2018 COMPASS QUICK REFERENCE GUIDE

Electric Park Brake (EPB)

Your vehicle is equipped with a new Electric

Park Brake System (EPB) that offers greater

convenience. The park brake switch is located

in the center console.

To apply the park brake manually, pull up on the

switch momentarily. The BRAKE warning lamp

in the instrument cluster and an indicator on

the switch will illuminate.

To release the park brake manually, the ignition

switch must be in RUN. Then put your foot on

the brake pedal and push the park brake switch

down momentarily. Once the park brake is fully

disengaged, the BRAKE warning lamp and the

switch indicator will extinguish.

The park brake can also be automatically re-

leased. With the engine running and the trans-

mission in gear, release the brake pedal and

depress the throttle pedal. For safety reasons,

your seat belt must also be fastened.

NOTE:

• You may hear a slight whirring sound from

the back of the vehicle while the parking

brake engages or disengages.

• If your foot is on the brake pedal while you

are engaging or disengaging the parking

brake, you may notice a small amount of

brake pedal movement.

• The new Auto Park Brake feature can be

used to apply the park brake automatically

every time you park the vehicle. Auto Park

Brake can be enabled and disabled in the

Settings menu in Uconnect.

• The parking brake can be engaged even

when the ignition switch is OFF, however, it

can only be disengaged when the ignition

switch is in the ON/RUN position.

• SafeHold a new feature that will automati-

cally apply the park brake under certain

conditions. The EPB monitors the status of

the driver’s seat belt, driver’s door and pedal

positions to determine if the driver may have

exited while the vehicle is still capable of

moving and will then automatically apply the

park brake to prevent the vehicle from

rolling.

• The EPB fault lamp will illuminate if the

EPB switch is held for longer than 20 sec-

onds in either the released or applied posi-

tion. The light will extinguish upon releasing

the switch.

Parking Brake Switch

STARTING AND OPERATING

Auto Park Brake

The EPB can be programmed to be applied

automatically whenever the vehicle speed is

below 1.9 mph (3 km/h) and the automatic

transmission is placed in PARK, or with a

manual transmission, whenever the ignition

switch is in the OFF position. Auto Park Brake is

enabled and disabled by customer selection

through the Customer Programmable Features

section of the Uconnect Settings.

Any single Auto Park Brake application can be

bypassed by pushing the EPB switch to the

release position while the transmission is

placed in PARK (automatic transmission) and

the ignition is in the ON/RUN position.

For further information, and applicable warn-

ings and cautions, please refer to the Owner’s

Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Selec-Terrain

Selec-Terrain combines the capabilities of the

vehicle control systems, along with driver input,

to provide the best performance for all terrains.

Mode Selection Guide

Rotate the Selec-Terrain knob to select the

desired mode.

•AUTO: This four-wheel drive operation is a

continuous operation, is fully automatic and

can be used on and off road. This mode

balances traction to ensure maneuverability

and acceleration improvement compared to

a vehicle with two wheel drive. This mode

also reduces fuel consumption, since it al-

lows the disconnect of the drive shaft where

conditions permit.

Selec-Terrain Switch

Selec-Terrain Switch (Trailhawk)

•SNOW: This mode allows you to have greater

stability under conditions of bad weather.

For use on and off road on surfaces with poor

traction, such as roads covered with snow.

When in SNOW mode (depending on certain

operating conditions), the transmission may

use second gear (rather than first gear) dur-

ing launches, to minimize wheel slippage.

•SAND: For off-road driving or use on surfaces

with poor traction, such as dry sand. The

transmission is set to provide maximum

traction.

•MUD: For off-road driving or use on surfaces

with poor traction, such as roads covered by

mud or wet grass.

•ROCK (Trailhawk only): This mode is only

available in 4WD LOW range. The device

sets the vehicle to maximize traction and

allow the highest steering capacity for off-

road surfaces. This mode gives you the maxi-

mum performance off-road. Use for low

speed obstacles such as large rocks, deep

ruts, etc.

NOTE:

• Rock mode is only available on the vehicles

equipped with the Off-Road package.

• Activate the Hill Descent Control for steep

downhill control. See “Electronic Brake Con-

trol System” in this section for further

information.

For further information, and applicable warn-

ings and cautions, please refer to the Owner’s

Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Front Wiper Operation

The windshield wiper/washer controls are lo-

cated on the lever on the right side of the

steering column.

Windshield Wiper Stalk

1 — Rear Wiper Operation

2 — Front Wiper Operation

WINDSHIELD WIPER/WASHER

FEATURES

Front Wiper Operation

The front wipers are operated by rotating a

switch, located on the end of the lever.

Rear Wiper Operation

The rear wiper/washer is operated by rotating a

switch, located at the middle of the lever.

NOTE:

When the front wipers are activated and reverse

gear is engaged, the rear wiper will activate to

clear the rear window.

Rain Sensing Wipers — If Equipped

This feature senses moisture on the windshield

and automatically activates the wipers for the

driver. The feature is especially useful for road

splash or overspray from the windshield wash-

ers of the vehicle ahead. Rotate the end of the

multifunction lever to one of two settings to

activate this feature. Rain Sensing Wipers are

activated through the Uconnect Settings.

For further information, and applicable warn-

ings and cautions, please refer to the Owner’s

Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Speed Control

When engaged, the Speed Control takes over

accelerator operations at speeds greater than

25 mph (40 km/h).

Speed Control Switches

1 — Push Cancel

2 — Push Set+/Accel

3 — Push Resume

4 — Push On/Off

5 — Push Set-/Decel

SPEED CONTROL

To Activate

Push the on/off button. To turn the system off,

push the on/off button a second time. The

system should be turned off when not in use.

To Set A Desired Speed

Turn the Speed Control on. When the vehicle has

reached the desired speed, push the SET (-) or

SET (+) button and release. Release the accelera-

tor and the vehicle will operate at the selected

speed.

To Deactivate

A soft tap on the brake pedal, pushing the CANC

button, or normal brake pressure while slowing the

vehicle will deactivate Speed Control without eras-

ing the set speed memory. Pushing the on/off

button or turning the ignition switch OFF erases

the set speed in memory.

To Resume Speed

To resume a previously set speed, push the RES

button and release.

To Increase Speed

When the Speed Control is set, you can in-

crease speed by pushing the SET (+) button.

To Decrease Speed

When the Speed Control is set, you can de-

crease speed by pushing the SET (-) button.

To Accelerate For Passing

Press the accelerator as you would normally.

When the pedal is released, the vehicle will

return to the set speed.

For further information, and applicable warn-

ings and cautions, please refer to the Owner’s

Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

ParkSense Rear Park Assist — If

Equipped

• The four ParkSense sensors, located in the

rear fascia/bumper, monitor the area behind

the vehicle that is within the sensor’s field of

view.

ParkSense Switch

PARKSENSE

• The sensors can detect obstacles from ap-

proximately 12 inches (30 cm) up to

79 inches (200 cm) from the rear bumper

while the vehicle is in REVERSE. When an

obstacle is detected, a warning will display

in the instrument cluster, and a chime will

sound (when Sound and Display is selected

from the Uconnect Settings/Customer Pro-

grammable Features section of the

Uconnect System screen). As the vehicle

moves closer to the object, the chime rate

will change from single 1/2 second tone, to

slow, to fast, to continuous.

• If the system detects a potential impact with

an object, the vehicle brakes may be

applied.

For further information, and applicable warn-

ings and cautions, please refer to the

Owner’s Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Parkview Rear Back-Up Camera

You can see an on-screen image of the rear of

your vehicle whenever the transmission is

shifted into REVERSE. The ParkView Rear

Back-Up Camera image will be displayed on the

Uconnect Display, located on the center stack

of the instrument panel.

For further information, and applicable warn-

ings and cautions, please refer to the

Owner’s Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Blind Spot Monitoring — If

Equipped

The Blind Spot Monitoring (BSM) system uses

two radar-based sensors, located inside the rear

bumper fascia, to detect highway licensable

vehicles (automobiles, trucks, motorcycles,

etc.) that enter the blind spot zones from the

rear/front/side of the vehicle.

The BSM warning light, located in the outside

mirrors, will illuminate if a vehicle moves into a

blind spot zone.

BSM Warning Light

PARKVIEW SAFETY FEATURES

Rear Cross Path

The Rear Cross Path (RCP) feature is intended

to aid the driver when backing out of parking

spaces where their vision of oncoming vehicles

may be blocked. Proceed slowly and cautiously

out of the parking space until the rear end of the

vehicle is exposed. The RCP system will then

have a clear view of the cross traffic and if an

oncoming vehicle is detected, alert the driver.

Mode Of Operation

Three selectable modes of operation are avail-

able through the Uconnect System.

For further information, and applicable warn-

ings and cautions, please refer to the

Owner’s Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Forward Collision Warning With

Mitigation — If Equipped

The Forward Collision Warning (FCW) system

provides the driver with active braking, audible

and visual warnings [within the instrument

cluster display] and may apply a brake jerk to

warn the driver when it detects a potential

frontal collision. The warnings and limited

braking are intended to provide the driver with

enough time to react and avoid or mitigate the

potential collision.

FCW monitors the information from the

forward-looking sensor, as well as the Elec-

tronic Brake Controller (EBC) to calculate a

probable collision. When the system deter-

mines that a collision is probable, a warning

message (both audible and visual) will be dis-

played within the cluster display along with a

brake jerk warning (previously enabled in the

Uconnect Settings). When the system senses

the driver applying the brakes to avoid a prob-

able collision, additional brake force will be

provided to the vehicle. When the system deter-

mines a collision with the vehicle in front of you

is no longer probable, the warning message will

be deactivated.

NOTE:

The FCW feature can be customized and turned

off through the Uconnect System touchscreen.

For further information, and applicable warn-

ings and cautions, please refer to the

Owner’s Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Opening

To unlock the liftgate, use the key fob or acti-

vate the power door lock switches located on

the driver door.

To open the liftgate, squeeze the electronic

liftgate release and pull the liftgate open with

one fluid motion.

Closing

Grasp the liftgate closing handle and initiate

lowering the liftgate. Release the handle when

the liftgate takes over the closing effort.

NOTE:

Before closing the liftgate, make sure to be in

possession of the key because the liftgate may

be locked.

For further information, and applicable warn-

ings and cautions, please refer to the

Owner’s Manual at www.mopar.com/en-us/care/

owners-manual.html (U.S. Residents) or

www.owners.mopar.ca (Canadian Residents).

Identifying Your Radio

Uconnect 3 With 5–inch Display

• 5.0” Full Color Touchscreen Display

• Bluetooth Connectivity/Bluetooth Streaming

Audio

Liftgate Handle Location

Uconnect 3 With 5–inch Display

LIFTGATE UCONNECT

Uconnect 4 With 7–inch Display

• 7.0” Full Color Touchscreen Display

• Bluetooth Connectivity/Bluetooth Streaming

Audio

Uconnect 4/4C/4C NAV With 8.4–inch Display

• 8.4” Full Color Touchscreen Display

• Navigation on the bottom bar menu (if

equipped)

• Bluetooth Connectivity/Bluetooth Streaming

Audio

Refer to the Uconnect Owner’s Manual Supple-

ment or the Uconnect Voice Recognition Tip

Card for further information about the

Uconnect Systems.

Activation

To use SiriusXM Guardian emergency, remote

and security services, you must activate your

SiriusXM Guardian account.

1. Press the Apps icon on the bottom of your

in-vehicle touchscreen.

2. Select the “Activate Services” icon from

your list of apps.

3. Select “Customer Care” to speak with a

SiriusXM Guardian Customer Care agent

who will activate services in your vehicle, or

select “Enter Email” to activate on the web.

Once you have activated your services, you’re

only a few steps away from using remote ser-

vices.

Uconnect 4 With 7–inch Display Uconnect 4/4C/4C NAV With 8.4–inch

Display

SIRIUSXM GUARDIAN — IF

EQUIPPED

Autres manuels pour COMPASS 2018

Table des matières

Autres manuels Jeep Automobile

Jeep

Jeep Grand Cherokee SRT 2014 Manuel utilisateur

Jeep

Jeep CHEROKEE 2017 Manuel utilisateur

Jeep

Jeep 2010 Wrangler Manuel utilisateur

Jeep

Jeep Grand Cherokee Manuel utilisateur

Jeep

Jeep GRAND CHEROKEE 2023 Manuel utilisateur

Jeep

Jeep Grand Cherokee Guide d'installation

Jeep

Jeep Grand Cherokee WK2 2014 Instructions d'utilisation

Jeep

Jeep Compass Manuel utilisateur

Jeep

Jeep The New 2014 Grand Cherokee Manuel utilisateur

Jeep

Jeep Grand Cherokee SRT 2014 Manuel utilisateur

Jeep

Jeep Jeep Wrangler Manuel utilisateur

Jeep

Jeep Jeep Wrangler 2013 Manuel utilisateur

Jeep

Jeep Wrangler2018 Manuel utilisateur

Jeep

Jeep Wrangler Postal Vehicle 2017 Guide de configuration

Jeep

Jeep 2015 Wrangler Manuel utilisateur

Jeep

Jeep 2009 Patriot Manuel utilisateur

Jeep

Jeep Jeep Wrangler Guide de configuration

Jeep

Jeep RENEGADE 2017 Manuel utilisateur

Jeep

Jeep Grand Cherokee 2012 Manuel utilisateur

Jeep

Jeep Cherokee 2019 Manuel utilisateur

Jeep

Jeep 2016 Patriot Manuel utilisateur

Jeep

Jeep Grand Cherokee Manuel utilisateur

Jeep

Jeep Automobile Manuel utilisateur

Jeep

Jeep 2014 Grand Cherokee Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
