In-Wall Loudspeaker

R-5502-W

requency response 46Hz-20kHz +/-3dB

power handling 75W continuous / 300W peak

recommended ampliﬁer power 130W

sensitivity 92dB @ 2.83V / 1m

nominal impedance 8 ohms compatible

high frequency drivers 1” (2.5cm) Titanium diaphragm

compression driver mated to pivoting

90° x 90° square Tractrix®Horn

high freq crossover 2200Hz & 1300Hz

low frequency drivers Dual 5.25” (13.3cm) Cerametallic™

cone woofers

enclosure material ABS

enclosure type Inﬁnite bafﬂe, front ﬂush with wall

dimensions 17.75” (45.1cm) H x 8” (20.3cm) W

mounting depth 3.5” (8.9cm)

cutout dimensions 16.5” (41.9cm) H x

6.5” (16.5cm) W

installation kit IK-502-W (sold seperately)

weight 6.5lbs (2.9kg)

ﬁnishes White paintable frame and grille

SpecificationS

The R-5502-W employs dual 5.25-inch

Cerametallic woofer cones for fast, accurate

sound with dynamic detail, while a titanium

tweeter mated to a pivoting Tractrix®Horn

generates ﬂat in-room frequency response

with high efﬁciency and low distortion. The

speaker’s precision-voiced crossover net-

works further ensure that the high and low

frequencies are faithfully reproduced.

This in-wall speaker also consistently

delivers thrilling, realistic sound, whether it’s

installed horizontally or vertically. It fea-

tures all-new sure-grip mounting dogs that

provide even pressure against drywall for

long-term installation reliability, and includes

a paintable grille that blends in perfectly with

any décor.

Bass and treble switches with custom EQ

settings allow the speaker to be tailored to

its environment, while IR receiver knockout

holes allow for infrared repeaters, bringing

custom conﬁguration to installers.

Furthermore, the R-5502-W offers unlimited

ﬂexibility. It is timbre matched to all of our

5000 series architectural products, so you

can mix and match to create a high-perfor-

mance, discreet stereo or home theater

system that’s just right for you.

• Perfect for left, center or right channel use

• Easily mounts horizontally or vertically

• Horn-loaded for high efciency and low distortion

• Bass and treble switches, IR receiver knockouts

• Maximum installation reliability

• Mix and match with our 5000 series products
