DIAPHRAGM METERING PUMP
FEM 1.02, FEM 1.09
Operating and
Installation
Instructions
Read and observe these Oper-
ating and Installation Instruc-
tions.
An additional letter prefixing the
FEM model code is a country-
specific designation, and does
not have any technical rele-
vance.
KNF Flodos AG
Wassermatte 2
6210 Sursee, Switzerland
Tel. +41 (0)41 925 00 25
Fax +41 (0)41 925 00 35
www.knf.c
om
info.flodos@knf.com
Contents Page
1. About this document ................................................................. 2
2. Use ........................................................................................... 3
3. Safety ....................................................................................... 4
4. Technical data .......................................................................... 6
5. Assembly and function ............................................................. 9
6. Installation and connection ..................................................... 11
7. Operation ................................................................................ 16
8. Servicing ................................................................................. 20
9. Troubleshooting ...................................................................... 24
10. Spare parts and accessories .................................................. 26
11. Return of the pump ................................................................. 28
FEM 1.02 KP .27 SM
-
2
.27 /
-
[Ch. 5]
1.02 / 1.09
FEM / UFEM
SM
-
2
-
/ PMLxxxx / PLxxxx [Ch. 1]
KP / KT / TT [Ch. 4]
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 About this document
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 2
1. About this document
1.1. Use of the Operating and Installation Instructions
The Operating and Installation Instructions are part of the pump.
Forward the Operating and Installation Instructions to any subsequent
owners of the pump.
Customer-specific project pumps (pump models which begin with "PL" or
"PML") may differ from the Operating and Installation Instructions.
In the case of project pumps, take note of any additionally agreed specifi-
cations.
1.2. Symbols and markings
Warning
WARNING
This symbol indicates a potential danger.
It also indicates the possible consequences of failure
to observe the warning. The signal word (e.g. "Warn-
ing") indicates the level of danger.
Here you will see actions for avoiding the
danger
and potential consequences.
Danger levels
Signal word
Meaning Consequences if not observed
DANGER warns of immedi-
ate danger
Consequences include death or
serious injuries and/or serious
property damage.
WARNING
warns of potential
danger
Death or serious injuries and/or
serious property damage are
possible.
CAUTION warns of a poten-
tially dangerous
situation
Minor injuries or damage to
property are possible.
Tab. 1
Other information and symbols
This indicates an activity (step) that must be carried out.
This indicates the first step of an activity to be carried out. Any additional
steps required are numbered consecutively.
This symbol indicates important information.
Project pumps
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Use
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 3
2. Use
2.1. Intended use
The pumps are intended for transferring and metering liquids.
Owner's responsibility
Only install and operate the pumps under the operating parameters and
conditions described in Chapter 4, Technical data.
Only fully assembled pumps may be taken into service.
Before transferring or metering a medium, check whether the medium can be
transferred danger-free in the specific application case.
Before using a medium, check the compatibility of the materials of the pump
head, pump housing, diaphragm and valves with the medium.
The temperature of the medium must lie within the permissible range (see
Chapter 4).
The pumped medium should not contain particles as these can prevent the
pump from working correctly. If this cannot be ensured, a < 50 m filter with a
sufficiently large filter area must be used upstream of the pump.
2.2. Improper use
The pumps must not be operated in a potentially explosive atmosphere.
The maximum ambient temperature must not exceed 40°C.
Do not use the pump controller in a damp environment or under condensing
conditions.
The controller must be protected against contamination, and contact with
liquids, solvents or vapours must be avoided.
The pump controller must only be operated when adapted to meet the ESD
(Electrostatic Discharge) safety standards.
Do not establish uncontrolled connections between the controller and conduc-
tive cables and materials.
For special modifications to the pumps outside the standard technical specifi-
cations please contact a KNF technical adviser.
Operating parameters and
conditions
Requirements for
transferred medium
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Safety
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 4
3. Safety
Observe the safety precautions in Chapters 6, Installation and
connection and 7, Operation.
The pumps are built according to the generally recognised rules of technology
and in accordance with the pertinent occupational safety and accident preven-
tion regulations. Nevertheless, dangers can result during their use which lead
to injuries to the user or others, or to damage to the pump or other property.
Only use the pumps when they are in a good technical and proper working
order, in accordance with their intended use, observing the safety advice
within the Operating and Installation Instructions, at all times.
Make sure that only trained and instructed personnel or specially trained
personnel work on the pumps. This especially applies to assembly, connection
and servicing work.
Make sure that all personnel have read and understood the Operating and
Installation Instructions, and in particular the "Safety" chapter.
Observe the accident prevention and safety regulations when performing any
work on the pump and during operation.
When transferring dangerous media, observe the safety regulations for han-
dling such media.
Always ensure adherence to all information stickers on the pumps, such as
flow direction arrows and type plates, and keep stickers in legible condition.
All replacement parts should be properly stored and disposed of in accord-
ance with the applicable environmental protection regulations. Ensure adher-
ence to the pertinent national and international regulations. This especially
applies to parts contaminated with toxic substances.
Dispose of all packaging in an environmentally-appropriate manner.
The packaging materials are recyclable.
Ensure that the old appliance is disposed of in an envi- ronmen-
tally-appropriate manner. Use appropriate waste collection systems
for the disposal of end-of-life equipment. Used pumps contain
valuable recyclable materials.
Personnel
Working in a
safety-conscious manner
Handling dangerous media
Notes
Environmental protection
Disposal
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Safety
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 5
The pumps are in accordance with the requirements of the guidelines
2011/65/EU (ROHS2)
For the purposes of the Machinery Directive 2006/42/EC, pumps are “partly
completed machinery", and are therefore to be regarded as not ready for use.
Partly completed machinery may not be commissioned until such time as it
has been determined that the machine in which the partly completed machin-
ery is to be assembled conforms to the provisions of the Machinery Directive
2006/42/EC. The essential requirements of Annex I of Directive 2006/42/EC
(general principles) are applied and observed.
The following harmonised standards are met:
When used in conjunction with the 2-phase stepping motor controller,
Id. No. 157870 or Id. No. 160536, with up to 1 metre of supply cable, all
FEM 1.02, FEM 1.09 and UFEM 1.09 pumps meet the following standards:
EN 61000-6-2
EN 61000-6-4
Please note: when used in conjunction with controllers from
other manufacturers, compliance with the above standards
cannot be guaranteed.
Please note: when used in conjunction with controllers from
other manufacturers, compliance with CE standards must be
verified by the customer.
All repairs to the pump(s) must be carried out by the relevant KNF Customer
Service team.
Only use genuine parts from KNF for servicing work.
EU directives/standards
Customer services and
repairs
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Technical data
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 6
4. Technical data
Pump materials
The pump type KP stands for:
Assembly Material1)
Pump head* PP
Valve plate EPDM
Diaphragm PTFE
Tab. 2 1) according to DIN ISO 1629 and 1043.1
The pump type KT stands for:
Assembly Material1)
Pump head* PP
Valve plate FFKM
Diaphragm PTFE
Tab. 3 1) according to DIN ISO 1629 and 1043.1
The pump type TT stands for:
Assembly Material1)
Pump head* PVDF
Valve plate FFKM
Diaphragm PTFE
Tab. 4 1) according to DIN ISO 1629 and 1043.1
* The pump head comprises a connecting plate and an
intermediate plate (Chapter 8.3, items 3 and 4)
Hydraulic ratings
Parameter Value
Flow rate FEM 1.02 [ml/min] 1), 2) 0.2 – 20
Flow rate FEM 1.09 [ml/min] 1), 2) 0.9 – 90
Permissible pressure [bar g] 6
Suction head [mWG] 4
Tab. 5
1) Measured with water at 23 °C at atmospheric pressure
2) Flow rates may vary from the values shown, depending on fluid viscosi-
ty, pump head material and the hoses/hose connectors used.
Hydraulic ratings, option .27
Parameter Value
Min. overflow pressure [bar] 0.5
Max. overflow pressure [bar] 6.5
Tab. 6
FEM ... .27
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Technical data
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 7
Hydraulic connections
Pump type Connection type
FEM 1.02 (internal thread) UNF 1/4"-28
FEM 1.02 (hose fitting) 4/6 mm
UFEM 1.09 (hose fitting) 1/8"/1/4"
Tab. 7
Electrical specifications FEM 1.02 / FEM 1.09
Motor voltage SM-2
Nominal voltage [V] 1) 5.52
Current [A/Phase] rms 1) 0.6
Inductivity [mH/phase] 14.6
Resistance [Ohms/phase] 9.2
Power consumption [W] 15
Maximum speed [rpm] 200
Step angle 1.8°
Connection type Connector with leads
Tab. 8
1) Nominal voltage and current.
2) The weight may differ slightly from the stated value, depending on the version.
Other parameters
Parameter Value
Permissible ambient temperature range
[°C]
+5 to +40
Permissible media temperature range [°C] +5 to +80
Permissible kinematic viscosity of medium
[cSt]
≤150
Protection class [-] IP40
Weight2) [g] 340
Tab. 9
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Technical data
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 8
Accuracy/reproducibility
The accuracy of the calibrated metering pump is appropriately characterised
by the maximum absolute error A (dependent on the nominal value) and the
maximum relative error B (dependent on the setting value):
max. inaccuracy ≤ (A + B)
FEM 1.02
Error Value
Absolute error A ≤ ±0.1% of nominal value
Relative error B ≤ ±1.0% of setting value
Tab. 10
FEM 1.09
Error Value
Absolute error A ≤ ±0.1% of nominal value
Relative error B ≤ ±1.0% of setting value
Tab. 11
Example: FEM 1.09; the nominal value for stroke volume is 500 µl
For a setting of 260 µl, the accuracy should therefore be within the following
error limits:
Inaccuracy ≤ (±0.1% x 500 µl) + (±1.0% x 260 µl)
≤ (±0.5 µl) + (±2.6 µl)
≤ ±3.1 µl
≈ ±1.2% of setting value
Under constant environmental conditions the pump achieves a reproducibility
of less than ±1%.
Greater inaccuracies may occur for fluids with a viscosity of >
150 cSt or with a tendency to outgas. Appropriate adjustments
may be made during calibration.
The accuracy of the pump is ultimately a matter of the meas-
urement and pumping system and the parameters with which
the pump is operated. The hose types used and the design of
the hose end at the pressure side play an important part in
precise metering.
FEM 1.02 ... SM-2 and FEM 1.09 ... SM-2 are not calibrated in the factory.
The pump must be calibrated electronically via the controller in the customer
system.
The flow rate may differ from the calibrated value in some applications. This is
influenced by the following factors: type of medium, its viscosity, density and
temperature, pressure and installation type (e.g. cross-section constrictions).
For accurate metering it is therefore recommended that the metering pump be
calibrated.
Accuracy
Reproducibility
Factory calibration
Calibration
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Assembly and function
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 9
5. Assembly and function
Assembly without overpressure relief valve
1 Inlet
2 Outlet
3 Pump head
4 Stepping motor (2-phase)
5 Stepping motor plug
Fig. 1: Stepping motor diaphragm metering pump FEM 1.02
Assembly with overpressure relief valve
1 Inlet
2 Outlet
3 Pump head
4 Stepping motor (2-phase)
5 Stepping motor plug
6 Overpressure relief valve
(.27)
Fig. 2: Stepping motor diaphragm metering pump FEM 1.02 ... .27
1 Outlet valve
2 Inlet valve
3 Working chamber
4 Diaphragm
5 Eccentric
6 Connecting rod
7 Pump drive
Fig. 3: Pump assembly
Stepping motor diaphragm metering pumps are based on reciprocating dis-
placement pump technology. The elastic diaphragm (4) is moved up and down
by the eccentric (5) and the connecting rod (6). In the downward stroke it
aspirates the medium to be transferred via the inlet valve (2). In the upward
stroke, the diaphragm pushes the medium out of the pump head via the outlet
valve (1). The diaphragm hermetically seals off the working chamber (3) from
the pump drive (7).
Stepping motor diaphragm metering pump FEM 1.02 / FEM 1.09 Assembly and function
KNF Flodos AG BA_FEM1-02_1-09_EN_07_157639.docx
Translation of Original Operating and Installation Instructions 10
FEM … -Version (standard version)
This pump type represents this product in its simplest form and is intended for
continuous delivery at an exact delivery rate.
FEM … .27-Version (with overpressure limitation)
If the metering pump is operating against a closed system, the delivery pres-
sure quickly exceeds the maximum permissible values. To prevent this hap-
pening, an overflow valve is integrated in the top part of the pump head. If the
pressure exceeds the variable limit range (min. 0.5 to max. 6.0 barg), the
valve opens and the liquid circulates from the pressure side to the suction side
via an internal bypass system. This prevents any further rise in pressure.
FEM … .55 version (with single-stroke metering)
The .55 version was specially developed for the KNF stepping motor partial
stroke controller FE Z5. The pumps have a Hall effect sensor for determining
the position of the diaphragms. This is needed during partial stroke metering
or with customer-specific operating profiles.
Please note:
The FEM … .55 is compatible with KNF controllers FE Z4
and FE Z5.
The FE Z5 stepping motor partial stroke controller from
KNF can only be used in combination with the FEM ... .55.
FEM … .55 RC version (single-stroke metering incl. controller)
In the .55 RD version the FE Z5 stepping motor partial stroke controller from
KNF is integrated in the pump and is supplied as a single unit.
Detailed information can be found in the relevant operating instructions.
The stepping motor controllers from KNF are available as accessories, see
accessory list in chapter 10. Two different controllers are available.
Stepping motor controller FE Z4 2-phase stepper
standard controller, single speed controller for variable delivery volume,
pulse input for maximum programming capability etc.
Stepping motor partial stroke FE Z5 Dispense
partial stroke controller, partial stroke metering using potentiometer or an-
alogue signals possible, alarm output etc.
More information about the functionality of the KNF controllers FE Z4 and FE
Z5 can be found in the relevant operating instructions.
FEM ...
FEM ... .27
FEM … .55
FEM … .55 RC
KNF stepping motor
controller
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels KNF Pompe à eau
KNF
KNF NF 1.30 Manuel utilisateur
KNF
KNF Laboport PM26285-811.18 Manuel utilisateur
KNF
KNF NF 60 Manuel utilisateur
KNF
KNF OEM Manuel utilisateur
KNF
KNF LABOPORT N820.18 CN Schéma de câblage
KNF
KNF N 0150 Manuel utilisateur
KNF
KNF SIMDOS 10 Manuel utilisateur
KNF
KNF N 922 Ex Manuel utilisateur
KNF
KNF N143.12 Manuel utilisateur
KNF
KNF UFK 1.1100 EX Manuel utilisateur
KNF
KNF N838 DC Series Manuel utilisateur
KNF
KNF NMP 830 KPDC-BI Manuel utilisateur
KNF
KNF N 816 Manuel utilisateur
KNF
KNF N936 Manuel utilisateur
KNF
KNF LIQUIPORT 100**.18 Series Manuel utilisateur
KNF
KNF N 816.3 Manuel utilisateur
KNF
KNF N963 Manuel utilisateur
KNF
KNF LABOPORT N 810 FT.18 Schéma de câblage
KNF
KNF UN 828 Manuel utilisateur
KNF
KNF N920 AP.18 Manuel utilisateur
Manuels Pompe à eau populaires d'autres marques
Sykes AmeriPumps
Sykes AmeriPumps GP100M Guide de dépannage
DUROMAX
DUROMAX XP WX Series Manuel utilisateur
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Manuel utilisateur
Franklin Electric
Franklin Electric IPS Manuel utilisateur
Xylem
Xylem e-1532 Series Manuel utilisateur
Milton Roy
Milton Roy PRIMEROYAL Manuel utilisateur
