Balanced SCUBA Regulator

User Guide

Document P/N 100-141

Kirby Morgan Dive Systems, Inc.

1430 Jason Way

Santa Maria, CA 93455, USA

Telephone (805) 928-7772

FAX (805) 928-0342

E-Mail: [email protected]

Web Site: www.kirbymorgan.com

Kirby Morgan, SuperLite, BandMask, Band Mask, KMB, KMB-Band Mask,

DSI, Diving Systems International, EXO, REX, SuperFlow and DECA are all

registered trademarks of Kirby Morgan Dive Systems, Inc. Use of these terms

to describe products that are not manufactured by KMDSI is illegal.

The two dimensional images (such as photographs and illustrations) of our

products are © copyrighted and trademarks of Kirby Morgan Dive Systems,

Inc. The three dimensional forms of our products are trademark, trade design

and trade dress protected.

is made available for the express use of the owner of this Kirby Morgan product.

No part of this manual may be reproduced, stored in any retrieval system, or

transmitted, or used in any form or by any means, whether graphic, electronic,

mechanical, photocopy, or otherwise by technology known or unknown, without

the prior written permission of Kirby Morgan Dive Systems, Inc.

Document #170814005

Warranty Information

NOTE: Be sure to complete the

enclosed warranty card and return

it immediately, or you may register

your purchase online at www.kir-

bymorgan.com—go to Support.

KMDSI warrants every new Mask,

Helmet, SCUBA Regulator, Manifold

Block or Kirby Morgan Air Control

System 5 (KMACS 5) (each, a Product) to be free from de-

fects in workmanship for a period of three hundred sixty

ve (365) days from the date of purchase from a KMDSI

authorized dealer. This warranty covers all metal and

plastic parts, but does NOT cover rubber parts, communi-

cations components, or head and chin cushions. In addi-

tion, due to the electrolytic nature of underwater cutting

and welding, chrome plating cannot be warranted when

the diver engages in these activities.

Any defect of the product in workmanship or material

covered by this warranty discovered within three hundred

sixty ve (365) days from the date of purchase must be

promptly communicated in writing to the nearest autho-

rized KMDSI dealer or (if no such dealer in the buyer’s

country) contact KMDSI directly at (805) 928-7772. No

Product returns will be accepted by KMDSI with-

out a returned merchandise authorization (RMA)

number from KMDSI. Upon receipt of the RMA from

KMDSI, the buyer should return the defective Product or

part, freight prepaid, to an authorized KMDSI dealer or

the KMDSI plant, as directed by the RMA. KMDSI will

repair or replace the Product at no charge, within a rea-

sonable time, as it deems necessary.

Warranty Information

This warranty is null and void if:

1) The Product is not registered with KMDSI within ten

(10) days of purchase, or

2) The Product has not been properly serviced and main-

tained according to KMDSI factory recommended proce-

dures described in the manual and/or Product updates

have not been performed as recommended by KMDSI,

3) Unauthorized attachments or modications have been

made to the Product, or

4) The Product has been used for purposes other than

those for which it was designed, or otherwise has been

abused, misused, or subjected to unusual conditions, or

the Product’s intended service has been exceeded.

EXCEPT AS SPECIFICALLY PROVIDED HEREIN,

THERE ARE NO OTHER WARRANTIES, EXPRESS

OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,

ANY IMPLIED WARRANTIES FOR MERCHANT-

ABILITY OR FITNESS FOR A PARTICULAR PUR-

POSE. THE PRODUCT COVERED BY THIS WAR-

RANTY IS MARKETED AND SOLD BY KMDSI

SOLELY FOR COMMERCIAL OR INDUSTRIAL

USE AND IS NOT A CONSUMER PRODUCT IN-

TENDED FOR PERSONAL, FAMILY, OR HOUSE-

HOLD USE.

In purchasing any Product subject to this warranty, the

buyer agrees that its sole and exclusive remedy and KMD-

SI’s entire obligation in contract, tort, or otherwise under

this contract will be repair or replacement at KMDSI’s

option of the Product or any parts which KMDSI deter-

mines during the applicable warranty period are defective

in workmanship or material covered by this warranty. All

exchanged parts are the property of KMDSI. The buyer’s

Warranty Information

exclusive remedy and the KMDSI’s entire liability in

contract, tort, or otherwise is the payment by KMDSI of

the buyer’s actual damages up to but not to exceed the

amount paid by the buyer for the Product.

In no event shall KMDSI be liable to the buyer for indi-

rect, special, incidental or consequential damages (includ-

ing, but not limited to, damages for lost prots, lost sales,

loss of business opportunity, or for injury to persons or

property arising out of the use of the Product). Any claim

or action for breach of warranty must be commenced with-

in one year following delivery of the Product to the buyer.

Buyer acknowledges that this warranty is the sole and

exclusive warranty of the Product and that it supersedes

any and all oral or written representations and undertak-

ings between KMDSI, its dealers, and the buyer relat-

ing to the Products. This warranty allocates the risks of

product failure between KMDSI and the buyer, which

allocation is recognized by both parties and is reected in

the price of the goods. The buyer acknowledges that it has

read this agreement, understands it, and is bound by its

terms.

BWARNING

Diving with compressed breathing gas is a hazardous

activity. Even if you do everything in the proper manner

there is always the potential for serious injury or death.

No one piece of diving equipment can prevent the possi-

bility that you may be injured or killed any time you enter

the water. The information in this manual is intended for

users of Kirby Morgan helmets and persons that maintain

or service Kirby Morgan helmets.

Table of Contents

2 Warranty Information

7 Denitions of Signal Words Used in this Guide

7 Product Changes

10 Cold Water Diving

11 CR Marking

11 CE Certication

12 Notied Body

12 2nd Stage Regulator Serial Number Location

13 1st Stage SCUBA Regulator and 2nd Stage

Regulator Maximum Work Pressure

13 Divers Work Rate Expressed as Respiratory Minute

Volume (RMV)*

13 Regulator Transport and Storage

15 References to EN250 - Object, Denitions, Limits

15 SCUBA-Minimum equipment (EN 250):

16 Denitions (EN 250)

16 Kirby Morgan Balanced SCUBA Regulator

Assembly

17 General Precautions and Warnings

Table of Contents

18 Preparation and Setup

18 Mounting the First Stage Onto the Cylinder Valve

(Yoke Connector)

19 Balance Purge Tube and Regulator Installation

24 Pull Test After Initial Assembly

25 Pre-Dive Checkout

25 Inspection Checklist

26 During the Dive

27 After the Dive

27 Removal of the Regulator Assembly from the

Cylinder Valve

28 Safety Precautions

28 Specications

29 Routine Maintenance

29 Daily Pre-Dive Maintenance

30 Post Dive Maintenance

31 Scheduled Maintenance

33 SuperFlow®First Stage Regulator

P/N 305-161

34 Balanced SCUBA Regulator Assembly

Denitions of Signal Words Used in this Guide

Denitions of Signal Words Used in this Guide

The original language of the Kirby Morgan Manuals is English.

Translation into other languages will be provided upon request.

KMDSI may charge a fee for these services.

BCAUTION

This word indicates a potentially hazardous situ-

ation, which if not avoided, may result in minor or

moderate injury. It may also be used to alert against

unsafe practices.

BWARNING

This word indicates a potentially hazardous situation,

which, if not avoided, could result in death or serious in-

jury.

REMARKS: Operating or descriptive information which

will help you make the best use of your regulator.

This user guide contains important safety information and should

always be available to those personnel using this equipment.

Read, understand, and retain all instructions before using this

equipment to prevent injury or equipment damage.

If you sell or loan this equipment to another person, be sure that

this manual accompanies the gear when you transfer possession

to them.

Product Changes

Following publication of this booklet, certain changes in standard

equipment, options, prices and the like may have occurred which

would not be included in these pages. Your Authorized KMDSI

dealer is your best source for up-to-date information on any of

these products. Kirby Morgan Dive Systems Inc. reserves the

right to change product specications at any time without incur-

ring obligations.

Product Changes

In order to use this regulator assembly, it is essential to complete

a training course and receive certication, issued by a recognized

national SCUBA training organization, conrming your ability

to dive.

BCAUTION

By using this equipment the diver acknowledges

that he has read and completely understands the

instruction manual provided with it, and hereby

agrees to hold harmless Kirby Morgan Dive Sys-

tems, inc. from any accident, malfunction, or other

event arising from the misuse of the equipment, or

from any lack of, or incomplete understanding of its

operation and function.

BCAUTION

This regulator assembly should be used only with

breathing air meeting requirements of the EN12021

BCAUTION

When the regulator is used in a European Union

member country, it should be used only with equip-

ment and accessories that are CE approved, ac-

cording to EN250.

BWARNING

•

The rst stage SCUBA regulator has not been

designed or tested for use with breathing gas

mixtures containing greater than 23% oxygen.

Do not use the rst stage or the regulator as-

sembly with second stage with breathing gases

containing more than 23% oxygen. Use with gas

mixtures containing in excess of 23% oxygen

could lead to res or explosions.

Product Changes

BWARNING

•

The second stage SCUBA regulator has not

been designed or tested for use with breathing

gas mixtures containing greater than 50% oxy-

gen.

Do not use the second stage with breathing

gases containing more than 50% oxygen. Use

with gas mixtures containing in excess of 50%

oxygen could lead to res or explosions.

BWARNING

In accordance with the EN250 Standard, the maximum

approved depth for the use of this equipment is 50 meters

(164 FSW) @ 62.5 RMV (heavy work load). Do not exceed

this limit. The use of open circuit SCUBA at depths below

164 FSW poses extreme risks including out-of-air emer-

gencies and decompression sickness, which can lead to

serious personal injury or death.

BWARNING

Never use solvents or aerosol sprays on our

around the regulator assembly. Certain solvents

and propulsion agents attack and damage rub-

ber and certain plastics. This could lead to regu-

lator failure. Drowning could result.

This user guide gives basic daily operational information for the

Kirby Morgan Balanced SCUBA Regulator assembly.

Before each use the regulator assembly should be carefully

checked and submitted to the operational tests. Never dive with

a regulator showing any signs of deterioration or a below normal

performance.

The hoses tted to the regulator assembly, and supplied by

KMDSI meet the requirements of the EN250 standard concerning

the connection of components. Only original Kirby Morgan hoses

should be used as replacements.

Cold Water Diving

- HP thread 7/16" - 20 UNF

- LP thread ⅜" - 24 UNF

BCAUTION

Always allow pressure to build up slowly in the

regulator by turning on the cylinder valve slowly.

Use only Christo-Lube®on the rubber components. Never grease

the parts of your regulator with a lubricant containing hydrocar-

bons, household oil, or motor oil.

Cold Water Diving

Before diving in cold water (water temperature below 10 °C/50 °F),

the diver should be trained and have mastered the techniques of

cold water diving, learning techniques and all precautions neces-

sary to avoid freezing of the regulator. All of this is included in the

training programs of organizations offering courses in diving in

cold water or under ice. You should also use equipment intended

for this purpose. This regulator is CE approved for waters colder

than 10°C /50 degrees F.

In order to reduce the risks of regulator freezing when diving in

cold water (below 10°C), consider doing the following:

1. Protect your regulators from any water entering the rst or

second stages.

2. Protect your equipment from cold before the dive. Keep your

regulator and all its accessories in a warm dry place.

3. Carry out all pre-dive checks of your equipment in a warm dry

place if necessary, before even going to the dive site.

4. Avoid breathing through the regulator or pressing the purge

button in very cold air before entering the water.

5. Check that the air used to ll your cylinder is dry. The water

vapor contained in this air should have a condensation point

below -54°C. Excess water vapor can freeze, causing a free

ow, or blocking the air ow completely.
