D-ILA PROJECTOR

ＤＬＡ－Ｇ３０１０

ＤＬＡ－Ｇ３０１０ＤＬＡ－Ｇ３０１０

ＤＬＡ－Ｇ３０１０series

seriesseries

series

ＤＬＡ－Ｍ２０００

ＤＬＡ－Ｍ２０００ＤＬＡ－Ｍ２０００

ＤＬＡ－Ｍ２０００series

seriesseries

series

RS-232C CONTROL SPECIFICATIONS

Victor Company of Japan, Limited

* D-ILA is a trademark of Victor Company of Japan, Limited.

Document Number CTGKE-0013

CONTENTS

1. Outline .......................................................................................................................... 2

2. Communication Format.................................................................................................. 2

3. Data Format ..................................................................................................................2

4. Header .......................................................................................................................... 4

5. ID.................................................................................................................................. 4

6. CR ................................................................................................................................ 5

7. Parameters.................................................................................................................... 5

8. Tally (Response) Data ................................................................................................... 9

9. Internal Errors ............................................................................................................. 10

10 Projector Operation Modes .......................................................................................... 12

11. Source ........................................................................................................................ 13

12. Commands .................................................................................................................. 14

13. Appendix ..................................................................................................................... 55

１．

１．１．

１．

OUTLINE

This document describes the communication and data formats used to control the projector via

its RS-232C port.

２．

２．２．

２．

COMMUNICATION FORMAT

Transfer Rate : 9600, 19200(default) bps

DataLength : 8bits

ParityBit : None

StartBit : 1bit

Flow Control : None

３．

３．３．

３．

DATA FORMAT

3.1 Command Data Format (External Control to Projector)

Header ID SP Command SP Parameter SP Parameter SP ・・ CR

Header ：Indicates the beginning of data and data type

‘!’(21H) ：Command for the Projector

‘?’(3FH) ：Query to the Projector (Request for data)

ID ：Identification number of Projector

SP ：Indicates the separation between ID and command, command and parameter,

parameter and parameter(20H)

CR ：Indicates the end of data(0DH)

3.2 Tally (Response) Data Format (Projector to External Control)

3.2.1 Tally (Response) Data when Terminated Normally

Header ID SP Normal Termination Status SP Parameter SP Parameter ・・ CR

Header : Indicates the beginning of tally (response) data

‘@’(40H)

ID ：Identification number of the Projector

SP ：Indicates the separation between ID and status, status and parameter,

parameter and parameter(20H)

Normal Termination ：‘0’(30H)

Status

CR ：Indicates the end of data(0DH)

* Parameter is sent when tally (response) data is issued in response to a query (request for data.) There is

no parameter for tally (response) data in response to a command.

3.2.2 Tally Data when Error Occurs

Header ID SP ErrorStatus CR

Header ：Indicates the beginning of the tally (response) data

‘@’(40H)

ID ：Identification number of Projector

SP ：Indicates the separation between ID and Status(20H)

Error ：‘A00’ (41H 30H 30H)

Status ‘A01’ (41H 30H 31H)

‘A02’ (41H 30H 32H)

‘A03’ (41H 30H 33H)

‘A04’ (41H 30H 34H)

‘A05’ (41H 30H 35H)

‘A0A’ (41H 30H 41H)

‘A0B’ (41H 30H 42H)

CR ：Indicates the end of the data(0DH)

*For details on error status, refer to 8. Tally (Response) Data.

3.3 Internal Error Data Format (Projector to External Control)

Header ID SP InternalErrorStatus SP Parameter SP Parameter SP ・・ CR

Header ：Indicates the beginning of the internal error data

‘＆’(26H)

ID ：Identification of Projector

SP ：Indicates the separation between ID and status, status and parameter,

parameter and parameter(20H)

Internal Error ：‘E01’ (45H 30H 31H)

Status ‘E02’ (45H 30H 32H)

‘E03’ (45H 30H 33H)

‘E04’ (45H 30H 34H)

‘E06’ (45H 30H 36H)

‘E07’ (45H 30H 37H)

‘E08’ (45H 30H 38H)

‘E09’ (45H 30H 39H)

‘E0B’ (45H 30H 42H)

‘E0C’ (45H 30H 43H)

‘E11’ (45H 31H 31H)

‘E12’ (45H 31H 32H)

‘E20’ (45H 32H 30H)

CR ：Indicates the end of the data(0DH)

* For details on internal error status, refer to 9. Internal Errors.

４．

４．４．

４．HEADER

Indicates the beginning and type of communication data.

4.1 External Control to Projector

Character HEX Definition

‘!’ 21 Command to the Projector

‘?’ 3F Query (request for information) to the Projector

4.2 Projector to External Control

Character HEX Definition

‘@’ 40 Tally (Response) data

‘&’ 26 Internal error data

5. ID

Numeric characters are used to identify an individual Projector when two or more Projector units are

connected to a single control machine.

Setting separate identification numbers for each Projector allows independent control of each

Projector unit.

# Assignable ID numbers

‘0’(30H) ‘8’(38H)

‘1’(31H) ‘9’(39H)

‘2’(32H) ‘A’(41H)

‘3’(33H) ‘B’(42H)

‘4’(34H) ‘C’(43H)

‘5’(35H) ‘D’(44H)

‘6’(36H) ‘E’(45H)

‘7’(37H) ‘F’(46H)

* Factory set ID is ‘1’ (31H).

ID number ‘0’ (30H) should be used when assigning all connected Projector units for batch operations.

This means that when assigning independent ID numbers to multiple units, 15 of the 16 assignable

numbers (from ‘1’ through ‘F’) can actually be used for registration.

Please note that tally (response) data is not returned from the projector when the global ID assignment

function (0) is used.

6. CR

Indicates the end of each set of data. (0DH)

7. PARAMETERS

There are three types of parameters:

1.Indicates the numeric value.

2.Indicates the ON/OFF status.

3.Special parameter.

7.1 Numeric Value Parameter

Signed 2-byte hexadecimal code represented by 4 (byte) characters.

Assignable range is between ‘8000’ and ‘7FFF’.

Ex-1) The parameter indicating ‘20’ (decimal):

Since ‘20’ (decimal) is represented as ‘0014’ in signed 2-byte hexadecimal,

its parameter is:

‘0014’(30H 30H 31H 34H)

Ex-2) The parameter to indicate ‘-2’ (decimal):

Since ‘-2’ (decimal) is represented as ‘FFFE’ in signed 2-byte hexadecimal,

its parameter is:

‘FFFE’(46H 46H 46H 45H)

7.2 ON/OFF Status Parameter

IndicatestheON/OFFstatusofitemssuchasPOWERorHIDE.

Character HEX Definition

‘0’ 30 OFF

‘1’ 31 ON

7.3 Special Parameters

Parameters other than those described in 7.1 to 7.2.

7.3.1 Menu Display Auto OFF Parameter

Character HEX Definition

‘0’ 30 NO

‘1’ 31 YES

7.3.2 Transfer Rate Parameter

Character HEX Definition

‘0’ 30 9600bps

‘1’ 31 19200bps

7.3.3 Decoder Parameter

Character HEX Definition

‘0’ 30 NTSC

‘1’ 31 NTSC4.43

‘2’ 32 PAL

‘3’ 33 SECAM

‘4’ 34 AUTO

7.3.4 Color Temperature Parameter

Character HEX Definition

‘0’ 30 LOW

‘1’ 31 MIDDLE

‘2’ 32 HIGH

7.3.5 Input Select Parameter

Character HEX Definition

‘0’ 30 Y／C

‘1’ 31 VIDEO

‘3’ 33 D-SUB

‘4’ 34 BNC

7.3.6 Projector Operation Mode Parameter

Character HEX Definition

‘0000’ 30H 30H 30H 30H S t a n d b y M o d e

‘0001’ 30H 30H 30H 31H P o w e r O N M o d e

‘0002’ 30H 30H 30H 32H C o o l - D o w n M o d e

‘0004’ 30H 30H 30H 34H E m e r g e n c y M o d e

7.3.7 Text Mode Parameter

Character HEX Definition

‘0’ 30 Text 1

‘1’ 31 Text 2

‘2’ 32 Text 3

‘3’ 33 Text 4

‘4’ 34 Text 5

7.3.8 Aspect Parameter

Character HEX Definition

‘0’ 30 4：3

‘1’ 31 16：9

7.3.9 Resize Parameter

Character HEX Definition

‘0’ 30 1：1

‘1’ 31 Full

‘2’ 32 Aspect

7.3.10 IDParameter

Character HEX Definition

‘0’ 30 ID 0(global command for all projectors)

‘1’ 31 ID 1

‘2’ 32 ID 2

‘3’ 33 ID 3

‘4’ 34 ID 4

‘5’ 35 ID 5

‘6’ 36 ID 6

‘7’ 37 ID 7

‘8’ 38 ID 8

‘9’ 39 ID 9

‘A’ 41 ID 10

‘B’ 42 ID 11

‘C’ 43 ID 12

‘D’ 44 ID 13

‘E’ 45 ID 14

‘F’ 46 ID 15

7.3.11 SwitcherNumberParameter

Character HEX Definition

‘ 0 0 0 1 ’ 30H 30H 30H 31H Switcher No.1

‘ 0 0 0 2 ’ 30H 30H 30H 32H Switcher No.2

‘ 0 0 0 3 ’ 30H 30H 30H 33H Switcher No.3

‘ 0 0 0 4 ’ 30H 30H 30H 34H Switcher No.4

‘ 0 0 0 5 ’ 30H 30H 30H 35H Switcher No.5

‘ 0 0 0 6 ’ 30H 30H 30H 36H Switcher No.6

‘ 0 0 0 7 ’ 30H 30H 30H 37H Switcher No.7

‘ 0 0 0 8 ’ 30H 30H 30H 38H Switcher No.8

‘ 0 0 0 9 ’ 30H 30H 30H 39H Switcher No.9

‘000A’ 30H 30H 30H 41H

Switcher No.10

8.TALLY(RESPONSE)DATA

The Projector will only accept and process data when the ID number included with the data coincides with

the ID-number registered to the Projector itself. (Except when ID = ‘0’) If the received ID-number

matches the Projector’s ID, it will return a response to the query from the external control unit. This

response data is called "Tally (Response) Data". (However, when ID = ‘0’, tally (response) data is not

replied.)

The Tally (Response) Data is normally returned within 3 seconds after the data is received.

There are some exceptions, however (e.g. POWER command)

After transmitting data, the external control unit cannot transmit subsequent data until the Tally

(Response) Data is received. However, if Tally (Response) Data is not returned within 3 seconds after

transmitting the data (there are some exceptions such as the POWER command), data transmission can

be retried.

8.1 Tally (Response) Data Status

8.1.1 Normal Termination Status

Character HEX Definition

‘0’ 30 Command received and processing terminated

8.1.2 Status when Error Occurs (Error Status)

Character HEX Definition

‘A00’

41H 30H 30H Command not supported

‘A01’

41H 30H 31H Invalid parameter

‘A02’

41H 30H 32H Parameter value exceeds operation range

‘A03’

41H 30H 33H Unclassified error

Unacceptable command in current mode

‘A04’

41H 30H 34H or

Unacceptable command with current setting

‘A05’

41H 30H 35H Command cannot be accepted if no signal.

‘A0A’

41H 30H 41H Time-out occurred with the communication with sub

microcomputer

‘A0B’

41H 30H 42H Error occurred with the communication with sub

microcomputer

8.2 Tally (Response) Data Parameter

The Tally (Response) Data Parameter is returned when the Tally (Response) Data is issued in

response to a query (request for data). No parameter is returned when Tally (Response) Data

issued in response to a command or when an error occurs.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels JVC Projecteur

JVC

JVC DLA-VS2200ZG Manuel utilisateur

JVC

JVC Reference DLA-RS57U Manuel utilisateur

JVC

JVC DLA-X700R Manuel du propriétaire

JVC

JVC D-ILA DLA-RS50 Manuel utilisateur

JVC

JVC D-ILA DLA-RS66 Manuel utilisateur

JVC

JVC D-ILA DLA-G3010ZG Manuel utilisateur

JVC

JVC D-ILA DLA-RS46 Guide d'installation

JVC

JVC DLA-SH7NLG Manuel utilisateur

JVC

JVC DLA-X770R Manuel utilisateur

JVC

JVC DLA-G150CLU Manuel utilisateur

JVC

JVC DLA-X30 Manuel d'utilisation et d'entretien

JVC

JVC DLA-SH7 Manuel d'utilisation et d'entretien

JVC

JVC DLA-M4000LU - D-ila Projector Manuel utilisateur

JVC

JVC DLA-HD10KSU - 1080p Home Theater Projector Manuel utilisateur

JVC

JVC DLA-X9000 Manuel utilisateur

JVC

JVC DLA-RS4810U Manuel utilisateur

JVC

JVC Procision DLA-HD990 Manuel utilisateur

JVC

JVC DLA-X900R Manuel

JVC

JVC DLA-X700R Manuel utilisateur

JVC

JVC DLA-M5000SC Manuel utilisateur

JVC

JVC DLA-RS15U - Reference Series Home Cinema... Guide d'installation

JVC

JVC DLA-M2000LU - 2000 Ansi Lumen D-ila Projector Less... Manuel utilisateur

JVC

JVC DLA-HD550-BU Manuel utilisateur

JVC

JVC DLA-RS4500 K Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
