Jetson SLATE Manuel utilisateur

SLATE

-MANUAL-

TABLE OF CONTENTS

A. Introduction 4

B. Included in the Box 5

C. Features and Specs 6

D. Unboxing 7

E. Unfolding and Folding the Slate 7

F. Operating the Slate 9

1. Turning the Slate On and Off

2. Turning the Headlight On and Off

3. Battery Display

4. Speed Modes

G. Charging the Battery 11

H. Safe Driving 12

I. Care and Maintenance 12

J. Safety Warnings 14

K. Warranty 16

L. Product Registration 18

Congratulations on your new Jetson Slate! The Slate is an innovative

and fun personal transportation device, ready to take on everyday use.

Before your rst ride, check whether the wheels are damaged, or parts

are loose. If there are any abnormalities, please contact Jetson

Customer Support at 1-(888) 976-9904 or email us at

customerservice@jetsonbike.com.

This product manual can help you understand, use, and maintain your

Slate. In order to avoid danger caused by collisions, falls, and loss of

control, please use caution and learn how to ride the Slate safely.

Jetson and authorized dealers cannot be held liable for injury or

damage caused from riding the Slate. Users ride at their own risk.

The rider is responsible for consequences caused by violating warnings

or improper operations.

If you want to return this product for any reason, be sure to rst call or

email us before taking it back to the store so we can assist you.

INTRODUCTION

INCLUDED IN THE BOX

1. Rear Tire

2. Rear Foot Brake

3. Loop for Hook

4. Deck

5. Stem

6. Headlight

7. Folding Lever Bolt

8. Front Tire

9. Motor

10. Charging Port

234

FEATURES AND SPECS

MODEL: SLATE

WHEEL SIZE: (FRONT) 6”

(REAR) 5”

MAX SPEED: 15 MPH

MAX RANGE: 10 MILES

BATTERY TYPE: LITHIUM ION

BATTERY RATED VOLTAGE: 24V, 5.2Ah

PRODUCT DIMS: 37.5” x 17” x 41.25”

(FOLDED) 37.5” x 17” x 14”

MOTOR TYPE: HUB

MOTOR: 250 WATT

CHARGER: 110-240V

CHARGE TIME: UP TO 3 HOURS

PRODUCT WEIGHT: 18.25 LBS

WEIGHT LIMIT: 265 LBS

RECOMMENDED AGE: 13+

1. Handlebars

2. Electronic Brake

3. Thumb Throttle

4. Hook

5. Battery Indicator LED Lights

6. On/ Off Button

Please be careful when removing the Slate from the box, making sure

to not scratch the frame. Please check the carton for loose parts before

discarding.

The Slate comes fully assembled, except for the Handlebars. Please look

at the inside of each Handlebar and see which is labeled R (right) and L

(left). To connect the Handlebars, place L into the Left side and R into the

Right side (left and right directions are as though you are standing on the

deck). Tighten by turning the Handlebars toward the Front Wheel.

UNFOLDING AND FOLDING THE SLATE

To unfold the Slate, rst make sure the Hook is not connected to the

Loop on the Rear Brake. Lift the Handlebar and Stem Up towards the

front tire and open the Folding Lever all the way down. Once the Stem

is fully up right, Push the Folding Lever up until you hear a clicking

sound to lock it.

Folding

Lever

Locked

UNBOXING

To fold the Slate, loosen the Folding Lever by sliding the Red Clip up

and lowering the Folding Lever all the way down. Lower the Handle-

bar and Stem down towards the Deck and then connect the Hook to the

Loop on the Rear Brake.

Please Note: If the Folding Lever seems too tight, you can loosen the

Folding Lever Bolt on the front of the Stem near the Front Tire (please

see diagram on page 4).

Slide

OPERATING THE SLATE

TURNING THE SLATE ON AND OFF

To turn the Slate on, press and hold the On/Off Button for 3 seconds.

To turn the Slate off, rst make sure the Slate is not in motion. Then,

press and hold the On/ Off Button for 3 seconds.

On/ Off

Button

TURNING THE HEADLIGHT ON AND OFF

To turn the Headlight on, click the On/Off Button. One click will turn the

Headlight on. Another click will turn the Headlight off. You can also turn

off the Headlight by turning the Slate off.

Headlight

BATTERY DISPLAY

There are 5 battery level indicators with LED Lights. When the ve blue

LED Lights are on, the battery is full. When there is only one blue LED

Light on, the battery is low. Before you ride the Slate, press the Thumb

Throttle down gently to get a more accurate battery reading. Please

charge the Slate once it displays low battery.

Full

Battery

Light

Low

Battery

Light

SPEED MODES

There are two speed modes to choose from for the Slate. To change the

speed mode, double click the Power Button. The Low Battery Light will

either blink red or blue. A red blinking light means it is in High Speed

Mode and a blue blinking light means it is in Low Speed Mode.

Red = High

Speed Mode

Blue = Low

Speed Mode

Double

Click
