COOKTOP PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

3−11 Litho in U.S.A. (JMJ) (bay) Part No. W10206095 Rev. C

30" FREE STANDING

ELECTRIC RANGE

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10168033

Use & Care Guide

W10167997

Wiring Diagram

W10185365

Installation

Instructions

2 Cooktop

W10217633

White

W10275755

Black

W10217638

Biscuit

3 74008761 Spacer Snap−In (4)

4 8523698 Element LR/RR (2)

5 74011676 Element, Warm

Y04100418

Spring, Element

7 74009538 Screw

4011F497−51

Bottom, Burner Box

7406P441−60

Element, RF Triple

10 4453909 Element, LF Double

CONTROL PANEL PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

3801F945−51

Bracket, Control

6 74011983 Control

7 End Cap, Left

74009023 Black

74009079 White

74009080 Biscuit

8 74003976 Screw

9 Shield, Heat Visor

74009202 Black

74009203 White

74009204 Biscuit

10 74009444 Shield, Vent

12 74010983 Cover, Rear Wire

13 End Cap, Right

74009022 Black

74009077 White

74009078 Biscuit

14 74002979 Screw

15 71001394 Screw

16 74004153 Light, Indicator

17 Knob (4)

W10160370

Black

W10160371

S.Steel

W10160368

White

W10160369

Biscuit

7730P011−60

Lens

2 Panel, Backguard

& Switch Assy

W10182778

Black

W10182780

White

W10183576

Biscuit

W10218257

Stainless Steel

7101P309−60

Screw, Switch (10)

4 Switch, Infinte

74010824 Dual RF/LR (2)

7403P238−60

LF/RR (2)

74008940 Low Heat

CHASSIS PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

CHASSIS PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Panel, Side

74008709 White

74008710 Black

74008708 Biscuit

2 71001394 Screw

3 74008701 Retainer, Side

8002P104−60

Latch Assembly

4002P347−51

Main Back

6 74009651 Cover, Main Wire

7 74008762 Bottom Wire Cover

7101P338−60

Screw

9 74008759 Insulator, Cord

4005P703−51

Cover, Wire (LWR)

4005P704−51

Panel, Access

7103P027−60

Nut, Term.Block

7401P039−60

Block, Terminal

3605F146−51

Plate, Conduit

15 74008703 Switch, Door

16 74008706 Rod, Door Switch

17 74008704 Insulator, Shield

18 74008707 Bumper

19 74008835 Clip, Retainer

20 74002373 Leg, Leveling

21 74005564 Bracket, Anti−Tip

7101P485−60

Screw, Anti−Tip

23 74008689 Shield, Heat

24 74002979 Screw, 8AB 1/2 (4)

7406P493−60

Element, Broil

26 74004943 Sensor, Oven

27 74008691 Vent, Oven

28 74011299 Lens, Bulb

7101P282−60

Screw (4)

30 71001394 Screw, Shoulder(6)

W10162385

Gasket

32 74008690 Spacer, Side Pnl.

33 74010551 Receiver, Hinge

34 74011278 Light Assembly

35 74011187 Bracket, Oven

36 74003975 Screw (Black) (2)

37 74008705 Rod, Door Sleeve

7407P103−60

Bulb, Oven

39 74003976 Screw, Shoulder

3801P822−45

Support, Ov BTM

41 74011117 Element, Bake

3807P680−45

Support, Oven

43 74008741 Bottom, Oven

3401F084−45

Pan, Bake Brnr

45 74008715 Switch, Terminal

7101P336−60

Screw (2)

INSULATION

74008700 Insulation, Wrap

7002P492−60

Insulation, Back

3804F316−51

Retainer,

Insulation

DOOR PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Trim, Door Top

3608F139−70

Black

3608F139−71

White

3608F139−78

Biscuit

2 Spacer, Handle

W10169552

Black

W10169553

White

W10169554

Biscuit

3 74010546 Hinge, Door (2)

3601F380−51

Baffel, Retainer

5 74002979 Screw (6)

6 74003645 Glass, Inner (2)

7 74003644 Frame, Glass Inner

8270P090−60

Tape, Foil

W10176584

Screw

10 74008926 Lining, Door

11 74011458 Bracket, Glass (2)

12 74003647 Insulation, Door

13 Y706189 Screw (8)

14 Bracket, Handle

3801P858−45

Left

3808P857−45

Right

15 74004224 Tape, White

16 Trim, Door Side

74010560 Black

74010561 White

74010562 Biscuit

17 Tape, Double Sided

74009014 White

74009025 Black

74009014 Biscuit

18 Trim, Door Bottom

74008757 White

74008745 Black

74008758 Biscuit

7101P282−60

Screw 10−24x5/16

20 Glass, Door

W10182776

White

W10182773

Black

W10183574

Biscuit

W10160909

S. Steel

(Order Item #15

When Replacing

Door Glass)

21 Handle, Door

W10153013

White

W10153016

S.Steel

W10153015

Black

W10153014

Biscuit

7760P218−60

Panel, SS Outer

DRAWER AND RACK PARTS

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

Illus. Part

No. No. DESCRIPTION

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

8270P098−60

Tape, Double Sided

2 74004310 Screw (2)

3 74008877 Drawer, Storage

7103P139−60

Nut, Lock

5 74005546 Spacer, Rubber

6 74005231 Shaft, Roller

7 74001530 Screw

7103P082−60

Nut

9 Panel, Drawer

W10163040

White

W10163038

Black

W10163041

Biscuit

3406P034−51

Runner, Drawer

11 74005230 Nut, Lock

12 74004078 Roller, Drawer

13 74005231 Shaft, Roller

14 74008688 Stop, Drawer

15 74008763 Rack, Oven

3605P337−51

Plate, Inner

7701P547−60

Handle, SS Only

W10165339

Panle, SS Only

OPTIONAL PARTS (NOT INCLUDED)

For Models: KERS205TWH0, KERS205TBL0, KERS205TSS0, KERS205TBT0

(White) (Black) (S.Steel) (Biscuit)

W10206095

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

REFINISHING MATERIAL

799832 Kit, Porcelain

Repair (White)

242756 Touch−Up

Self−Clean(1/2 Pt)

261582 Grease

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

4392899 Biscuit

511873 White Porcelain

(2 Oz.)

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

4392901 Biscuit

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

4392900 Biscuit(Uncut)

ACCESSORY PARTS

241430 Foil, Aluminum

Oven (18" x 25’)

3191048 Cleaner, Glass

WIRING HARNESS PARTS

5171P792−60

Harness, Wire

(Cooktop Right)

5171P791−60

Harness, Wire

(Cooktop Left)

W10167991

Harness, Wire

(Burner Box)

W10160683

Harness, Wire

(Main)

74006811 Clip, Wire

7101P027−60

Screw, Ground
