air bath

K-724-G0

Lumbar

Angle 31°

3-1/4" (83 mm)

1" (25 mm)

33-3/4" (857 mm)

1/8" (3 mm)

17-7/16"

(443 mm)

1-1/2"

(38 mm)

NOTE: Blower protrusion

beyond the rim.

(76 mm)

2-7/8" (73 mm)

8-1/2" (216 mm)

1-13/16" (46 mm)

16"

(406 mm)

32"

(813 mm)

60" (1524 mm)

Blower Motor/Control Access

34" (864 mm) W x

15" (381 mm) H

No change in measurements if connected

with drain illustrated. (K-7161-AF)

1-1/2"

Bath Drain

Required Electrical Service

One dedicated circuit required, protected with Class A Ground-

Fault Circuit-Interrupter (GFCI). Outside North America, this

device may be known as a Residual Current Device (RCD).

Blower: 240 V, 15 A, 50/60 Hz

Technical Information

All product dimensions are nominal.

Drain location: Right

Basin area, bottom: 45" x 23" (1143 mm x 584 mm)

Basin area, top: 54" x 25" (1372 mm x 635 mm)

Weight: 390 lbs (176.9 kg)

Minimum floor load: 61 lbs/ft²(297.8 kg/m²)

Water depth: 11-5/8" (295 mm)

Water capacity: 52 gal (196.8 L)

Electrical component

rating:

Blower: 240 V, 5 A, 50/60 Hz

Blower speed: Variable

Notes

Measure your actual product for rough-in

details.

Install this product according to the installation

instructions.

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

If relocating the blower motor, do not relocate

or alter the PVC tee or coiled flexible tubing

connected to the blower. Follow the blower

relocation instructions exactly. Provide access

for servicing the blower.

ADA compliant when installed to the specific

requirements of these regulations.

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-17-2023 00:54 - US/CA
