KitchenAid KES6403 Manuel utilisateur

KES6403, KES6503

W11312156C.indb 1W11312156C.indb 1 8/12/2020 7:43:37 PM8/12/2020 7:43:37 PM

 

11 12 13 14

PARTS AND FEATURES

1Water Tank (Capacity: 47 ounces)

2Water Tank Handle

3Water Tank Lid

4Cup Warmer

5Drip Tray Plate

6Drip Tray

7Main Power On/Off Switch

8Steam Wand

9Steam Wand Release Button

10 Portafilter (58 mm)

11 Mode Button : Espresso

: Steam

: Hot Water

12 Dose Button : 1(1 shot)

: 2(2 shot)

13 Clean Cycle Button

14 Start/Cancel Button

15 Empty Drip Tray Indicator

16 Group Head

Milk

Pitcher Coffee

Scoop

Tamper Single wall

1 shot Single wall

2 shot Double wall

1 shot Double wall

2 shot

W11312156C.indb 2W11312156C.indb 2 8/12/2020 7:43:37 PM8/12/2020 7:43:37 PM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. Close supervision is necessary when any appliance is used by or near children.

4. To protect against re, electric shock, and personal injury do not immerse cord,

plugs, or appliance in water or other liquids.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts, and before cleaning.

6. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, or is dropped or damaged in any manner. Contact the

manufacturer at their customer service telephone number for information on

examination, repair, or adjustment.

7. The use of accessory attachments not recommended by the appliance

manufacturer may result in re, electric shock, or personal injury.

8. Do not use the appliance outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Always turn the appliance off, then plug cord into the wall outlet. To disconnect,

turn the appliance off, then remove plug from wall outlet.

12. Do not clean the Espresso Machine with abrasive cleaners, steel wool, or other

abrasive materials.

W11312156C.indb 3W11312156C.indb 3 8/12/2020 7:43:38 PM8/12/2020 7:43:38 PM

PRODUCT SAFETY

ELECTRICAL REQUIREMENTS

Voltage: 120 V~

Frequency: 60 Hz

Wattage: 1460 W

NOTE: If the plug does not fit in the outlet,

contact a qualified electrician or service

person. Do not modify the plug in any way.

Do not use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualified

electrician or service person to install an

outlet near the appliance.

The cord should be arranged so that it will

not drape over the countertop or tabletop

where it can be pulled on by children or

tripped over unintentionally.

13. Use extreme caution when using hot steam.

14. Do not use appliance for other than intended use.

15. Irritation to skin or eyes can occur if they come into contact with the descaling

solution. Avoid skin and eye contact. Rinse off descaling solution with clean

water. Obtain medical advice after eye contact.

16. Damage to delicate surfaces can occur after contact with the descaling solution.

Remove any splashes immediately.

17. WARNING: To avoid the risk of injury, do not open the brew chamber during the

brew process.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

W11312156C.indb 4W11312156C.indb 4 8/12/2020 7:43:38 PM8/12/2020 7:43:38 PM

ENGLISH

Plug into a grounded 3 prong outlet.

Press the Main power switch to “ON (-)”.

 

The machine automatically pumps water

into the heater and starts heating. When

lights stop blinking, the Espresso Machine

is ready for use.

WARNING

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, fire, or

electrical shock.

GETTING STARTED

First, clean all parts and accessories (See “Care and Cleaning” section).

Place the Espresso Machine on a dry, at, level surface such as a countertop or table.

MAX

Fill the Water Tank with fresh water

(max. 47 ounces / 1.4 liters). Replace the

Water Tank Lid.

Insert the Steam Wand until you hear a

click.

IMPORTANT: Distilled water or mineral water can damage the Espresso Machine.

Do not use either to brew espresso.

W11312156C.indb 5W11312156C.indb 5 8/12/2020 7:43:38 PM8/12/2020 7:43:38 PM

GETTING STARTED

PRODUCT USAGE

BREWING ESPRESSO

Select desired Filter basket (see Basket

selection chart). Press the Filter basket into

the Portafilter until it clicks into place.

Fill the Filter basket with fine Espresso

coffee grounds (see Basket selection chart

for dosing recommendations).

Basket type Shot Dose (gram) Use for

Single wall 1 shot 10 - 12 Freshly ground whole bean coffee

Single wall 2 shot 18 - 20 Freshly ground whole bean coffee

Double wall 1 shot 10 - 12 Pre-ground coffee

Double wall 2 shot 18 - 20 Pre-ground coffee

BASKET SELECTION CHART

1 2

To rinse the Steam Wand, direct the Steam

Wand towards the Drip Tray or into a cup.

Then, toggle the Mode Button to select

Hot Water and press button to start.

Allow water to ow for 3 to 5 seconds

then, press button to stop.

1 2

To rinse the Group Head, place a container

under the Group Head. Toggle the Mode

Button to select Espresso. Toggle Dose

Button to 1and press button.

The machine will ush water through the

Group Head and automatically stop when

the cycle is complete.

W11312156C.indb 6W11312156C.indb 6 8/12/2020 7:43:39 PM8/12/2020 7:43:39 PM

ENGLISH

Tap the Portafilter to level the ground

coffee bed and rest on a flat surface.

Use the Tamper to tamp down the ground

coffee. Sweep excess coffee grinds from

the rim.

Position the Portafilter under the Group

Head with the handle align to unlock.

Raise the Portafilter into the Group Head

and twist to the right side to lock.

PRODUCT USAGE

1 2

Toggle the Mode Button to select Espresso.

Toggle the Dose Button to select desired

number of shots 1 (~ 1 ounce) or

2 (~ 2 ounces).

Press button to run selected Espresso

cycle.

NOTE: Do not remove the Portafilter when brewing.

TIP: Shot duration should be between 20-30 seconds for 1 and 2 shot selections.

- If less than 20 seconds: decrease grind size and/or increase tamp pressure.

- If more than 30 seconds: increase grind size and/or reduce tamp pressure.

W11312156C.indb 7W11312156C.indb 7 8/12/2020 7:43:39 PM8/12/2020 7:43:39 PM

PRODUCT USAGE

USING THE STEAM MODE FOR MILK

1 2

Toggle the Mode Button to select Steam.

The machine will automatically start

heating, indicated by the flashing Steam

light. The Steam light will go solid when

machine is ready for steaming.

Fill the Milk pitcher with desired amount of

cold milk.

TIP: Fill to bottom of the pour spout.

Adjust the Steam Wand to desirable

position. Submerge the tip of the Steam

Wand just below the surface of milk in the

Milk pitcher.

Angle the Steam Wand towards the Drip

Tray or into a cup. Press button to

start. Once water turns to steam, press

button to stop.

Press button to initiate the steam.

Froth until desired level of foam and

temperature is reached. To stop the steam,

press button again.

To avoid splattering, wait until the steam

stops before removing the Steam Wand

from the milk.

W11312156C.indb 8W11312156C.indb 8 8/12/2020 7:43:40 PM8/12/2020 7:43:40 PM

ENGLISH

PRODUCT USAGE

USING HOT WATER FEATURE

The Steam Wand can also dispense hot water which is great for an americano, tea, hot

chocolate, etc. You can also use hot water to pre-heat cups.

1 2

Toggle the Mode Button to select Water.

Place a cup under the Steam Wand.

1 2

Press Dose Button to select the volume of

water 1 (~ 4 ounces) or 2 (~ 6 ounces).

Press button to start water cycle.

Water flows out from the Steam Wand.

NOTE: You can pause the cycle by pressing button to stop the flow of water

before the cycle complete.

PROGRAMING FUNCTION

The Espresso Machine is equipped with programing functionality. Any customized settings will

be saved even in the event power is lost to the machine.

PROGRAMING THE ESPRESSO AND HOT WATER AMOUNT

1 2

To change pre-programmed Espresso

Volume for 1 or 2: Toggle the Mode

Button to select Espresso. Select the dose

you desire to program (1 or 2). Press and

hold button until desired espresso

amount is reached in your cup.

While programing your selected dose, the

dose and the button lights will blink.

Lights will stop blinking when programing

is complete.

1 2

To change pre-programmed Water

Volume for 1 or 2: Toggle the Mode

Button to select Water. Select the dose

you desire to program (1 or 2). Press

and hold button until desired water

amount is reached in your cup.

While programing your selected dose, the

dose and the button light will blink.

Lights will stop blinking when programing

is complete.

W11312156C.indb 9W11312156C.indb 9 8/12/2020 7:43:40 PM8/12/2020 7:43:40 PM

PROGRAMING THE WATER TEMPERATURE AND WATER HARDNESS

1 2

To change pre-programmed Water

Temperature: Toggle the Mode Button

to select Espresso, press and hold for 3

seconds.

The indicator lights will show the default

factory setting or previous saved setting

(see Indicator light chart for reference).

Toggle the Mode Button between Low-Mid-

High to select desired temperature.

To save your selection, press button or

wait for 10 seconds.

1 2

To change pre-programmed Water

Hardness: Toggle the Mode Button to

Water, Press and hold for 3 seconds.

The indicator lights will show the default

factory setting or previous saved setting

(see Indicator light chart for reference).

Toggle the Mode Button between Low-

Mid-High to select desired water hardness.

To save your selection, press button

or wait for 10 seconds.

INDICATOR LIGHT CHART

TIP: To restore all factory settings, Press and Hold “Dose Button” for 3 seconds.

All indicator lights will blink indicating that all settings are restored.

Water Temperature or Water Hardness

Low

Medium

High

NOTE: Water Hardness - Low: 0 to 60 ppm

Medium: 60 to 120 ppm

High: more than 120 ppm

PROGRAMING FUNCTION

TIP: To restore all factory settings, Press and Hold “Dose Button” for 3 seconds.

Changing the factory default Espresso or Water Volumes may impact the intended

performance of the machine.

W11312156C.indb 10W11312156C.indb 10 8/12/2020 7:43:41 PM8/12/2020 7:43:41 PM

Autres manuels pour KES6403

Table des matières

Autres manuels KitchenAid Cafetière

KitchenAid

KitchenAid 5KES0504AAC Manuel utilisateur

KitchenAid

KitchenAid KCM112 Manuel utilisateur

KitchenAid

KitchenAid KCM1209 Manuel utilisateur

KitchenAid

KitchenAid 5KES2102 Manuel utilisateur

KitchenAid

KitchenAid 5KES2102A Manuel utilisateur

KitchenAid

KitchenAid KPCM050PM - Pro Line Single-Carafe Coffee... Manuel utilisateur

KitchenAid

KitchenAid NESPRESSO KES0503 Manuel utilisateur

KitchenAid

KitchenAid KCM4212SX Manuel utilisateur

KitchenAid

KitchenAid KCM1402 Manuel utilisateur

KitchenAid

KitchenAid KCM514ER - JavaStudio Stainless-Steel Programmable... Manuel utilisateur

KitchenAid

KitchenAid ARTISAN 5KES100 Manuel utilisateur

KitchenAid

KitchenAid KCM1202 Manuel utilisateur

KitchenAid

KitchenAid KCM1208 Manuel utilisateur

KitchenAid

KitchenAid Pro line KPCM100 Manuel utilisateur

KitchenAid

KitchenAid 5KCM0802 Manuel utilisateur

KitchenAid

KitchenAid 5KCM1208 Manuel utilisateur

KitchenAid

KitchenAid 5KES6403 Manuel utilisateur

KitchenAid

KitchenAid KCM1204 Manuel utilisateur

KitchenAid

KitchenAid KCM0802 Manuel utilisateur

KitchenAid

KitchenAid KCM223 Manuel utilisateur

KitchenAid

KitchenAid KCM0812 Manuel utilisateur

KitchenAid

KitchenAid KCM1203 Manuel utilisateur

KitchenAid

KitchenAid 5KCM1208 Manuel utilisateur

KitchenAid

KitchenAid KCM1204OB Manuel utilisateur

Manuels Cafetière populaires d'autres marques

Taurus

Taurus Livorno 6 Manuel utilisateur

Delta-q

Delta-q QUICK Manuel utilisateur

Bunn

Bunn LCA-1 Guide de dépannage

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instructions d'installation

Saeco

Saeco Vienna Plus Sup 018M Manuel utilisateur

DeLonghi

DeLonghi DC300 Manuel utilisateur

INCAPTO

INCAPTO BXCO1470E Manuel utilisateur

Bosch

Bosch TASSIMO finesse TAS16B Series Manuel utilisateur

Exido

Exido 245-072 Manuel utilisateur

Animo

Animo OptiVend Choco Manuel utilisateur

Siemens

Siemens TQ505DF Series Manuel utilisateur

DeLonghi

DeLonghi ECI341 Manuel utilisateur

Krups

Krups KT406511 Manuel utilisateur

Cimbali

Cimbali M32 Classic Manuel utilisateur

Philips

Philips HL3844N Manuel utilisateur

Bosch

Bosch TES 515 SERIES Manuel utilisateur

Tekmatix

Tekmatix TMFM - 65 Manuel utilisateur

Scarlett

Scarlett SC-CM33005 Manuel utilisateur
