DIAPHRAGM LIQUID PUMP

NF 1.30

Operating and

Installation

Instructions

Read and observe these Oper-

ating and Installation Instruc-

tions.

An additional letter prefixing

the

NF model code is a country-

specific designation, with no

technical relevance.

Contents Page

1. About this document ................................................................. 2

2. Use ........................................................................................... 3

3. Safety ....................................................................................... 4

4. Technical data .......................................................................... 6

5. Assembly and function ............................................................. 8

6. Installation and connection ....................................................... 9

7. Operation ................................................................................ 11

8. Servicing ................................................................................. 14

9. Troubleshooting ...................................................................... 17

10. Spare Parts and Accessories ................................................. 19

11. Return of the pump ................................................................. 20

KNF Flodos AG

Wassermatte 2

6210 Sursee, Switzerland

Tel +41 (0)41 925 00 25

Fax +41 (0)41 925 00 35

www.knf.com

info.flodos@knf.com

NF 1.30 KT DCG 12V

DCG

1.30

Supply voltage [Ch. 4]

/ PMLxxxx / PLxxxx [Ch. 1]

KT / TT [Ch. 4]

About this document Diaphragm Liquid Pump NF 1.30

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

2 Translation of original Operating and Installation Instructions

1. About this document

1.1. Use of the Operating and Installation Instruc-

tions

The Operating and Installation Instructions are part of the pump.

 Forward the Operating and Installation Instructions to any

subsequent owners of the pump.

Customer-specific project pumps (pump models which begin with

"PL" or "PML") may differ from the Operating and Installation

Instructions.

 In the case of project pumps, take note of any additionally

agreed specifications.

1.2. Symbols and markings

Warning

WARNING

This symbol indicates a potential danger.

It also indicates the possible consequences of failure

to observe the warning. The signal word (e.g. "Warn-

ing") indicates the level of danger.

 Here you will see

actions for avoiding the danger

and potential consequences.

Danger levels

Signal word

Meaning Consequences if not observed

DANGER warns of immedi-

ate danger

Consequences are death or

serious injury and/or serious

property damage.

WARNING

warns of potential

danger

Death or serious injury and/or

serious damage to property are

possible.

CAUTION warns of a poten-

tially dangerous

situation

Minor injury or damage to prop-

erty are possible.

Tab. 1

Other information and symbols

 This indicates a required activity (step) that must be carried

out.

This indicates the first step of an activity to be carried out. Any

additional steps are numbered consecutively.

This symbol indicates important information.

Project pumps

Diaphragm Liquid Pump NF 1.30 For your notes

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

Translation of original Operating and Installation Instructions 3

2. Use

2.1. Intended use

The pumps are intended for transferring and metering liquids.

Owner's responsibility

Install and operate the pumps only under the operating parameters

and conditions described in Chapter 4. Technical data.

Only completely installed pumps may be taken into service.

Before transferring or metering a medium, check whether the

medium can be transferred danger-free in the specific application

case.

Before using a medium, check the compatibility of the materials of

the pump head, pump housing, diaphragm and valves with the

medium.

The temperature of the medium must lie within the permissible

temperature range (see Chapter 4).

The transferred medium should not contain particles as these can

prevent the pump from working correctly. If this cannot be guaran-

teed, a filter < 100 m with sufficiently large filter area must be

used upstream of the pump.

 Filters may be ordered as accessories, see Spare Parts and

Accessories (Chapter 10).

2.2. Improper use

DANGER

The pumps must not be operated in an explosive

atmosphere.

Please contact your local KNF partner for special designs that

are not included in the technical specification (www.knf.com).

Operating parameters and

conditions

Requirements for media

to be transferred

Risk of explosion

Safety Diaphragm Liquid Pump NF 1.30

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

4 Translation of original Operating and Installation Instructions

3. Safety

Observe the safety precautions in Chapters

6. Installation and connection and 7. Operation.

The pumps are built according to the generally recognised rules of

technology and in accordance with the pertinent occupational

safety and accident prevention regulations. Nevertheless, potential

dangers during use can result in injuries to the user or others, or in

damage to the pump or other property.

Only use the pumps when they are in a good technical and proper

working order, in accordance with their intended use, observing the

safety advice within the Operating and Installation Instructions, at

all times.

Make sure that only trained and instructed personnel or specially

trained personnel work on the pumps. This especially applies to

assembly, connection and servicing work.

Make sure that the personnel has read and understood the Operat-

ing and Installation Instructions, and in particular the "Safety"

chapter.

Always ensure adherence to all pertinent accident prevention and

safety regulations when working on and operating the pump.

When transferring dangerous media, observe the safety regula-

tions for handling such media.

Always ensure adherence to all information stickers on the pumps,

such as flow direction arrows and type plates, and keep stickers in

a legible condition.

All replacement parts should be properly stored and disposed of in

accordance with the applicable environmental protection regula-

tions. Ensure adherence to the pertinent national and international

regulations. This applies especially to parts contaminated with toxic

substances.

Dispose of all packaging in an environmentally-appropriate

manner. The packaging materials are recyclable.

Dispose of end-of-life equipment in an environmentally

friendly manner. Use appropriate waste collection systems

for the disposal of end-of-life equipment. Used pumps

contain valuable recyclable materials.

Personnel

Working in a

safety-conscious manner

Handling dangerous media

Notes

Environmental protection

Disposal

Diaphragm Liquid Pump NF 1.30 For your notes

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

Translation of original Operating and Installation Instructions 5

The pumps comply with the fundamental requirements of Directive

2011/65/EU (RoHS2).

For the purposes of the Machinery Directive 2006/42/EC, pumps

are “partly completed machinery", and are therefore to be regarded

as not ready for use. Partly completed machinery may not be

commissioned until such time as it has been determined that the

machine in which the partly completed machinery is to be assem-

bled conforms to the provisions of the Machinery Directive

2006/42/EC. The essential requirements of Annex I of Directive

2006/42/EC (general principles) are applied and observed.

The following harmonized standards are met:

NF 1.30 DCG

 EN 55014 - 1: 2001

All repairs to the pumps must be carried out by the responsible

KNF customer service team.

Use only genuine parts from KNF for servicing work.

EU directives/standards

Customer service and

repairs

Technical data Diaphragm Liquid Pump NF 1.30

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

6 Translation of original Operating and Installation Instructions

4. Technical data

Pump materials

The pump type KT stands for:

Assembly Material1)

Pump head* PP

Valve socket PP / FFKM

Sealing washer FFKM

Diaphragm PTFE

Tab. 2 1) according to DIN ISO 1629 and 1043.1

* The pump head comprises an intermediate plate and a connect-

ing plate (Fig. 1).

The pump type TT stands for:

Assembly Material1)

Pump head* PVDF

Valve socket PVDF / FFKM

Sealing washer FFKM

Diaphragm PTFE

Tab. 3 1) according to DIN ISO 1629 and 1043.1

Diaphragm Liquid Pump NF 1.30 For your notes

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

Translation of original Operating and Installation Instructions 7

Hydraulic ratings

Parameter Value

Flow rate [ml/min] 1), 2) 170

Permissible pressure [bar g] 4

Suction head [mWG] 5

Tab. 4

1) Measured with water at 20°C / at atmospheric pressure

2) Flow rates may vary from the values shown, depending on fluid

viscosity, pump head material and the hoses / hose connectors

used.

Hydraulic connections

Parameter Value

Recommended hose size ID [mm] / OD

[mm]

4/6

Tab. 5

Specifications NF 1.30 DCG

Motor voltage 12V 24V

Power consumption [W] 10.1 11

Max. I load [A] 0.61 0.35

Max. permissible operating

current [A] 0.84 0.46

Lead size [-] AWG28

Protection class [-] IP00

Weight1) [g] 220

Tab. 6

1) The weight may differ slightly from the stated value, depending on

the version.

Other parameters

Parameter Value

Permissible

ambient temperature range (°C)

+5 to +40

Permissible media temperature range (°C) +5 to +80

Permissible kinematic viscosity of medium

[cSt]

≤150

Tab. 7

Assembly and function Diaphragm Liquid Pump NF 1.30

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

8 Translation of original Operating and Installation Instructions

5. Assembly and function

Assembly

1 Outlet

2 Inlet

3 Head plate

4 Connecting plate

5 Intermediate plate

6 Motor

Fig. 1: Diaphragm liquid pump

1 Outlet valve

2 Inlet valve

3 Working chamber

4 Diaphragm

5 Eccentric

6 Connecting rod

7 Pump drive

Fig. 2: Pump assembly

The diaphragm liquid pumps are based on reciprocating displace-

ment pump technology. The elastic diaphragm (4) is moved up and

down by the eccentric (5) and the connecting rod (6). In the down-

ward stroke it aspirates the medium to be transferred via the inlet

valve (2). In the upward stroke the diaphragm pushes the medium

out of the pump head via the outlet valve (1). The diaphragm

hermetically seals off the working chamber (3) from the pump

drive (7).

Diaphragm Liquid Pump NF 1.30 For your notes

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

Translation of original Operating and Installation Instructions 9

6. Installation and connection

Install the pumps only under the operating parameters and condi-

tions described in Chapter 4. Technical data.

Observe all safety precautions (see Chapter 3).

6.1. Installation

 Before installation, store the pump at the installation location to

bring it up to ambient temperature.

 Mounting dimensions (see Fig. 3)

Fig. 3: Mounting dimensions NF 1.30 DCG

 Make sure that the installation location is dry and the pump is

protected against water in the form of rain, spray, splashes and

drips.

 Protect the pump against dust.

 Protect the pump against vibration and impact.

 Generally speaking, the pump can be installed in any position.

For maximum precision and rapid venting, install pump as

shown in the illustration (Fig. 4).

 KNF recommends mechanically decoupling the pump from the

piping system, e.g. by using flexible hoses or pipes. This pre-

vents any oscillations of the pump being transferred to the sys-

tem.

Mounting dimensions

Installation location

Installation position

Fig. 4: Optimum

installation position

Decoupling

Installation and connection Diaphragm Liquid Pump NF 1.30

KNF Flodos AG BA_NF1.30_EN_04_067674.docx

10 Translation of original Operating and Installation Instructions

6.2. Electrical connection

 Only have the pump connected by an authorised specialist.

 Only have the pump connected when the power supply is

disconnected.

 When connecting the device to a power source, the relevant

norms, directives, regulations and technical standards must be

observed.

Connecting the pump

Make sure that the power supply data match the data on the

motor's type plate. The operating current can be found on the

type plate.

Connect positive and negative terminals. For electrical data

see Chapter 4

With DC motors, please pay attention to correct polarity:

red motor cable: +

black motor cable: -

6.3. Hydraulic connection

 Only connect components to the pump that are designed to

handle the hydraulic data of the pump (see

Chapter 4. Technical data)

 Only use hoses that are suitable for the maximum permissible

operating pressure of the pump (see Chapter 4).

 Only use hoses that are sufficiently chemically resistant to the

liquids being transferred.

6.3.1. Connecting the pump

Arrows on the pump head indicate the flow direction.

Remove the protective caps.

Connect the suction and pressure lines.

Keep the suction line as short as possible in order to keep the

priming process as brief as possible.

If the pump is used to build up pressure, make sure that all

transition joints between hose and pump are secure in order to

ensure that the hoses cannot come off.

Check that the hoses and transition joints are fitted correctly

and securely.

Check that the system is leak-tight.

Connected

components

Hoses

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels KNF Pompe à eau

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
