KinAn RHD108 Manuel utilisateur

HDMI KVM Switch

（

8 Port / 16 Port

）

User Manual

www.kinankvm.com/

Printing date：2019/08

Version：V1.0

8 Port /16 Port User Manual

- 1 -

Overview

Descriptions

HDMI switch is a control device which controls multiple computers from

a single console (keyboard, video and mouse). It is easy and fast to

install the KVM switch, you just need to connect corresponding cables

to the right ports of the KVM. Since the KVM directly get the signal input

from the keyboard and mouse, there is no software setup or other

complex installation, so no worry about compatibility.

Features

Control 8 / 16 pcs HDMI computers from a single console

Fit for standard 19” rack mounting

Fully complied with HDCP

Support HDMI1.4a

Multi-platform Support-Compatible with Windows, Sun, Unix and

Linux

Support wireless keyboard and mouse from different suppliers

Convenientcomputerswitchingvia frontpanelpushbuttons,hotkeys,

or mouse

Complete keyboard & mouse emulation for error-free booting.

Auto scan feature for monitoring user-selected computers

Broadcast mode –operations simultaneously performed on all

selected computers

Support hot-plugging

8 Port /16 Port User Manual

- 2 -

Hardware Installation

Rack Mounting

Make sure all the computers and external device are shut down before

installation.

Put the KVM switch in place, screw the brackets to the two sides of the

KVM to install the KVM in the standard 19”rack.Pay attention to the cable

length, to keep a certain distance between the KVM and the computer.

Bear bracket

Appearance

8 Port /16 Port User Manual

- 3 -

Rear View

Installation Diagram

Make sure the KVM has been connected to the ground(①)

Connect the power adapter to KVM(②)

Connect Screen, keyboard, mouse to local CONSOLE(③)

Connect PC and KVM with HDMI cable, USB adapter cable (④)

Power on the pc and switch to start to use it

1.2 Installation Diagram

No.

Instruction

Grounded Screw

Power adapter socket

Console HDMI port

Console USB port ( keyboard, Mouse)

KVM Port

8 Port /16 Port User Manual

- 4 -

LED Instructions

1.3 KVM front view

Table 1.2：

Mouse Switching

Single click Scroll button and Left-click button to switch to previous

port(↑)

Single click Scroll button and Right-click button to switch to next port(↓)

Scroll + Right:

to next port

Left Right

Scroll + Left:

to previous port

No.

Components

Function

1-8 or 1-16

1)Switching freely from port 1 to port 8/16

Port Selection

Buttons& LEDs

1）An online LED light(orange) indicates

that the KVM has connected to its

corresponding computer and power on.

2）A selected LED light(green) indicates

that the computer attached to its

corresponding port is up and running.

Port ID

It shows the current Port

8 Port /16 Port User Manual

- 5 -

Hotkey Operation

Double click【Scroll Lock】(in 2 seconds) , when you heard the beep

sound, you are in hotkey mode. If there are no any operations in Hotkey

Mode in 2 second, keyboard out hotkey mouse.

Hotkey commands are as follows：

Double click【Scroll Lock】+ the corresponding function key

Operating

Function description

【Scroll-Lock】+【Scroll-Lock】

+【1~8】

Switch from port 1- 8

【Scroll-Lock】+【Scroll-Lock】

+【F1-F8】

Switch from port 9 –16

【Scroll-Lock】+【Scroll-Lock】

+【↑ / ↓】

Switch to previous or next port

【Scroll-Lock】+【Scroll-Lock】

+【S】

Scan all ports automatically (default interval:

5s)

1. Press【+】add 5s (Max: 30S)

2. Press【-】reduce 5s (Min: 5S)

3. Move mouse to extend the scan time

4. Press【Esc】to exit auto scan

【Scroll-Lock】+【Scroll-Lock】

+【Z】

On/Off Beeper

【Scroll-Lock】+【Scroll-Lock】

+【M】

On/Off mouse switch function

【Scroll-Lock】+【Scroll-Lock】

+【B】

Under broadcast mode, the computer

keyboard and mouse can be operated

synchronously.

【Scroll-Lock】+【Scroll-Lock】

+【F】

Default hotkey mode:【Scroll Lock】

Hotkey cycling mode:

【L_Ctrl】--> 【Caps Lock】-->

【F12】-->【Scroll Lock】

【Scroll-Lock】+【Scroll-Lock】

+【R】

Restore to the original factory setting

8 Port /16 Port User Manual

- 6 -

Specification

Mode

RHD108

RHD116

Direct Computer Connection

Max Computer Connection

Port Selection

Pushbutton, Hotkey

Connector

Console

Monitor

Keyboard

Mouse

1x HDMI Type A

2x USB type A

KVM

8x HDMI Type A

8x USB Type B

16x HDMI Type A

16x USB Type B

Switch

Port Selection

8x buttons

16x buttons

LEDs

Online

8 (orange)

16 (orange)

Selected

8 (green)

16 (green)

Port Display

2*7- Segment (orange)

I/R Value

DC12V/2A

Resolution

1920x1080@60Hz

Consumption

Emulation

Keyboard/Mouse

PS/2, USB

Environment

Operating

0-40℃

Storage

-20-60℃

Humidity

0-80%RH,Non-condensing

Physical

Features

Material

Metal

Weight

2.0kg

2.2kg

Dimension

440x169x43mm
