24" POLA WALL FAN

INSTRUCTION MANUAL

Product images may vary slightly from actual product

KICHLER.COM

24" POLA WALL FAN | 3

TABLE OF CONTENTS

SAFETY RULES..................................................................4

TOOLS AND MATERIALS REQUIRED..................................5

PACKAGE CONTENTS........................................................5

MOUNTING BASE ON A WOOD FRAMED WALL................6

MOUNTING PIPE AND BASE ASSEMBLY..........................6

WALL MOUNT BRACKET / MOTOR ASSEMBLY...............7

MOTOR / REAR GRILLE AND BLADE ASSEMBLY...............7

FRONT GRILLE ASSEMBLY...............................................7

OPERATING INSTRUCTIONS............................................8

MAINTENANCE..............................................................8

| KICHLER.COM

SAFETY RULES

CAUTION: Read and follow all instructions before operating fan.

Do not use if any part is damaged or missing.

WARNING: To reduce the risk of fire or electrical shock, DO NOT use this fan with any solid state speed control device. This appliance

has a 3-prong grounded plug that must be inserted into a matching outlet. To reduce the risk of electrical shock, this grounding plug

must not be cut o the plug. Where a two-prong wall outlet is encountered, it must be replaced: contact a qualified electrician. DO NOT

attempt to defeat this safety feature. Use your fan only with adequate wiring that is up to code. Connect to properly grounded outlets

only.

NOTE: Installation of this equipment should be performed by a qualified person. We do not warrant any damage or injuries as a result of

improper installation.

This fan is suitable for wet location. The fan has Ground-Fault Circuit-Interrupters (GFCI) plug for protection against electrical shock ,

please press the TEST button (then RESET button) every month to assure proper operation.

RULES FOR SAFE OPERATION:

• Always unplug before cleaning.

• Always unplug unit when not in use.

• Do not place foreign objects through guard into the blade.

• Do not operate without fan guards properly locked.

• Do not use this fan with an extension cord.

• Do not place fan or any parts near an open flame, cooking or other heating appliance.

• Do not operate this unit with a damaged cord or plug, especially when this unit has been malfunctioning, dropped or damaged.

24" POLA WALL FAN | 5

TOOLS REQUIRED PACKAGE CONTENTS

• Motor Assembly

• Front/Rear Grille and Blade

• Wall Mounting Pipe and Base

• Owner’s Manual and Hardware Package

• Philips screw driver

• Blade screw driver

• 11mm wrench

• Step ladder

• Wire cutters

Unpack your fan and check the contents. You should have the

following items:

| KICHLER.COM

Mounting Base on a Wood Framed Wall

1. Locate a wall stud secure and solid enough to hold the

weight of the base assembly. Carefully locate and mark

the center of the wall stud. If you do not have a solid

structural framing member at that location then you must

provide an adequate alternative for mounting the fan.

2. Place mounting bracket (4) against the wall centered with

the centerline of the wall stud and 4 holes.

3. Drill 4 holes on the wall and secure bracket to wall using 3

lag screws (2) and spring washer (3) provided.

If mounting on a concrete wall, be sure to locate a structurally

solid and secure location to hold the weight of the fan

assembly and use suitable concrete anchors (not provided) to

mount the base to the wall.

Mounting Pipe and Base Assembly

1. Put one end of the pipe (7) into the slot of the base.

2. Carefully insert the position knob (6) and tighten it to hold

the pipe.

ASSEMBLY

24" POLA WALL FAN | 7

Wall Mount Bracket / Motor Assembly

1. Remove the 2 bolts (11), washers (10) and nuts (12) from

the wall mount / pipe (7).

2. Align the holes on the pipe with the holes in the motor

flange on the motor assembly.

3. Insert the bolts (11) and replace the washers and nuts

removed in step 1.

4. Adjust the tilt to the desired positionand tighten the pivot

knob (8) to set the angle.

5. Tighten the position bolt and nut.

CAUTION: Be sure to secure the knob.

Motor / Rear Grille and Blade Assembly

1. Remove the 4 nuts, spring washers and flat washers

(15,16,17) from the bolts around the motor shaft.

2. Carefully slide the rear grille (14) over the bolts.

3. Secure with the flat washers, spring washers, and nuts

removed in Step 1.

4. Carefully slide the blade assembly (18) over the shaft and

align the inner hex head driver (20) provided with the slot

on the shaft of the motor.

5. Tighten the blade assembly (18) with the screws using a

philips-head screwdriver (not provided).

CAUTION: Do not alter the angle of the blades.

Front Grille Assembly

1. Hang the front grille (19) on top rib of rear grille (14) by

utilizing the hook.

2. Put the decorative ring (17) into the front grille (19), then

insert the bolts (22) and tighten the nut (20) to following

interface.

3. Snap the front grille into the rear grille to secure.

4. Cover with decorative screw cover (21).

Install the mounting bracket decorative cover (1) to the

mounting bracket last.

| KICHLER.COM

OPERATING INSTRUCTIONS

1. Change the setting on the speed control to the desired

operating speed. The pull chain controls the fan speed as

follows:

• 1 pull - Low

• 2 pulls - Medium

• 3 pulls - High

• 4 pulls - O

2. To change the tilting angle of the fan head, loosen the tilt

adjustment knob on the fan head joint, tilt the fan head to

the desired angle and tighten the pivot knob.

3. To make the fan oscillate, pull up on the oscillating knob

located on the bottom of the motor housing. To stop the

fan from oscillating, push down on the oscillating knob.

CLEANING

WARNING: Unplug from electrical supply source before

cleaning. After servicing, any safety device (including grills

and blades) must be reinstalled or remounted as previously

installed. Use soft damp cloth then wipe with dry cloth.

Do not use harmful cleaners.

Do not bend the blades.

If you should have any operation questions, contact us toll free

at 1-866-558-5706.

24" POLA WALL FAN | 9

www.kichler.com

KICHLER®LIGHTING

7711 EAST PLEASANT VALLEY ROAD P.O. BOX 318010

CLEVELAND, OHIO 44131-8010

CUSTOMER SERVICE 866.558.5706

8:30 AM TO 5:00 PM EST, MONDAY - FRIDAY

VENTILADOR DE PARED POLA, 71.1 CM

MANUAL DE INSTRUCCIONES

Las imágenes del producto pueden diferir ligeramente del producto original
