Kingston Technology KTM609 Manuel utilisateur

Kingston Technology

KTM609/16

Memory Expansion

for IBM PS/2 Model 50,

50z, 55sx, 60, and 65sx

KTM-609/16 Installation Guide - Rev. D1 Kingston Technology Corporation

KTM-609/16

Memory Expansion Board

for

IBM PS/2 Models

50, 50z, 55sx, 60, and 65sx

Installation Guide

Kingston Technology Corporation

17600 Newhope Street

Fountain Valley, CA 92708

Phone (714) 435-2600

ii Preface

Kingston Technology Corporation KTM-609/16 Installation Guide - Rev. D1

Limited Warranty

KINGSTON TECHNOLOGY CORPORATION (hereinafter called KTC) warrants

that this product is free from defective material and workmanship and, subject to the

conditions set forth below, agrees to repair or replace any part of this product which

proves defective by reason of improper workmanship or materials for a period of five

years from the date of original retail purchase, without charge for parts and labor.

If this product does not perform as warranted herein, owners sole remedy shall be

repair or replacement as provided below. In no event will KTC be liable for damages,

lost revenue, lost wages, lost savings or any other incidental or consequential damages

arising from purchase, use, or inability to use this product, even if KTC has been

advised of the possibility of such damages.

Any defective product should be returned to your local dealer or distributor, along

with a copy of your sales slip, product serial number and a detailed description of the

problem you are experiencing.

No express or implied warranty is made for any KTC product damaged by accidents,

abuse, misuse, natural or personal disaster or unauthorized modification.

All trademarks are property of their respective companies.

Preface iii

KTM-609/16 Installation Guide - Rev. D1 Kingston Technology Corporation

TABLE OF CONTENTS

Introduction........................................................................................................................... 1

General Description.............................................................................................................. 2

Package Contents ................................................................................................................ 4

Packaging Materials .............................................................................................................4

Order Information ................................................................................................................. 4

Before You Begin .................................................................................................................5

Software Installation ............................................................................................................. 6

Installation Overview................................................................................................6

Updating Your Backup Copy of the Reference Diskette............................................6

Running the INSTALL Program................................................................................7

Hardware Installation............................................................................................................9

Installing the SIMM Modules ....................................................................................9

Installing the KTM-609/16 Board ............................................................................ 12

Configuring the System....................................................................................................... 13

Installing the Kingston EMS Driver ......................................................................... 16

Changing Existing EMS Driver Parameters ............................................................ 20

Changing the System Configuration ....................................................................... 23

Adding or Removing SIMMs ...................................................................... 23

Changing the Amount of Expanded Memory.............................................. 24

iv Preface

Kingston Technology Corporation KTM-609/16 Installation Guide - Rev. D1

Appendices.........................................................................................................................26

Appendix A Extended vs. Expanded Memory.......................................................27

Some History .............................................................................................27

Extended (Linear) Memory.........................................................................27

Expanded (Paged) Memory........................................................................28

Appendix B Modifying CONFIG.SYS ...................................................................29

Installing the Driver ....................................................................................29

Testing the Kingston EMS Driver................................................................30

Command Line Options..............................................................................30

Appendix C Troubleshooting................................................................................32

Error Messages..........................................................................................32

Working With QEMM 50/60 Memory Manager............................................36

List of Figures

Figure 1: KTM-609/16 Board (Type I) .......................................................................2

Figure 2: KTM-609/16 Board (Type II) ......................................................................3

Figure 3: KTM-609/16 Board (Type III) .....................................................................3

Figure 4: Installing the SIMM Modules....................................................................11

Figure A-1: Extended and Expanded Memory Configuration ...................................26

General Information 1

KTM-609/16 Installation Guide - Rev. D1 Kingston Technology Corporation

Introduction

Kingston Technology welcomes you to the growing family of IBM PS/2 users who

have chosen Kingston Memory Expansion options for their computers. As application

programs expand in size and complexity, the need for efficient and reliable memory

expansion becomes critical. Our aim is to provide you with high quality memory

expansion products that give maximum performance benefits at an affordable cost.

We have engineered our memory products to be durable, reliable, and trouble-free;

and we are confident that you will receive optimum performance from this Kingston

product for many years to come.

The information in this manual will guide you through the process of placing the

memory modules on the circuit board, installing the circuit board inside your

computer, and configuring the necessary software to recognize the new memory.

Please take a few moments to read through this manual now and familiarize yourself

with the procedures you will need to follow when you install the Kingston board and

software. This can save you a lot of anxiety later on.

We have tried to anticipate many of the problems that may arise during the

installation, and most of your questions will be answered by reading this manual.

However, if you encounter a situation that you cannot resolve, or have questions

regarding the installation or use of this product, please call Kingston Technical

Support at (714) 435-2639. Our main goal is customer satisfaction.

2General Information

Kingston Technology Corporation KTM-609/16 Installation Guide - Rev. D1

General Description

The Kingston Technology KTM-609/16 Memory Expansion Board is capable of

adding up to 16MB of Random Access Memory to IBM PS/2 Models 50, 50z, 55sx,

60, and 65sx personal computer systems. There are three models of the KTM609/16:

Type I has four SIMM sockets with no memory soldered directly to the board; Type II

has 4MB soldered and three sockets for expansion; and Type III has 8MB soldered

with two sockets available. Single In-line Memory Modules (SIMMs) can be plugged

into the SIMM sockets on the KTM-609/16 board, and can be combined in a wide

variety of memory configurations. The KTM-609/16 board can be installed in any 16-

bit expansion slot on the PS/2 system board.

The KTM-609/16 Memory Expansion Board (shown in Figures 1, 2, and 3) support

both Extended (linear) memory and Expanded (paged) memory. It adheres to the

Lotus/Intel/Microsoft Expanded Memory Specification (LIM) version 4.0 software to

enable memory paging. EMS 4.0 is compatible with applications written for EMS 3.2

and Enhanced Expanded Memory Specification (EMMS). Use Extended memory for

today's latest software to run under Microsoft Windows®and IBM OS/2®.

Figure 1: KTM609/16 Type I - 0MB soldered, 4 SIMM Sockets

General Information 3

KTM-609/16 Installation Guide - Rev. D1 Kingston Technology Corporation

Figure 2: KTM609/16 Type II - 4MB soldered, 3 SIMM Sockets

Figure 3: KTM609/16 Type III - 8MB soldered, 2 SIMM Sockets

4General Information

Kingston Technology Corporation KTM-609/16 Installation Guide - Rev. D1

Package Contents

In addition to this manual, you should also receive the following items:

•One KTM-609/16 Memory Expansion Board

•One or more Single In-line Memory Modules (SIMMs), if applicable.

•One Kingston Option Diskette

If any item is missing or damaged, contact the Kingston dealer or distributor from

whom you purchased this upgrade.

Packaging Materials

Kingston memory boards are shipped in an anti-static plastic bag, inside a cushioned

box, which protects them from shock and static electricity that could cause severe

damage to the memory chips. Before you remove any memory component from its

packaging, be sure you discharge any static electricity by touching a securely

grounded metal object. Also, keep magnetized tools, such as magnetic screwdrivers,

away from the board and memory modules.

Order Information

Kingston Part # IBM Part # Description

KTM-1000/M70 6450603 1MB SIMM

KTM-2000/M70 6450604 2MB SIMM

KTM-4000/M70 34F2933 4MB SIMM

KTM-609/16 6450609 16MB Memory Board

General Information 5

KTM-609/16 Installation Guide - Rev. D1 Kingston Technology Corporation

Before You Begin

Read through this manual before you begin installing the KTM-609/16 board, so

you’ll know what to expect as you go along. Although this is a relatively easy

installation, you may feel more comfortable asking your local Kingston dealer or

computer service center to do it for you. There will undoubtedly be a fee associated

with doing this, but your peace of mind may be worth the cost.

Pay special attention to Appendix A, “Extended vs. Expanded Memory.” If your

computer uses DOS, you will have to decide how much of your added Kingston

memory to allocate as Extended (linear) memory, and how much to allocate as

Expanded (paged) memory. If your computer uses Windows or OS/2, all added

memory should be allocated as Extended since Windows and OS/2 can address all

added memory directly. Also, if your PS/2 has a 386SX microprocessor or higher, it is

best to allocated all added memory as Extended. If Expanded memory is required, use

a 386-level Expanded Memory Manager, such as DOS's EMM386.EXE, located in

your DOS or WINDOWS directory with the RAM switch. Consult your DOS manual

for details.

Besides the contents of the KTM-609/16 memory upgrade package described earlier,

you will also need to prepare a backup copy of your IBM PS/2 Reference Diskette.

(Follow the instructions in the IBM PS/2 Quick Reference Manual to make the back

up copy if you don’t already have one.) You will also need a flat-tip, non-magnetic

screwdriver for the installation process.

Allow plenty of time for the installation and configuration process. It should take very

little time, but if you rush yourself, errors and set-backs are more likely to occur. We

want this process to go smoothly for you, so have patience and use caution.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Kingston Technology Stockage

Kingston Technology

Kingston Technology DataTraveler 2000 Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler Vault-Privacy Manuel utilisateur

Kingston Technology

Kingston Technology IronKey Vault Privacy 80 Manuel utilisateur

Kingston Technology

Kingston Technology Ironkey D300 Manuel utilisateur

Kingston Technology

Kingston Technology SSDNow M-series Manuel utilisateur

Kingston Technology

Kingston Technology Locker+ Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler Bolt Duo Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler DT400 Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler 6000 Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler SE9 Manuel utilisateur

Kingston Technology

Kingston Technology 100 G2 Manuel utilisateur

Kingston Technology

Kingston Technology DT111 Manuel utilisateur

Kingston Technology

Kingston Technology Wi-Drive 16GB Manuel utilisateur

Kingston Technology

Kingston Technology KTM8000/386 Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler II Plus Migo Edition Manuel utilisateur

Kingston Technology

Kingston Technology MyTraveler Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler Bolt Duo Manuel utilisateur

Kingston Technology

Kingston Technology IRONKEY D300SM Manuel utilisateur

Kingston Technology

Kingston Technology Flash Memory Manuel utilisateur

Kingston Technology

Kingston Technology DataTraveler 4000 Manuel utilisateur

Kingston Technology

Kingston Technology Wi-Drive Manuel utilisateur

Kingston Technology

Kingston Technology SSDNow 07-16-2009 Manuel utilisateur

Kingston Technology

Kingston Technology Wi-Drive Manuel utilisateur

Kingston Technology

Kingston Technology SD10V/8GB Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
