Kogan KAMN30FUSA Manuel utilisateur

30" CURVED 21:9 ULTRAWIDE

75Hz MONITOR

(2560 x 1080)

KAMN30FUSA

•Read all instructions before using the appliance and retain for reference.

•Unplug the monitor before cleaning it.

•Use a clean, slightly dampened cloth to wipe the main monitor body.

•To clean the screen: turn it off, unplug it and wait for it to cool completely, then

wipe it with a dry micro-fibre cloth.

•Do not use cleaning alcohol, ammonia-based liquids or other harsh cleaners.

•This monitor is designed with ventilation holes on the back of the casing. Do not

cover or block them.

•Do not insert any object or allow any liquid to enter the ventilation.

•Avoid placing the monitor near heaters, stoves, fireplaces or other sources of heat,

as well as in rooms lacking adequate ventilation.

•Do not position the monitor in unsafe locations. If the monitor falls, it may be

damaged and may injure nearby people.

•Unplug the monitor if it is not going to be used for an extended period.

•Do not place heavy objects on the monitor, its power cord or any connected cable.

•Do not open the back panel of the monitor, as it contains a high-voltage current

even when not plugged in.

The terms HDMI and HDMI High-Definition Multimedia Interface

and the HDMI Logos are trademarks or registered trademarks of

HDMI Licensing Administrator, Inc. in the United States and other

countries.

SAFETY & WARNINGS

Monitor

Stand connector

Stand base

Stand base screws

(M4*10mm x 4, M4*16mm x 2)

VESA screws (x4)

DisplayPort cable

Power cable

User guide

PARTS

Monitor Controls

M Menu button

Press to display the OSD menu or enter sub-menus.

Forward button

Press to move forward in the menu or increase parameters.

Back button

Press to move back in the menu or decrease parameters.

E Exit button

Press to exit.

Power button

Press to turn the monitor on/off.

Monitor Ports

AUDIO OUT

DP Connector

HDMI1 2.0

HDMI2 1.4

HDMI3 1.4

Power Connector

OVERVIEW

Attention: Panel is fragile. Keep the foam underneath the monitor while assembling the

stand.

1. Carefully remove the monitor from the packaging with the protective foam

attached and place it face down on a soft cloth spread across a stable surface

such as a table.

2. Remove and assemble the stand base and connector using the included screws.

3. Remove the connection block from the back of the monitor by pressing the detach

button.

4. Insert the Connection Block into the back cabinet, then push down until it snaps

into place.

5. Remove the bottom foam and place the monitor on the desk or other location

intended for use: installation is complete.

STAND ASSEMBLY

1. Carefully remove the monitor from the packaging with foam attached and place it

face down on a soft cloth spread across a stable surface such as a table.

2. Remove the connection block from the back of the monitor by pressing the detach

button. If the stand is attached, remove it.

3. Assemble the mount as per the instructions provided with the mount.

VESA MOUNT

Stand base

Monitor

Stand Stem

Stand plate

Button

Mount (Not included)

VESA 100*100mm, Screw size (M4 screw needed for VESA Mount)

Note: VESA mount or mounting accessory are NOT included.

Power Cable

Connect the included power cable to the monitor power port and then connect the other

end to a power outlet.

Earphones (Audio Out)

You can connect earphones or another audio device to the 3.5mm output on the monitor.

You may need to set the Kogan monitor as your PC’s sound output device.

CONNECTIVITY

HDMI

Connect an HDMI cable from the computer’s display output to the monitor’s display input.

DisplayPort

Connect a DisplayPort cable from the computer’s display output to the monitor’s display

input.

1. Connect the monitor to your input device via HDMI or DisplayPort.

2. Connect the power cable to your monitor and then connect the other end directly

to a power socket.

3. Use the power button to turn the monitor on.

FreeSync

•The feature is disabled by default when setting a 75Hz refresh rate.

•In order to use this feature, ensure your hardware has FreeSync capability and the

graphics drivers are fully up to date.

•After connecting, you may receive a prompt to enable the feature on your

computer. If you do not receive the prompt, you may need to enable the function in

your graphics card menu.

•See your graphics card manufacturer’s documentation for instructions on how to

turn on and/or enable FreeSync.

BASIC OPERATION
