Thank you for selecting the JENCO Model 3631. The 3631 pH/O P transmitter is a

rugged microprocessor based instrument assembled in a watertight 1/8 DIN case,

designed for use in laboratories and process control applications.

The system displays pH or O P or Temperature status in one large LCD screen.

The model 3631 microprocessor performs a self-diagnostic routine every time you turn

on the unit providing you with basic information on the stability of the instrument.

The model 3631 has an isolated 4-20mA analog output, offset and span configurable

for the pH or O P display.

  $ ! 

Carefully unpack the unit and accessories. Inspect for damages made in shipment. If

any damage is found, notify your  representative immediately. All packing

materials should be saved until satisfactory operation is confirmed.

%! '    

ERVIEW

$# * 

PANEL CUTOUT DIMENSIONS

45.0

1.772"

92.0

3.622"

0.813 0.032

0.61

0.024

0.00

0.000

0.000 0.000

±±

$4 ' 

1. Make a cutout on any panel, with a

thickness of 1/16 inch (1.5mm) to

3/8 inch (9.5mm). efer to

$4 ' .

Mount ng Brackets

$4 ' )

2. emove the mounting assembly

from the controller and insert the

controller into the cutout. efer to

$4 ' ).

Panel Mount ng brackets

$4 ' 

3. eplace the mounting bracket

assembly onto the controller and

secure the controller to the

mounting panel. efer to

$4 ' .

【

Note

】

If the equipment is used in a manner not specified by the manufacturer, the protection

provided by the equipment may be impaired.

# & 

The front panel consists of a 4-digit LCD display and 4 keys.

5$! 



STAND SLOPE 7.00 ATC

ENTER

MODE

1. 6  7 key:

1a. In the  , this key will switch the display in sequence from pH,

Temperature, O P absolute mV, O P relative mV and back to pH again.

1b. In the /!* , pressing this key for three seconds will

move you back to the previous parameter in the case when recalibration / resetting

is required.

2. 6 % 7 key:

2a. In the / , pressing this key will show the next possible option.

In the !* , pressing this key will show the next possible option and

increases the numeral increment.

2b. In the  " pressing this key and 67 key at the same time,

the unit will enter the / .

3. 6 4 7 key:

3a. In the / , pressing this key will show the next possible option.

In the !* , pressing this key will show the next possible option and

decreases the numeral increment.

3b. In the  , pressing this key and 67 key at the same time,

the unit will enter the !* #

4. 6  7 key:

In any mode where the user can change the settings, pressing this key will save

the new settings. If no change has been made then pressing this key will just move

the user to the next setting.

#  

STAND SLOPE

RmV

CAL

6.86 7.00 ATC MAN

1 2 3 4 5

9876

1. Major LCD display.

2. $ 8 This icon will be displayed if the meter is in the /!* #

3. $ 8 This icon, when displayed, indicate in the 1 $ or ).$ !* .

4. ℃

℃℃

℃8Temperature and unit display.

5.  8 Unit indicator.

6. !$ 8 This icon will blink before Buffer 1 calibration. The icon will stay on while

Buffer 1 is being calibrated.

7. ! 8 This icon will blink before Buffer 2 calibration. The icon will stay on while

Buffer 2 is being calibrated.

8. #9 8 The 6.86 buffer group: 6.86, 4.00, 9.18.

9. ,#.. 8 The 7.00 buffer group: 7.00, 4.01, 10.01.

10. $ 8This icon will be displayed when a temperature probe is connected.

11. $ 8This icon will be displayed when a temperature probe is not connected.

12. 0 8 Unit indicator.

#  

100~230VAC

LNE

+ -

+V -V

10k TH Pt 1000

GND

INPUT FF

1. Connect the AC line to the rear of the instrument. The model 3631 can be used

with 100~240V AC at 50/60 HZ. Make sure the $ connector is connected to

the earth lead of the AC power line.

2. Set the proper load to the 4-20mA-output connector. Make sure that the load

impedance is less than 500 Ohms.
