Klipsch Icon XL-23 Manuel utilisateur

Engineered for pure, dynamic listening,

the XL-23 utilizes a premium titanium

diaphragm compression driver and dual

high-output ﬁberglass cone woofers.

But what puts this ﬂat-panel speaker

above the rest is an all-new patent-pend-

ing Tractrix®horn-loaded tweeter with

XT™ technology. For over 60 years, horns

have been the driving force behind our

stunningly precise sound, and this latest

design moves us farther ahead by allowing

the slender XL-23 to deliver an extremely

smooth response with constant directivity.

Offering more than just a signature sound,

the XL-23 also has a signature style. Its

beautifully crafted aluminum extruded

enclosure, featuring an anodized black-

grain ﬁnish and high-gloss black accents,

is the direct result of our engineers’ quest

for perfect balance. In fact, it’s a look that

brings a splash of sophistication to any

room.

For increased placement ﬂexibility, the

XL-23 can be paired with the company’s

optional XFS ﬂoor stand.

The entire ICON Series is performance

art at its best, capturing the spirit of our

past and pushing us into the future. It is a

brilliant representation of how our prod-

ucts have evolved and remained desirable

over time. After just one listen, the ICON

sound will be imprinted in your conscious-

ness forever.

XL-23 LCR

www.klipsch.com

1-800-KLIPSCH

LCR Flat-Panel Speaker

frequency response 86Hz-23kHz +/-3dB

low frequency extension 64Hz

power handling 70W continuous / 275W peak

recommended ampliﬁer power 125W

sensitivity 94dB @ 2.83V / 1m

nominal impedance 8 ohms compatible

high frequency drivers 0.75” (1.9cm) Titanium

diaphragm compression driver

mated to 80° x 80° round

XT Tractrix®Horn

high freq crossover 2500Hz

low frequency drivers Dual 4” (10.2cm) high-output,

ﬁberglass cone woofers

enclosure material Aluminum

enclosure type Bass-reﬂex via dual front-ﬁring ports

height 26.3” (66.7cm) including removable

table stand

width 5.75” (14.6cm)

depth 6.75” (17.1cm) not including removable

8” (20.3cm) diameter table stand

mounting Wall mount bracket and center

channel accessories included

(Also ﬁts optional XFS ﬂoor stand)

weight 18lbs (8.2kg)

ﬁnishes Black anodized w/ high-gloss

Black accents

built from 2007

SpecificationS

• Patent-pending XT™ Tractrix®Horn technology

• Titanium compression driver creates precise high frequencies

• Dual high-output woofers generate hard-hitting intensity

• Mounts to optional XFS ﬂoor stand for increased placement ﬂexibility
