Junghans J645.85 Manuel utilisateur

Quarzwerk

Quarz movement

J645.85

JUNGHANS – DIE DEUTSCHE UHR

1514

JUNGHANS – THE GERMAN WATCH

Many congratulations on your purchase of a timepiece from

Junghans.

What began in 1861 with the founding of the rm in Schramberg

quickly developed into one of the most fascinating success stories

of the German watchmaking industry. While since that time the

demands made of watches may have changed, the Junghans

philosophy has always remained the same. Innovative air and

the constant pursuit of precision right down to the smallest

detail dene how the company works and thinks. You can see and

sense this in every watch that carries the Junghans name. For as

diverse as the Junghans range may be, it pursues one single goal:

to combine traditional craftsmanship with cutting-edge watch

technology and exciting design. That makes every watch with the

Junghans star unique.

We hope you will enjoy this very special time-keeping instrument.

Yours,

Uhrenfabrik Junghans GmbH & Co. KG

ENGLISH

1716

Contents Page

1. Operating elements and functions 17

2. Operating the chronoscope (stopwatch function) 18

3. Technical information 21

4. Impermeability 22

5. General information 23

Setting the time

Pull the crown into position C. That stops the watch movement. To set

the watch accurately to the second it is best to stop the movement as

the second hand is passing the gure 60. You can now position the

minute hand precisely in line with the relevant minute marker and set

the desired time. Return the crown to position A to start the second

hand.

1. Operating elements and functions

30-minute counter Hour hand

Minute hand

Start-stop pusher

Reset pusher

Crown

Date display

Second hand

12-hour counter

Second counter

18 19

Adding measured time

Stop times may be added by pressing the start-stop pusher (D) again

after the initial measurement, instead of the reset pusher (E). The

chronoscope hands will then recommence from the stopped position.

Stop the chronoscope function by pressing the start-stop pusher (D)

again. You can continue the addition until the maximum stop time

is reached. To return the chronoscope hands to the starting position,

press the reset pusher (E).

Measuring split times

During the time measurement process it is possible to display a split

time without stopping the stopwatch process. To do so, start measure-

ment using the start-stop pusher (D). To read the split time press the

reset pusher (E). The time measurement continues in the background.

Pressing the reset pusher (E) again results in the chronoscope hands

advancing rapidly to catch up with the time that has elapsed. Further

interim times can be displayed by pressing the reset pusher (E). Stop

the chronoscope function by pressing the start-stop pusher (D) again.

The nal time is now displayed.To return the chronoscope hands to the

starting position, press the reset pusher (E).

Setting the date

Pull the crown into position B. Rotate the crown to the right to set the

date. Date alteration should not be performed between 8:00 p.m. and

3:00 a.m., as the date is automatically advanced by the movement

during this period and you could damage the advance mechanism. If

the month has less than 31 days, set the date manually to the rst day

of the following month.

2. Operating the chronoscope (stopwatch function)

Starting time measurement

Start the chronoscope function by pressing the start-stop pusher (D).

Stopping time measurement

Stop the chronoscope function by pressing the start-stop pusher (D)

again.

Resetting

Press the reset pusher (E). The three chronograph hands (5, 6, 7) move

back to the starting position.

20 21

Setting the chronoscope counters to the zero position

If one or more of the chronoscope hands is not in the correct zero

position (e.g. following battery replacement) you can adjust this as

follows: Pull the crown to position C. All chronoscope hands move to

the starting position. Activate the correction mode by simultaneously

operating the start-stop pusher (D) and the reset pusher (E) for at least

2 seconds. The hand of the second counter (7) rotates through 360°.

To set the second counter (7) press the start-stop pusher (D) briey

for a single step and longer for continuous setting, until the hand of

the second counter (7) is directly on the zero position. By pressing the

reset pusher (E) again you complete the positioning of the hand of the

second counter (7) and switch to setting the minute and second coun-

ter hand (5+6, mechanically connected). To set the minute and second

counter hands operate the start-stop pusher (D) briey for a single

step and longer for continuous setting, until the two hands are directly

on the zero position. After correctly aligning all chronoscope counters,

press the crown back to position A.

3. Technical information

Calibre J645.85

Quartz chronoscope with 30-minute and 12-hour counter

Battery 384 / SR 41 SW

Operating temperature 0° to + 50° C

Subject to technical alterations.

2322

4. Impermeability

Marking Instructions for use

Washing,

rain,

splashes Shower Bath Swimming

Diving

without

equipment

No mark No No No No No

3 BAR Yes No No No No

5 BAR Yes No Yes No No

10 BAR Yes Yes Yes Yes No

The designation ”3 – 10 BAR” only applies to brand new watches.

External inuences can aect water resistance. Please have your watch

checked regularly.

5. General information

External inuences can aect the watch’s waterproof qualities, which

may let in moisture. We therefore recommend that you have your

watch regularly inspected by your Junghans specialist. Other servicing

tasks or wrist strap repairs should also be done by your Junghans

specialist. Your watch is tted with a quality wrist strap that has

undergone multiple inspections in our factory. If, however, you decide

to change the strap, please t a new one of the same quality, preferably

an original Junghans wrist strap. Watch and wrist strap can be cleaned

with a dry or slightly moistened cloth.

NB: Do not use chemical cleaners (e.g. benzine or paint thinners). These

may harm the surface.

42.712-0601 / 0417 J645.85

Uhrenfabrik Junghans GmbH & Co. KG

Postfach 100 · D-78701 Schramberg

www.junghans.de · [email protected]
