Klipsch CDT-2800-C Manuel utilisateur

CDT-2800-C

With integrated whole-house audio systems

becoming more popular than ever, Klipsch

designed the CDT-2800-C to meet the

market’s demand for a high-performance in-

ceiling loudspeaker that easily challenges the

inherent limitations of fixed locations.

Thanks to a new patent-pending gimbal

mechanism, known as Controlled

Dispersion Technology™ (CDT), both the

high and low frequencies of the CDT-2800-

C can be directed towards the listening area.

Because the tweeter is independently

adjustable from the woofer, this speaker

offers even more precise localization.

The CDT-2800-C features a 1-inch silk

tweeter mated to a swiveling 100-degree

Tractrix® Horn. This swiveling horn design

dramatically increases efficiency by enabling

the speaker to produce more output using

less energy. Additionally, a horn-loaded

tweeter works well in instances where you

want to point the sound to a specific location

because it has more controlled directivity

than a conventional dome tweeter.

The speaker’s 8-inch polymer woofer also

has great positioning capabilities. It can

rotate a full 360 degrees and then shift 15

degrees in any direction. This flexibility

combined with the swiveling tweeter puts

you in complete control of where the sound

will go.

Available in a white finish, the paintable

CDT-2800-C can be paired with the Klipsch

IK-800-C installation kit (sold separately).

This revolutionary kit design incorporates a

8" Two-Way Pivoting In-Ceiling Loudspeaker

SPECIFICATIONS

FREQUENCY RESPONSE 65Hz-20kHz ± 3dB

SENSITIVITY 93dB @ 1 watt/1 meter

NOMINAL IMPEDANCE 8 ohms

CROSSOVER FREQUENCY 2177Hz

POWER HANDLING 50 watts (200 watts peak)

ENCLOSURE MATERIA/TYPE ABS/ Infinite baffle, front flush with ceiling

DRIVE COMPONENTS Two-way system using one 1" (2.5cm)

silk dome tweeter with a swiveling 100˚

Tractrix Horn and one 8" (20.3cm) pivoting

poly woofer

WIRE GAUGE ACCOMMODATED 12

WEIGHT 7.1 lbs. (3.2 kg)

DIAMETER 11" (27.9cm)

MOUNTING DEPTH 5.4" (13.7cm)

CUTOUT DIMENSIONS 9.8" (24.9cm)

INSTALLATION KIT IK-800-C (sold separately)

FIRE RATED ENCLOSURE ME-800-C (sold separately)

■Good sensitivity and power handling, strong bass

■Rugged ABS frame

■Paintable to match ceiling

www.klipsch.com

1-800-KLIPSCH

mud ring, breakaway wire tie and color-coded brackets for easy speaker

size identification. It also includes perforated metal wings that easily fasten

to the studs via screws, staples or nails. Painted white for easy marking

and placement, these metal wings can be folded around the edge of the

studs if necessary.
