JONIX maximate
AIR PURIFICATION DEVICE
WITH ADVANCED COLD PLASMA TECHNOLOGY
USE AND MAINTENANCE MANUAL
These instructions are translated from Italian (the original language).
JONIX S.p.A. reserves every right concerning this manual, including the right to make any necessary change or
improvement to its products and to the manual at any time and without notice. It is forbidden to reproduce in full or in part
this manual without JONIX S.p.A. ’s consent.
3
JONIXmaximate
TABLE OF CONTENTS
1 - GENERAL INFORMATION 5
1.1 - SERIAL NUMBER PLATE 5
1.2 - LIABILITY 5
1.3 - SYMBOLS 6
2 - WARNINGS AND GENERAL PROHIBITIONS 6
3 - THE OPERATING SYSTEM 8
4 - TECHNICAL DATA 9
4.1 - COMPONENT DESCRIPTION JONIX maximate 9
4.1.1 - Technical features JONIX maximate 9
5 - RECEPTION, TRANSPORT AND STORAGE 10
5.1 - PACKAGING 10
5.2 - HANDLING AND TRANSPORT 10
5.3 - INSPECTION UPON RECEPTION 10
5.4 - STORAGE 10
5.5 - HANDLING DEVICE IN OPERATING CONDITIONS 10
6 - INSTALLATION AND COMMISSIONING 11
6.1 - SAFETY STANDARDS 11
6.2 - GETTING STARTED 12
6.3 - CHOOSING THE INSTALLATION SITE 13
6.4 - ELECTRICAL CONNECTIONS 13
6.5 - ELECTRIC POWER SUPPLY 13
6.6 - USING THE DEVICE 14
6.7 - DEFAULT SETTINGS 14
6.8 - USER INTERFACE AND MENU NAVIGATION 15
6.8.1 - Main screen 15
6.8.2 - Ionisers screen 17
6.8.3 - Filters screen 17
6.8.4 - Fan screen 18
6.8.5 - Settings screen 18
6.8.5.1 - Date and time 18
6.8.5.2 - Language 19
6.8.5.3 - Protection 19
6.8.5.4 - Time slots 20
6.8.5.5 - Alarms history 21
6.8.5.6 - Maintenance 21
6.8.5.7 - Display 22
6.8.5.8 - Info 22
6.8.5.9 - Configuration 23
6.8.5.10 - Multimedia screen 23
4
JONIXmaximate
7 - MAINTENANCE 24
7.1 - WARNINGS 24
7.2 - ROUTINE MAINTENANCE 24
7.2.1 - Cleaning the Ionising Tubes 25
7.2.2 - External cleaning of the equipment 28
7.3 - SPECIAL MAINTENANCE 29
7.3.1 - Replacing the ionising tubes 29
7.3.2 - Replacing filters 32
7.3.2.1 - Absolute filters H13 32
7.3.2.2 - Rigid pocket filters F7 33
7.3.2.3 - Prefilter particulate coarse G4 34
8 - OPERATIONAL CHECK AND TROUBLESHOOTING 36
9 - DISPOSAL 37
ATTACHMENTS 38
EXPLODED JONIX maximate 38
OVERALL DIMENSIONS JONIX maximate 39
Thank you purchasing the JONIX maximate device.
This manual contains the information and all that is required for the transportation, installation,
use and maintenance of the JONIX maximate sanitation and filtering module.
Improper installation of the device and/or failure to comply with the instructions in this manual,
may invalidate the warranty that the Manufacturer issues for its products.
The Manufacturer is not liable for any direct and/or indirect damage caused by incorrect installation
or damage caused by the units installed by inexperienced and/or unauthorised staff. At the time of
purchase, check that the device is intact and complete.
The Manufacturer declines any liability in case of personal injury or property damage resulting
from any improper use of the device or from the failure to observe the use and safety instructions
specified in this manual. In any such case, any warranty claim will be void.
Any complaints must be submitted in writing within 8 days of receiving the goods.
For more information, download of the manual or video tutorial, we invite you to visit
www.jonixair.com.
5
JONIXmaximate
Fabbricante / Manufacturer
REF
SN
Nome del prodotto /
Product name
Descrizione del prodotto /
Product description
Dispositivo per la sanificazione attiva e
purificazione dell’aria
70MAXIMATEWHITE
230V / ~1 / 50Hz
2800
15
xxxxxxxxxxxx
Codice prodotto /
Model
Numero di serie /
Serial number
Caratteristiche elettriche
Alimentazione / Power Supply
Potenza nominale Assorbita /
Power Consumption (W)
Corrente massima / Full load
ampere (A)
JONIX maximate
JONIX S.p.A. S.B.
Viale Spagna, 31/33
35020 Tribano (PD)
The equipment described in this manual is provided with
a plate (applied inside the panelling that closes access
to the filters and to the ionising modules) containing the
equipment and Manufacturer data:
1.1 SERIAL NUMBER PLATE
The sanitation and filtering module JONIX maximate is
in compliance with Directives 2006/42/CE, 2011/65/UE,
2014/30/UE, 2014/35/UE and subsequent amendments.
1 - GENERAL INFORMATION
IMPORTANT WARNING
The JONIX maximate device is designed and made to sanitise the air in
residential environments that are incompatible with toxic and flammable
gases. It is therefore strictly forbidden to use the device in environments
where the air is mixed with and/or altered by other gaseous compounds
and/or solid particles. Using the device for purposes other than those
intended and that do not comply with those described in this manual, will
immediately relieve the manufacturer and its distributors from any direct
and/or indirect liability.
Failure to comply with the instructions contained in this Use and maintenance manual relieves the
Manufacturer from any liability. For any information not included or that cannot be deduced from
the Manual, consult the Manufacturer directly.
JONIX S.p.A. Società Benefit
Viale Spagna 31/33
35020 Tribano - PD - Italy
http://www.jonixair.com
In particular, if equipment maintenance is carried out in a way that is not in compliance with the
instructions supplied, or in a way to jeopardise integrity or modify features, JONIX S.p.A. is
relieved from any liability inherent to safety of persons and faulty operation of the equipments.
1.2 LIABILITY
6
JONIXmaximate
This instruction manual is an integral part of the device and therefore must be kept
carefully and must ALWAYS accompany the device, even in the event that it is sold
to another owner or user or transferred to another facility. In the event that it is
damaged or lost contact JONIX S.p.A. for another copy or download the document
from www.jonixair.com.
Repairs and maintenance work must be carried out by JONIX S.p.A. authorised
staff or by qualified staff according to the provisions set out by this manual. Do not
alter or tamper with the device as it can lead to hazards and the manufacturer of
the device shall not be liable for any damage caused.
After removing the packaging check that the contents are intact and complete. In
the event of a noncompliance please contact the Company that sold you the device.
2 - WARNINGS AND GENERAL PROHIBITIONS
HAZARD: It refers to dangerous situations that may result from the use of the device,
in order to ensure personal safety.
WARNING: It refers to integrations or suggestions concerning the proper use of the
device.
FORBIDDEN: This symbol refers to operations that must be avoided under any
circumstances, and hence forbidden.
HIGH VOLTAGE HAZARD!
Do not open or remove any doors or protections before disconnecting the voltage
supply.
WARNING!
It is mandatory to use protective gloves.
Please pay utmost attention to the following symbols and their meaning. They emphasise specific
information, such as:
1.3 SYMBOLS
WASTE FROM ELECTRICAL AND ELECTRONIC EQUIPMENT.
The crossed-out wheelie bin symbol on the equipment label indicates that the
equipment is compliant with the Waste Electrical and Electronic Equipment (WEEE)
Directive. Disposing of the equipment freely in the environment or illegally disposing of
the equipment are punishable by law.
7
JONIXmaximate
This device is not intended for use by people (including children) with reduced
physical, mental or sensory capabilities or without experience and knowledge,
unless they are supervised or are given instructions to use the appliance by a
person responsible for their safety. Take suitable precautions to prevent children
from playing with the device.
Do not carry out any maintenance or cleaning operations without having first
disconnected the device from the mains, by turning the main system switch to
“OFF”.
Do not touch the device if you are barefoot and with parts of the body that are wet
or damp.
Do not alter the safety or adjustment devices without prior authorisation and
instructions from the manufacturer of the device.
Please note that the use of products that require electricity, involves the observance of some
crucial safety rules such as:
When installing, commissioning and operating this product, it is mandatory to
observe the requirements and instructions specified in this manual.
JONIX S.p.A. disclaims any liability for damage caused to people, animals or
property due to installation, adjustment and maintenance errors or by improper
use.
Do not pull, detach or twist the electrical wires coming out of the device, even
when it is disconnected from the mains.
Do not open the panels for accessing the internal parts of the device without
having first turned the system switch to “OFF”.
Do not stand, sit and/or rest any type of object on the device.
Not dispose of or leave the packaging materials within reach of children because
it can be potentially dangerous.
Do not spray or throw water or other liquids directly onto the device.
8
JONIXmaximate
H2O, O3, VOC
BACTERIA
FUNGI
MOLDS AND YEASTS
M
I
C
R
O
B
I
C
I
D
A
L
A
C
T
I
O
N
free radical
OH, HO2, HO2- •
This sanitization device, by exploiting the physical process of ionisation, promotes the controlled
formation of particular ionic species (electrically charged species) in the air, through an
electrostatic field that simulates the natural process that normally occurs through solar radiation,
mechanically or by means of other physical phenomena.
The particular ionic species produced have proved to be particularly effective as sanitizing agents
in the air and on surfaces, moreover are historically and scientifically proven to be beneficial in
people, especially those with a negative electrical charge (arising from individual or small groups
of molecules that receive an electron).
3 - THE OPERATING SYSTEM
electric
field
< 3000W
free electron
Staphilococcus
Aureus
Abatement > 98%*
Aspergillus
Niger
Abatement > 96%*
Saccharomyces
Cerevisiae
Abatement > 99%*
neutral molecule
(O2, CO2, H2O)
gas molecule
(O2, O3, NO, NO2)
stable negative
ion
(O, O2, O3)
The JONIX maximate mobile filtering and sanitation
module, is the ideal solution for purifying and
decontaminating air in environments at risk such as
hospitals, clean rooms, food processing and packaging
rooms and clinics.
It is immediately operational after installation, requiring
no further operations.
The device combines 3 progressive filtration stages to
active air sanitization before it is reintroduced into the
environment.
The advanced control system adjusts ventilation and
the ionising load necessary to sanitise and purify air.
It is designed for quick and convenient maintenance as
all its components can be accessed from the front. The
sanitising cabinet is equipped with a double grid with
movable fins to direct the supply air flow. Compact,
portable and quiet, the JONIX maximate module
quickly and effectively meets the requirements of reducing bacterial and particulate load.
9
JONIXmaximate
11
06
07
10
04
12
05
06
07
09
04
05
01
03
03
02
08
02
4 - TECHNICAL DATA JONIX maximate
4.1 COMPONENT DESCRIPTION JONIX maximate
01 Adjustable 2 way air outlet register 07
Pre filter G4 – Coarse dust filter EN 779: 2012
02 Ionising modules JONIX maximate (n° 8) 08 Electrical panel - On / Off selector
03 Display Touch screen (7" or 13") 09
Straight plug
04 Main filter H13 – HEPA filter
Class EN 1822 - ISO 29463 10 Swivel casters with brake
05 Plug centrifugal EC fan (n° 2) 11 Straight connector
06 Secondary filter F7 – Fine dust filter
Class EN 779:2012 - ISO 16890 12 Handle for moving
Model Dimensions
(WxDxH) [mm] Power Supply Max power
absorption [W] Air flow rate [m3/h] Weight
[Kg]
JONIX
maximate
1305 x 715 x 2165
230 V / ~1 / 50Hz 2800 from 1500 to 7500 220
4.1.1 Technical features JONIX maximate
For the code of replacement components, refer to the "ATTACHMENTS" section.
FRONT VIEW
10
JONIXmaximate
5 - RECEPTION, TRANSPORT AND STORAGE
5.2 HANDLING AND TRANSPORT
To handle the device, use appropriate means, depending on the weight, as required
by Directive 89/391/EEC and subsequent amendments.
Please take great care while unloading and positioning the devices, to prevent
damaging the casing or components. Avoid uncontrolled rotations.
JONIX maximate and its accessories are delivered in specific protective packaging and
must remain intact until they are assembled. The materials that were not installed for technical
requirements are supplied with suitable enclosure secured to the inside or outside of the device
itself. The package includes:
- JONIX maximate sanitation and filtering module.
- Power cable.
- Operating and maintenance manual.
- Declaration of Conformity.
- Warranty conditions.
5.1 PACKAGING
Any type of complaint must be sent in writing within eight days from receiving the
goods.
When you receive the device please check all its parts, in order to make sure that it has not been
damaged during transport.
Any damage must be reported to the carrier, by filling in the relevant section on the delivery note
and specifying the type of damage.
5.3 INSPECTION UPON RECEPTION
The Manufacturer disclaims any liability for damage due to incorrect unloading
failure to protect the device from the elements.
In the event of extended storage keep the devices away from dust and sources of vibration and
heat.
5.4 STORAGE
The JONIX maximate device can easily be moved in various types of environments, as it has 4
360° rotating wheels. It can be blocked and secured in its operating position by the brakes on the
wheels (see Chap. "Technical Data").
5.5 HANDLING DEVICE IN OPERATING CONDITIONS
Table des matières
Autres manuels Jonix Purificateur d'air
