JONATHAN Y JYL4029A Manuel utilisateur

WARNING

WE RECOMMEND INSTALLATION OF THIS LIGHTING FIXTURE BE DONE BY A LICENSED ELECTRICIAN.

WARNING *** SWITCH OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT

BREAKER BEFORE INSTALLATION.

INSPECT ITEM CAREFULLY BEFORE ATTEMPTING TO INSTALL. IF THERE IS ANY DAMAGE OR

Model# JYL4029A

Product Dimensions: 7"Lx 7"W x 20"H

OBVIOUS DEFECT, DO NOT INSTALL. ITEM MAY NOT BE RETURNED ONCE IT HAS BEEN INSTALLED.

CARE AND MAINTENANCE

Unplug lamps before using any cleaning solutions. Dust shades with a feather duster or with an appropriate

vacuum-brush attachment. Wipe with a soft, dry cloth and clean lamp bases with the methods appropriate to

the material. Avoid the use of chemicals and household cleaners as the

dama

e the finish.

* Please make sure that you have all parts indicated before you begin assembly of this item

* This item should be assembled on a soft surface to prevent scratching the finish during assembly

* To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below

yy g

NOTICE& IMPORTANT SAFETY INSTRUCTIONS

for safe use and installation

*The external flexible cable or cord of this luminaire cannot be replaced;

If the cord is damaged, the luminaire shall be destroyed

**This portable lamp has a polarized plug (one blade is wider than the other) as a safety feature to reduce

the risk of electric shock. this plug will fit in a polarized outlet only one way. if the plug does not fit fully in

PIECE

DESCRIPTION


QUANTITY

PIECE

DESCRIPTION


QUANTITY

pg p y y pg y

the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Never use with an extension

cord unless the plug can be fully inserted. do not attempt to defeat this safety feature.

Part List and Hardware List

PIECE DESCRIPTION PICTURE QUANTIT

A Lamp base 1X E Finial 1X

B Lamp body 1X F shade 1X

Lamp body

Bulb

Lamp

body

Bulb

D Socket 1X

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware

contents list. If any part is missing or damaged, do not attempt to assemble the product.

Estimated Assembl

Time: 6 minutes.

PLEASE USE ON/OFF TYPE"A" BULB MAX 40-WATT OR EDISON BULB MAX 40-WATT OR CFL BULB MAX 13-WATT OR

LED BULB MAX 9-WATT

THERE IS 25-WATT EDISON BULB IN THE BOX

Estimated

Assembly

Time:

minutes

1 2 3

C E

Step 1 Step2 Step3

Make sure all parts could be aligned before assemble Insert the bulb(G) into the socket(D). Put the light on a level surface to check

Do not rotate lamp body too hard avoid base screw broke

Put the shade(E) on the Harp(C),then if everything is stable.

S thL bd(B) tthL b (A)

ti ht th Fi i l (F)

crew the Lamp body

(

)

onto the Lamp base

(

)

tighten the Finial

(

)

Screw the Lamp body (C) onto the Lamp base (B)

ENJOY YOUR LAMP
