KitchenAid KHM31 Manuel utilisateur

Hand Mixer

KHM31, KHM51 and KHM61

PARTS AND FEATURES

1Swivel Lock Power Cord

2Non-Tip Heel Rest

3Comfort Designed Handle

4Easy-to-Use Speed Control

5Oversized Beater Ejector Button

6Air Vents

73-Speed Control

85-Speed Control

96-Speed Control

10 Stainless Steel Turbo Beater™

Accessory

11 Flex Edge Beaters*

12 Stainless Steel 16-Tine Pro Whisk*

13 Integrated Storage Clip*

/ 0

*Accessories available with select models.

11 13

/ 0

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against the risk of electrical shock do not put Hand Mixer in water or

other liquid.

3. This appliance is not intended for use by children or by persons with reduced

physical, sensory, or mental capabilities, or lack of experience and knowledge.

Close supervision is necessary when any appliance is used near children.

Children should be supervised to ensure that they do not play with the appliance.

4. Turn the appliance OFF/0, then unplug from the outlet when not in use, before

assembling or disassembling parts and before cleaning. To unplug, grasp the

plug and pull from the outlet. Never pull from the power cord.

5. Avoid contacting moving parts. Keep hands, hair, and clothing, as well as

spatulas and other utensils, away from Beater during operation to reduce the risk

of injury to persons and/or damage to the Hand Mixer.

6. Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorized Service Facility for examination, repair, or

electrical or mechanical adjustment.

7. The use of accessories or attachments not recommended or sold by the

manufacturer may cause re, electric shock or injury.

8. Never leave the appliance unattended while it is in operation.

9. Do not use the appliance outdoors.

10. Do not let the cord hang over the edge of table or counter.

PRODUCT SAFETY

ELECTRICAL REQUIREMENTS

Voltage: 120 V

Frequency: 60 Hz

NOTE: This Hand Mixer has a polarized plug (one blade is wider than the other). To

reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If

the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician. Do not modify the plug in any way.

ACCESSORY GUIDE

11. Do not let the cord contact hot surface, including the stove.

12. Remove any accessories from the Hand Mixer before washing.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

To order these accessories

In USA: visit www.shopkitchenaid.com, or call 1-800-541-6390.

In Canada: call 1-800-807-6777.

Accessory Uses Included with Model

KHM31 KHM51 KHM61

Turbo Beater™

Cookie dough, Cake batter • • •

Flex Edge Beaters*

Cake batter, Pancake batter,

Cookie dough, Cheese spreads,

Frosting, Mashed potatoes,

Brownie mixes

•

16-Tine Pro Whisk* Whipped cream, Puddings,

Whipped egg whites, Sauces •

Storage Clip* To store accessories •

*Accessories available with select models.

ENGLISH

SPEED CONTROL GUIDE

NOTE: The Turbo Beater™ accessories are not designed for mixing and kneading

bread dough.

IMPORTANT: Hand Mixer should always be set on the lowest speed to start mixing.

Move to higher speeds as needed.

First, clean all parts and accessories (see “Care and Cleaning” section).

3-Speed

Hand Mixer 5-Speed

Hand Mixer 6-Speed

Hand Mixer Attachment Uses

1 1 Turbo Beater

™,

Flex Edge Beater

For slow stirring,

combining, and starting

all mixing procedures. Use

this speed to stir in nuts,

chocolate chips, shredded

cheese, onions, olives, and

other chunky ingredients.

Helps prevent ingredients

from splashing out of bowl.

2 2

Turbo Beater

™,

Flex Edge Beater

Mix flour and other dry

ingredients with liquids or

other moist mixtures.

Turbo Beater

™,

Flex Edge Beater

Mix pancake batter.

3 3

Turbo Beater

™,

Flex Edge Beater

Combine heavy mixtures,

such as cookie dough.

Mix light cream cheese

spreads. Stir batters and

gelatin mixtures.

Turbo Beater

™,

Flex Edge Beater

Mix muffins and quick

breads. Combine heavy

cream cheese mixtures.

Mash potatoes or squash.

4Turbo Beater

™,

Flex Edge Beater

Mix batter breads. Blend

butter and sugar. Mix

frostings.

5Turbo Beater

™,

Flex Edge Beater

Finish mixing cake and

other batters. Whip

heavy cream and mousse

mixtures.

5 6

Turbo Beater

™,

16-Tine Pro Whisk

Beat egg whites. Whip

heavy cream and mousse

mixtures.

Turbo Beater

™,

16-Tine Pro Whisk Beat meringue mixtures.

ATTACHING THE ACCESSORIES

PRODUCT ASSEMBLY

IMPORTANT: Be sure to read and follow

the specific instructions in this manual for

proper use of the Hand Mixer.

Before attaching an Accessory, make sure

the Hand Mixer is unplugged from the

electrical outlet.

Paired accessories (Beaters, optional

Dough Hooks) include one accessory

with a collar (D) and one without (C).

The single accessory comes with a collar

(D) (Liquid Blending Rod) or without (C)

(Whisk).

Insert the accessory shaft with the collar

(D) into the larger opening (B) of the

Hand Mixer. Align the flanges on the shaft

with the slots in the opening. Push to lock

into place.

Insert the Accessory without a collar (C)

into the smaller opening (A). Align and

push to lock into place.

4NOTE: An accessory shaft without a collar

maybe used in either opening (A or B).

Those with a collar may only be used in

the larger opening (B).

ENGLISH

REMOVING THE ACCESSORIES

PRODUCT DISASSEMBLY

/ 0

First, stop the Hand Mixer by sliding the

Speed Control to the “OFF/0” position.

Then unplug from the electrical outlet.

Press the Ejector Button to release the

accessories from the Hand Mixer, then

remove them.

This KitchenAid®Hand Mixer will beat faster

and more thoroughly than most other electric

Hand Mixers. Therefore, the beating time in

most recipes must be adjusted to avoid over

beating. Beating time is faster due to larger

Beater sizes.

To help determine the ideal beating time,

observe the batter or dough and beat only

until it has the desired appearance described

in your recipe, such as “smooth and creamy”.

To select the best beating speeds, see the

“Speed Control Guide” section.

OPERATING THE SPEED CONTROL

PRODUCT USAGE

/ 0

First, turn the Hand Mixer to the “OFF/0”

position. Then plug into an electrical

outlet.

Always start mixing at the lowest speed,

which is Speed 1.

PRODUCT USAGE

To increase the speed, slide the Speed

Control forward.

To decrease the speed, slide the Speed

Control backward.

/ 0

When finished, turn the Hand Mixer to

the “OFF/0’’ position. Then unplug from

the electrical outlet.

CARE AND CLEANING

IMPORTANT: Do not immerse the Hand Mixer body in water or other liquids. Do not

use abrasive cleansers or scouring pads to avoid scratching.

Wipe the Hand Mixer body with a soft,

damp cloth.

/ 0

Turn the Hand Mixer to the “OFF/0’’

position. Then unplug from an electrical

outlet.

Electrical Shock Hazard

Do not put in water.

Doing so can result in death or

electrical shock.

ENGLISH

The following parts are dishwasher-safe,

top rack only: Turbo Beater*, Flex Edge

Beaters*, 16-Tine Pro Whisk*, and

Storage Clip*.

After cleaning of the Flex Edge Beaters*

and 16-Tine Pro Whisk*, fix those to the

Integrated Storage Clip* and assemble

the Clip onto the bottom of the Hand

Mixer.

3 4

CARE AND CLEANING

*These parts can also be washed by hand in warm, soapy water and dry thoroughly.

TROUBLESHOOTING GUIDE

Problem Solution

If the Hand Mixer fails to start:

Check if the Hand Mixer is securely plugged into an

outlet.

If you have a circuit breaker box, make sure the circuit is

closed.

If the problem cannot be

corrected:

Contact KitchenAid or an Authorized Service Center**.

See the “Warranty and Service” section.

Do not return the Hand Mixer to the retailer; retailers do

not provide service.

**USA/Puerto Rico: 1-800-541-6390,

Canada: 1-800-807-6777,

Mexico: 01-800-024-17-17

(JV Distribuciones)

01-800-902-31-00

(Industrias Birtman)

WARRANTY AND SERVICE

KITCHENAID®HAND MIXER WARRANTY FOR THE 50 UNITED

STATES, THE DISTRICT OF COLUMBIA, PUERTO RICO, AND CANADA

This warranty extends to the purchaser and any succeeding owner for Hand Mixer

operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada.

Length of Warranty: One Year Full Warranty from date of purchase.

KitchenAid Will Pay

for Your Choice of: Hassle-Free Replacement of your Hand Mixer. See

the next page for details on how to arrange for

service, or call the Customer eXperience Center

toll-free at 1-800-541-6390.

The replacement parts and repair labor costs to correct

defects in materials and workmanship. Service must be

provided by an Authorized KitchenAid Service Center.

KitchenAid Will

Not Pay for: A. Repairs when your Hand Mixer is used in other

than normal single family home use.

B. Damage resulting from accident, alteration,

misuse or abuse.

C. Any shipping or handling costs to deliver your

Hand Mixer to an Authorized Service Center.

D. Replacement parts or repair labor costs for

Hand Mixer attachments operated outside the

50 United States, District of Columbia, Puerto

Rico, and Canada.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED

TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY

BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD

ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS

OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY

OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY

TO YOU.

IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND

EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE

TERMS OF THIS LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA

DO NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL

DAMAGES. This warranty gives you speciﬁc legal rights and you may also have other

rights which vary from state to state or province to province.

Autres manuels pour KHM31

Table des matières

Autres manuels KitchenAid Batteur à main

KitchenAid

KitchenAid KHM620 Guide rapide

KitchenAid

KitchenAid KHM9218Q Manuel utilisateur

KitchenAid

KitchenAid KHMR700 Manuel utilisateur

KitchenAid

KitchenAid 5KHMB732C Manuel utilisateur

KitchenAid

KitchenAid KHM72 Series Manuel utilisateur

KitchenAid

KitchenAid KHM5TB - 5 Speed Classic Manuel utilisateur

KitchenAid

KitchenAid 5KHM5110 Manuel utilisateur

KitchenAid

KitchenAid 4-C Manuel utilisateur

KitchenAid

KitchenAid 5KHMR700A Manuel utilisateur

KitchenAid

KitchenAid 5KHM926 Manuel utilisateur

KitchenAid

KitchenAid KHM61 Manuel utilisateur

KitchenAid

KitchenAid KHMR700 Manuel utilisateur

KitchenAid

KitchenAid KHM7212QTG Manuel utilisateur

KitchenAid

KitchenAid KHM3WH - Hand Mixer Manuel utilisateur

KitchenAid

KitchenAid 5KHM9212 Manuel utilisateur

KitchenAid

KitchenAid 5KHM9212EER Manuel utilisateur

KitchenAid

KitchenAid KHM920ACS0 Guide rapide

KitchenAid

KitchenAid 5KHM5110 Manuel utilisateur

KitchenAid

KitchenAid KHM720 Guide rapide

KitchenAid

KitchenAid KHM7210 Manuel utilisateur

KitchenAid

KitchenAid 5KHM6118 Manuel utilisateur

KitchenAid

KitchenAid KEE07A Manuel utilisateur

KitchenAid

KitchenAid KHM9PER - Hand Mixer Manuel utilisateur

KitchenAid

KitchenAid Ultra Power Plus Guide rapide

Manuels Batteur à main populaires d'autres marques

Philips

Philips Essence 5000 Series Manuel utilisateur

emerio

emerio HM-110921.1 Manuel utilisateur

ARDES

ARDES ARSBAT01 Manuel utilisateur

ECG

ECG RS 840 Manuel utilisateur

TEFAL

TEFAL PREP'LINE HT4111 Manuel utilisateur

Oster

Oster 2534 Manuel utilisateur

Bosch

Bosch CleverMixx Spotlight MFQ25 Series Manuel utilisateur

Grundig

Grundig HM 6280 Manuel utilisateur

Clatronic

Clatronic ProfiCook SM 3044 Manuel utilisateur

Oster

Oster 2574 Manuel utilisateur

DCOOK

DCOOK 5425945 Manuel utilisateur

Gorenje

Gorenje ME510W Manuel utilisateur

Oster

Oster 2534 Manuel utilisateur

Sunbeam

Sunbeam 2484 Manuel utilisateur

Currys

Currys Essentials C12HMW17 Manuel utilisateur

Orbegozo

Orbegozo BA 3250 Manuel utilisateur

Dynamic

Dynamic Dynamix Nomad Manuel utilisateur

GE 106716 Manuel utilisateur
