Kicker PSC57 Manuel utilisateur

PSC57

Coaxial Speaker

Altavoz coaxial

Haut-parleur coaxial

Koaxiallautsprecher

Installation Manual

Manual de Instalación

Manuel d’installation

Benutzerhandbuch

Contents

Disassembly................... 3

Installation ...................... 5

Warranty ........................ 8

Important: Over-tightening mounting

fasteners may result in damage to your

motorcycle. Please refer to your

service manual for proper procedures

and torque speciﬁcations. KICKER is not

responsible for damage resulting from

improper installation techniques.

Light Kit

Delete Plugs

Disassembly

1. Before you begin, make sure the

motorcycle and radio are in the OFF

position.

2. From inside the saddlebag, remove the

four grille retaining screws, or remove the

grille from the saddlebag according to the

manufacturer’s guidelines.

3. Disconnect the speaker leads from the

speaker to be replaced. If equipped with

Harley-Davidson Plugs, unplug them from

the speaker.

4. Remove the speaker to be replaced

by removing the four mounting screws

securing it to the bag lid. Remove the

speaker.

Installation

5. From inside the saddlebag, feed the

speaker leads into the top of the saddlebag

speaker cavity to the positive and negative

terminals of the PSC57, or simply connect

the Harley-Davidson Plugs if available.

6. Install and mount the PSC57 speaker

with the four screws removed in Step

4. Make sure the tweeter and speaker

are oriented towards the front of the

motorcycle.

7. Replace the grille and reinstall using the

grille retainer screws removed in Step 2, or

as necessary for your make and model of

motorcycle.

Optionally, you may replace the HD logo on

the grille with the KICKER logo. Now enjoy

your new coaxial speaker upgrade!

Warranty

When purchased from an Authorized KICKER Dealer, KICKER

warrants this product to be free from defects in material and

workmanship under normal use for a period of TWO (2) YEARS from

date of original purchase with receipt. If this product is identiﬁed as

“Refurbished” or “B Goods”, the warranty is limited to a period of

THREE (3) MONTHS from the date of original purchase. In all cases

you must have the original receipt. Should service be necessary

under this warranty for any reason due to manufacturing defect

or malfunction during the warranty period, KICKER will repair or

replace (at its discretion) the defective merchandise with equivalent

merchandise. Warranty replacements may have cosmetic scratches

and blemishes. Discontinued products may be replaced with more

current equivalent products. This warranty is valid only for the original

purchaser and is not extended to owners of the product subsequent

to the original purchaser. Any applicable implied warranties are limited

in duration to a period of the express warranty as provided herein

beginning with the date of the original purchase at retail, and no

warranties, whether express or implied, shall apply to this product

thereafter. Some states do not allow limitations on implied warranties;

therefore, these exclusions may not apply to you. This warranty gives

you speciﬁc legal rights; however you may have other rights that vary

from state to state.

WHAT TO DO IF YOU NEED WARRANTY OR SERVICE:

Defective merchandise should be returned to your local Authorized

Stillwater Designs (KICKER) Dealer for warranty service. Assistance

in locating an Authorized Dealer can be found at www.KICKER.com

or by contacting Stillwater Designs directly. You can conﬁrm that

a dealer is authorized by asking to see a current authorized dealer

window decal.

If it becomes necessary for you to return defective merchandise

directly to Stillwater Designs (KICKER), call the KICKER Customer

Service Department at (405) 624-8510 for a Return Merchandise

Authorization (RMA) number. Package only the defective items in a

package that will prevent shipping damage, and return to:

Stillwater Designs

3100 North Husband St

Stillwater, OK 74075

The RMA number must be clearly marked on the outside of the

package. Please return only defective components. The return

of functioning items increases your return freight charges. Non-

defective items will be returned freight collect to you. For example,

if a subwoofer is defective, only return the defective subwoofer, not

the entire enclosure. Include a copy of the original receipt with the

purchase date clearly visible, and a “proof-of-purchase” statement

listing the Customer’s name, Dealer’s name and invoice number, and

product purchased. Warranty expiration on items without proof-of-

purchase will be determined from the type of sale and manufacturing

date code. Freight must be prepaid; items sent freight-collect, or

COD, will be refused.

WHAT IS NOT COVERED?

This warranty is valid only if the product is used for the purpose for

which it was designed. It does not cover:

o Damage due to improper installation

o Subsequent damage to other components

o Damage caused by exposure to moisture, excessive heat,

chemical cleaners, and/or UV radiation

o Damage through negligence, misuse, accident or abuse. Repeated

returns for the same damage may be considered abuse

o Any cost or expense related to the removal or reinstallation of

product

o Speakers damaged due to ampliﬁer clipping or distortion

o Items previously repaired or modiﬁed by any unauthorized repair

facility

o Return shipping on non-defective items

o Products with tampered or missing barcode labels

o Products with tampered or missing serial numbers

o Products returned without a Return Merchandise Authorization

(RMA) number

o Products purchased from an UNAUTHORIZED dealer

o Freight Damage

o The cost of shipping product to KICKER

o Service performed by anyone other than KICKER

HOW LONG WILL IT TAKE?

KICKER strives to maintain a goal of one-week service for all

acoustics (subwoofers, midrange drivers, tweeters, crossovers, etc)

returns. Delays may be incurred if lack of replacement inventory or

parts is encountered. Failure to follow these steps may void your

warranty. Any questions can be directed to the KICKER Customer

Service Department at (405) 624-8510. Contact your International

KICKER dealer or distributor concerning speciﬁc procedures for your

country’s warranty policies.

stillwaterdesigns

P.O. Box 459

Stillwater, Oklahoma 74076

USA

(405) 624–8510

Garantía | Garantie

Contact your International KICKER dealer or distributor concerning speciﬁc procedures for your

country’s warranty policies.

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced

if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

GARANTÍA INTERNACIONAL Versión Español

Comuníquese con su concesionario o distribuidor KICKER internacional para obtener infor ación

sobre procedimientos especíﬁcos relacionados con las normas de garantía de su país.

La frase “combustible para vivir la vida Livin’ Loud™ a todo volumen” se reﬁere al entusiasmo por la

vida que la marca KICKER de estéreos de automóvil representa y a la recomendación a nuestros

clientes de que vivan lo mejor posible (“a todo volumen”) en todo sentido. La línea de altavoces y

ampliﬁcadores KICKER es la mejor del mercado de audio de automóviles y por lo tanto representa el

“combustible” para vivir a todo volumen en el área de “estéreos de automóvil” de la vida de nuestros

clientes. Recomendamos a todos nuestros clientes que obedezcan todas las reglas y reglamentos

locales sobre ruido en cuanto a los niveles legales y apropiados de audición fuera del vehículo.

INTERNATIONALE GARANTIE Deutsche Version

Nehmen Sie mit Ihren internationalen KICKER-Fachhändler oder Vertrieb Kontakt auf, um Details über

die Garantieleistungen in Ihrem Land zu erfahren.

Der Slogan “Treibstoff für Livin’ Loud” bezieht sich auf die mit den KICKER-Autostereosystemen

assoziierte Lebensfreude und die Tatsache, dass wir unsere Kunden ermutigen, in allen Aspekten

ihres Lebens nach dem Besten (“Livin’ Loud”) zu streben. Die Lautsprecher und Verstärker von

KICKER sind auf dem Markt für Auto-Soundsysteme führend und stellen somit den “Treibstoff” für

das Autostereoerlebnis unserer Kunden dar. Wir empfehlen allen unseren Kunden, sich bezüglich der

zugelassenen und passenden Lautstärkepegel außerhalb des Autos an die örtlichen Lärmvorschriften

zu halten.

GARANTIE INTERNATIONALE Version Française

Pour connaître les procédures propres à la politique de garantie de votre pays, contactez votre

revendeur ou distributeur International KICKER.

L’expression “ carburant pour vivre plein pot “ fait référence au dynamisme de la marque KICKER

d’équipements audio pour véhicules et a pour but d’encourager nos clients à faire le maximum

(“ vivre plein pot “) dans tous les aspects de leur vie. Les haut-parleurs et ampliﬁcateurs KICKER

sont les meilleurs dans le domaine des équipements audio et représentent donc pour nos client

le “ carburant pour vivre plein pot “ dans l’aspect “ installation audio de véhicule “ de leur vie. Nous

encourageons tous nos clients à respecter toutes les lois et réglementations locales relatives aux

niveaux sonores acceptables à l’extérieur des véhicules.
