KitchenAid KECC567BAL1 Manuel utilisateur

NOTE: The screws and nuts required to attach a part are listed immediately

following that part.

1 Trim Ring, Cooktop

3187820 Black

3187821 White

3187822 Almond

2 Cooktop, Glass

3187818 Black

3187819 White

3188896 Almond

4 3188308 Bracket, Switch Mounting

6 3189165 Spring Locator(10)

246119 Screw (8)

7 Switch, Infinite

3188755 Use W/2400/1000W Left Rear Burner

3188755 Use W/2200/1000W Right Rear Burner

3148970 Use W/1500W Right Front Burner

3148969 Use W/1200 W Left Front Burner

3148970 Use W/1400W Center Rear

8 3183956 Seal, Switch Shaft

311865 Screw

10 Knob, Control (4)

9750372FF Black

9750372FW White

9750372FT Almond

11 3188103 Box, Burner

13 3188533 Grommet

4159456 Screw

15 3182435 Seal, Switch (5)

16 Switch, Limiter

3189667 Use W/3189655 Element

3189668 Use W/3189656 Element

3190253 Use W/3189894 Element

3190247 Use W/3189901 Element

3190441 Use W/3189899 Element

18 3189843 Plate, Backer

19 Seal, Silicone

3185589 Small (2)

3188854 Large (2)

20 3187753 Shield, Heat

4159456 Screw

21 Seal, Silicone

3188852 8 In.

3188853 11 In.

22 3189756 Lamp, Hot Surface Indicator

4168863 Screw

23 3189152 Bracket, Stiffening

4159456 Screw

24 Element, Surface (Includes # 16)

3189655 1200W Left Front

3189656 1500 W Right Front

3189894 1400W Center Rear

3189901 2200/1000W Right Rear

3189899 2400/1000 Left Rear

29 3188876 Shield, Heat

4159456 Screw

30 3189175 Bracket, L

4159456 Screw

31 3188309 Shield, Heat

32 3188158 Plate, Interior

4159456 Screw

33 3189159 Plate, End

4159456 Screw

34 3189036 Plate Louver

4159456 Screw

35 3189273 Cover, Conduit

37 3188760 Housing, Backlight

311865 Screw

38 3188761 Lens, Backlight

39 3188786 Insulator

4159456 Screw

1 3189759 Wiring Harness Surface Unit

2 3179589 Tie, Wire

FOLLOWING PARTS NOT ILLUSTRATED

LITERATURE PARTS

LIT3189330 Installation Instructions

LIT3190374 Wiring Diagram

LIT4454475 Use & Care Guide

Miscellaneous

3172515 Mtg. Hardware Kit

FOLLOWING PARTS NOT ILLUSTRATED

SPLICING WIRES--25FT. LENGTH

242828 Wire, Black 12 Ga. 150~ C

242820 Wire, Black 14 Ga. 150~ C

242822 Wire, Blue 14 Ga. 150~ C

242830 Wire, Brown 14 Ga. 200~ C

242823 Wire, Green 14 Ga. 150~ C

242824 Wire, Orange 14 Ga. 150~ C

242829 Wire, Red 12 Ga. 150~ C

242825 Wire, Red 14 Ga. 150~ C

242831 Wire, Red 14 Ga. 200~ C

242826 Wire, White 14 Ga. 150~ C

242827 Wire, Yellow 14 Ga. 150~ C

242832 Wire, Yellow 14 Ga. 200~ C

ACCESSORY PARTS

3184478 Cleaner, Glass

3183488 Scraper, Glass
