JONATHAN Y JYL4030A Manuel utilisateur

CARE AND MAINTENANCE

Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate

vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to

the material. Avoid the use of chemicals and household cleaners as they may damage the finish.

Model# JYL4030A

Product Dimensions: 11"L X 11"W X 64.5"H

NOTICE & IMPORTANT SAFETY INSTRUCTIONS

* Please make sure that you have all parts indicated before you begin assembly of this item

* This item should be assembled on a soft surface to prevent scratching the finish during assembly

* To reduce the risk of fire electrical shock or injury to persons or property please follow the guideline

o re

uce

e r

re, e

ury

o persons or proper

y, p

ease

e gu

below for safe use and installation

*The external flexible cable or cord of this luminaire cannot be replaced;

If the cord is damaged, the luminaire shall be destroyed

**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce

the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in the

outlet, reverse the plug, if it still does not fit, contact a qualified electrician. never use with an extension cord

unless the plug can be fully inserted. do not attempt to defeat this safety feature.

PIECE DESCRIPTION PICTURE QUANTIT

PIECE DESCRIPTION PICTURE QUANTITY

Part List and Hardware List

A Lamp base 1X E HARP 1X

B Lamp Body 1X F Metal Cap 1X

C Socket 2X G Bulb 2X

D Lamp Shade 1X H Finial 1X

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware

contents list. If any part is missing or damaged, do not attempt to assemble the product.

Estimated Assembly Time: 6 minutes

Estimated

Assembly

Time:

minutes

PLEASE USE ON/OFF TYPE"A" BULB MAX 60-WATT OR EDISON BULB MAX 60-WATT OR CFL BULB MAX 13-WATT OR LED BULB MAX 9-WATT

THERE ARE TWO 25-WATT EDISON BULBS IN THE BOX

C D

St 1

St 2

St 3

Step 1 Step2 Step3

Make sure all parts could be aligned before assemble Insert the Harp (E) into the Metal cap (F). Put the light on a level surface to check

Do not rotate lamp body too hard avoid base screw broke Put the shade(D) on the Harp(E),then if everything is stable.

Screw the Lamp body (B1) onto the Lamp base (A) tighten the Finial (H)into the Harp (E)

Screw the Lamp body (B2) onto the Lamp body (B1) Insert the bulb(F) into the socket(C).

S th L b d (B3) t th L b d (B2)

Screw the Lamp body (B3) onto the Lamp body(B2)

Screw the Lamp body (B4) onto the Lamp body(B3)

Screw the Socket (C) onto the Lamp base(B4)

Be careful not to twist the power cord and tighten securely

ENJOY YOUR LAMP
