KAWOTI 21017 Manuel utilisateur
USE AND CARE MANUAL
TABLE LAMP SET OF 2
Model number: 21017/21018
THIS MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Page 1 of 4
Hardware (Parts are not to scale)
H1
Finial (Pre-assembled
to harp (H2))
2 pcs
H2
Harp
2 pcs
H3
Socket assembly
(connecting to fixture
body (B))
2 pcs
B
A
IMPORTANT SAFETY INFORMATION
• This lamp is for indoor use only. The lamp should not be used near water. Never immerse the lamp in water
or other liquids.
• Never cover the lamp with any object including cloth or paper as this is a fire hazard.
• Do not handle the bulb immediately after the light is turned off as it will be hot.
• This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce
the risk of electric shock. This plug will fit into a polarized outlet only one way. If the plug does not fit fully
into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Never use with an
extension cord unless plug can be fully inserted. Do not alter the plug.
PREPARATION
• Before beginning assembly, installation or operation of product, make sure all parts are present. Compare
parts with package contents list and diagram on previous page. If any part is missing or damaged, do not
attempt to assemble, install or operate the product. Contact customer service for replacement parts.
Page 2 of 4
ASSEMBLY
1Assembling the socket assembly 2Installing the light bulb
• Pull the excess power cord through the base of
the fixture body (B).
• Tighten the socket assembly (H3) onto the fixture
body (B) securely.
NOTE: Do not twist the power cord.
• Install the light bulb (not provided) into the
socket. Use one MAX 100 W 3-way medium base
(E26) type "A" bulb (recommended).
NOTE: You can also use one MAX 16W 3-way
medium base (E26) self-ballasted LED bulb. Do
not exceed the recommended wattage.
H3
H3
B
ASSEMBLY (continued)
Page 3 of 4
3Assembling the harp
5Assembling the second lamp
4Assembling the shade
• Insert the harp (H2) prongs into the saddle of
the socket assembly (H3) and slide the retaining
covers over joints to secure the harp.
• Repeat steps 1 - 4 for the second lamp.
• Unscrew the finial (H1) from the harp (H2).
• Place the shade (A) onto the harp (H2) and
secure with the finial (H1).
• Plug into the wall outlet, turn the switch
clockwise and enjoy.
NOTE: Remove the plastic cover from the shade
before using.
H3
H3
H2
H2
H1
A
Switch knob
Page 4 of 4
CLEANING
• Do not use any cleaners with chemicals, solvents, or harsh abrasives. Use only a dry, soft cloth to dust or
wipe carefully.
• To clean the fixture, pull the plug from the wall outlet. Use a dry or slightly dampened, clean cloth to wipe
the exterior surface of the fixture.
QUESTIONS?
For customer service support and the fastest response, please email us at
customersupport@kawoti.com.
TROUBLESHOOTING
• The light does not come on at all:
a) Ensure the power supply is turned on.
b) Ensure the cord is plugged into an outlet.
c) Ensure the circuit breaker is set in the “ON” position.
• Fuse blows or circuit trips when light is turned on.
a) Check for crossed wires, ensure wiring is correct.
