Kia EV6 2022 Manuel utilisateur

Emergency

Response

Guide

Version_1

1. Identification / Recognition

2. Immobilization / Stabilization / Lifting

3. Disable Direct Hazards / Safety Regulations

4. Access to the Occupants

5. Stored Energy / Liquid / Gases / Solids

6. In Case of Fire

7. In Case of Submersion

8. Towing / Transportation / Storage

9. ImportantAdditional Information

Contents

1. Identification / Recognition

Initial Response: Identify, Immobilize and Disable

Identify

•

The EV6 is an electric vehicle. Emergency responders should respond to emergency

scenarios involving the EV6 accordingly, exercising extreme care and caution to avoid

contact with the high voltage system within the vehicle.

The following procedures should be used whenever you are dealing with a EV6 at an

emergency scene. However, all operations should be consistent with your department’s

standard operating procedures, guidelines, and any applicable laws. When an EV is

damaged in a crash, the high voltage safety systems may have been compromised and

present a potential high voltage electrical shock hazard. Exercise caution and wear

appropriate personal protective equipment (PPE) safety gear, including high voltage safety

gloves and boots. Remove all metallic jewelry, including watches and rings.

WARNING

1. Identification / Recognition

1.1 Identifying a EV6

“EV6

” Car name emblem on Tailgate

•

The EV6 can be easily identified by the car

name emblem attached on the tailgate on the

left side.

•

The car name emblem may be missing or

hidden after a crash due to damage to the

vehicle. Always be sure to utilize additional

methods of identification before determining

that the vehicle is not a electric car.

Charging Port

•

The charging port is located on the rear right side.

#Note : The doors must be un

-locked to open the charge port door.

How to open the charging port

Press the unlock door button, depress the brake pedal and apply the Electric Parking Brake

(EPB).

Turn OFF all switches, move the shift lever to P (Park) and turn off the vehicle.

Open the charging door by pressing it, or press the “charging door open button” in the crash

pad.

1. Identification / Recognition

1.1 Identifying a EV6

VIN Label

The VIN (Vehicle Identification Number) identifies

an electric car

with a “C” displayed in the

4th position, as shown in the below picture.

The VIN can be found:

1) VIN Plate also can be seen through the windshield from outside.

2) On the vehicle certification label attached to the driver’s side (or passenger) center pillar.

3) Underneath the front passenger seat (or driver seat).

XXXCXXXXXXXXXXXX

4th position (C)

1. Identification / Recognition

1.1 Identifying a EV6

The EV6 Cluster Instrument Panel displays

EV specific features such as high voltage

battery SOC (State of Charge) as below

EV6 Cluster Instrument Panel

Charge Status Indicator

The battery charge status indicator (4 lighted bars),located inside the charging door, is

illuminated when the vehicle is charged. The number of lights illuminated indicates the

charge level of the battery.

1. Speedometer

2. Distance to empty

3. Power/Charge gauge

4. Battery SOC (State of Charge)

5. LCD display

6. Warning and indicator lights

7. Reduction gear shift indicator

8. Odometer

9. Regenerative braking level indicator

10. Electric energy economy

2. Immobilization / Stabilization / Lifting

The next step is to immobilize the vehicle to prevent any accidental movement that can

endanger response personnel or civilians. When the EV6 is damaged in a crash, the vehicle

may appear to be shut off, even when it actually is not, due to a lack of engine sounds.

When the "READY" mode light is illuminated on the Instrument Panel, the vehicle can move

silently using the electric motor. Responders should approach the vehicle from the sides and

stay away from the front or rear as they are potential paths for vehicle movement. Be sure to

immobilize the vehicle in the following manner.

Chock the wheels

Set the Electronic Parking

Brake (EPB)

Put the vehicle in P (Park)

position by pressing the ‘P’

button on the rotary shifter

2.2 Vehicle Stabilization

Use standard stabilization (lift) points, as

shown beside.Always be sure to connect to a

structural component of the vehicle and avoid

placing cribbing under high voltage cables,

and other areas not normally considered

acceptable.

2.1 Immobilization

•

When installing a block or jack, avoid high voltage cable, high voltage battery.

•

If high voltage components or cables are exposed, do not place any support on them.

WARNING

Disable Direct Hazards / Safety Regulations

The final step in the initial response process, conducted after immobilizing the vehicle, is to

disable the vehicle, its SRS components and the high voltage electrical system. To prevent

current flow through the system, use one of the following procedures to disable the vehicle.

3.1 Disabling the System – Smart Key System and “POWER”

START/STOP Button

Confirm the status of the READY light on

the instrument panel. If the READY

light is illuminated, the vehicle is ON.

“POWER” START/STOP Button

a) If the READY light is NOT

illuminated, the vehicle is off. Do not

push the “POWER” START/STOP

button because the vehicle may start

(go

into READY mode).

b) To turn OFF the system, press the 'P' (Park) button on the rotary shifter dial, and

press the POWER button.

Case I

Power

Off

12V battery

disconnection

High voltage

shut off

Case II*

12V battery

disconnection

Fuse removal

(Fuse box)

High voltage

shut off

*In case of emergency

Disable Direct Hazards / Safety Regulations

2. If necessary, lower the windows, unlock the doors and open the tail gate as required,

before disconnecting the 12V battery. Once the 12V battery is disconnected, power

controls will not operate.

3. Before disconnecting the 12V battery, turn OFF ignition and remove the smart key at

least 2 meters away from the vehicle to prevent accidental restart.

4. Open the hood and front trunk (A).

While depressing the brake pedal

Pressing POWER button Vehicle condition

One time Ready to drive

Without depressing

the brake pedal

Pressing POWER

button Vehicle condition

One time Electrical accessories are operational.

Two times The warning lights can be checked before the vehicle is started.

Three times Off

5. Open the 12V battery service cover (A).

Disable Direct Hazards / Safety Regulations

6. Disconnect the 12 auxiliary battery negative (

-) terminal.

7. Pull up the yellow lever (interlock connector) to cut off the high voltage.

*The yellow lever doesn't get pulled out completely.
