JBL HT5 Manuel utilisateur

X +

0 +

MHZ

X + 0 + Y

”

X + 0 + Y

DESIGN GOAL: Bring the thrill of live performance and movie sound to

the home environment by calling on JBL’s professional engineering leadership.

CROSSOVER NETWORK: Straight-Line Signal Path

™

(SSP)

PORT DESIGN: FreeFlow

™

flared

PROFESSIONAL REFERENCE: Cinema Loudspeaker Series

OWNER’S GUIDE

WOOFER TYPE:

Cast-aluminum basket with HeatScape

™

motor structure

PRODUCT LINE: HT SERIES

MODEL HT5

NUMBER:

THANK YOU FOR CHOOSING JBL

For more than 50 years, JBL

has been involved in every

aspect of music and film

recording and reproduction,

from live performances to the

recordings you play in your

home, car or office.

We’re confident that the JBL

loudspeakers you have

chosen will provide every

note of enjoyment that you

expected –and that when you

think about purchasing

additional audio equipment

for your home, car or

office, you will once again

choose JBL.

Please take a moment to

complete the enclosed

profile card. It enables us

to keep you posted on our

latest advancements, and

helps us to better understand

our customers and build

products that meet their

needs and expectations.

JBL Consumer Products

TWEETER TYPE: Pure-titanium dome with Bi-Radial®Constant Directivity Horn

SPEAKER PLACEMENT

Proper placement of the

speakers is an important step

in obtaining the most realistic

soundstage possible. These

recommendations are for the

optimum placement of the

loudspeakers. Use these

placement recommendations

as a guide. Slight variations

will not diminish your

listening pleasure.

HT5 loudspeakers are video-

shielded and can safely be

placed near a television.

As Front Speakers

As Surround Speakers

5–6 ft.

HT5

The front speakers should

be placed the same distance

from each other as they are

from the listening position.

They should be placed at

about the same height from

the floor as the listeners’

ears will be, or they may be

angled toward the listeners.

If a center-channel speaker

is used, it should be placed

slightly behind the front left

and right speakers, and no

more than two feet above or

below the tweeters of the

left and right speakers. It is

often convenient to set the

center speaker on top of the

television set.

The two surround speakers

should be placed slightly

behind the listening position

and, ideally, should face

each other and be at a level

higher than the listeners’

ears. If that is not possible,

they may be placed in the

corners of the room behind

the listening position, angled

in toward the center of the

listening area. The surround

speakers should not call

attention to themselves.

Experiment with their

placement until you hear a

diffuse, ambient sound

accompanying the main-

program material heard in

the front speakers.

SPEAKER FEET

The HT5 comes with rubber,

self-adhesive footpads,

which should be attached to

the bottom corners of each

speaker to protect both

your furniture and the

speakers.

Alternative Surround Speaker

Placement

If there is no sound from

any of the speakers:

•Check that receiver/

amplifier is on and that

a source is playing.

•Review proper operation

of your receiver/amplifier.

•Check all wires and con-

nections between receiver/

amplifier and speakers.

•Make sure all wires are

connected. Make sure none

of the speaker wires are

frayed, cut or punctured.

If there is no sound coming

from one speaker:

•Check the “Balance”

control on your receiver/

amplifier.

•Check all wires and

connections between

receiver/amplifier and

speakers. Make sure all

wires are connected. Make

sure none of the speaker

wires are frayed, cut or

punctured.

•In Dolby* Digital or DTS®

modes, make sure that the

receiver/processor is

configured so that the

speaker in question is

enabled.

If the system plays at low

volumes but shuts off as

volume is increased:

•Check all wires and

connections between

receiver/amplifier and

speakers. Make sure all

wires are connected. Make

sure none of the speaker

wires are frayed, cut or

punctured.

•If more than one pair of

main speakers is being

used, check the minimum

impedance requirements of

your receiver/amplifier.

If there is low (or no) bass

output:

•Make sure the connections

to the left and right “Speaker

Inputs”have the correct

polarity (+ and –).

•If a powered subwoofer is

being used, check the

manufacturer’s instructions

for proper use.

•If a subwoofer is being

used in Dolby Digital or DTS

mode, make sure your

receiver/processor is

configured so that the

subwoofer and LFE output

are enabled.

If there is no sound from

the surround speakers:

•Check all wires and con-

nections between receiver/

amplifier and speakers.

Make sure all wires are

connected. Make sure none

of the speaker wires are

frayed, cut or punctured.

•Review proper operation of

your receiver/amplifier and

its surround-sound features.

•Make sure the movie or TV

show you are watching is

CONNECTION TIPS

SPEAKER CONNECTIONS

TROUBLESHOOTING

Speakers and electronics

terminals have corre-

sponding (+) and (–)

terminals. It is important to

connect both speakers

identically: (+) on the

speaker to (+) on the

amplifier and (–) on the

speaker to (–) on the

amplifier. Wiring “out of

phase”results in thin sound,

weak bass and a poor

stereo image.

With multichannel surround-

sound systems, connecting

all of the speakers in your

system with the correct

polarity is important in order

to preserve the proper

ambience and directionality

of the program material.

–+–+

–+

Speaker Outputs

LEFT

RIGHT

–+

JBL Consumer Products

250 Crossways Park Drive, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91329

800-336-4JBL (4525) (USA only)

www.jbl.com

JBL is a registered trademark of JBL, Incorporated.

Part No.

336349-001

TWEETER TYPE: Pure-titanium dome with Bi-Radial®Constant Directivity Horn

DESIGN GOAL: Bring the thrill of live performance and movie sound to

the home environment by calling on JBL’s professional engineering leadership.

CROSSOVER NETWORK: Straight-Line Signal Path

™

(SSP)

WOOFER TYPE:

Cast-aluminum basket with HeatScape

™

motor structure

PORT DESIGN: FreeFlow

™

flared

PROFESSIONAL REFERENCE: Cinema Loudspeaker Series

OWNER’S GUIDE PRO SOUND

COMES HOME™

PRODUCT LINE: HT SERIES

MODEL HT5

NUMBER:

SPECIFICATIONS

HT5

Frequency Response (–6dB):

50Hz –20kHz

(±2dB):

100Hz –18kHz

Sensitivity (2.83V/1m):

85dB

Maximum Recommended Amplifier Power**: 130W

Nominal Impedance: 8 Ohms

Crossover Frequency: 2300Hz

Low-Frequency Transducer

:5-1/4"

High-Frequency Transducer: 1" Pure-titanium dome, with Bi-Radial®horn

Dimensions (H x W x D): 13-5/8" x 6-13/16" x 10"

346mm x 173mm x 254mm

Weight: 14 lb/6.4kg

Occasional refinements may be made to existing products without notice, but will always meet or exceed original specifications

unless otherwise stated.

* Trademark of Dolby Laboratories. DTS is a registered trademark of Digital Theater Systems, Inc.

** The maximum recommended amplifier power rating will ensure proper system headroom to allow for occasional peaks. We do not

recommend sustained operation at these maximum power levels.

recorded in a surround-

sound mode. If it is not, check

to see if your receiver/

amplifier has other surround

modes you may use.

•In Dolby Digital or DTS

modes, make sure your

receiver/processor is

configured so that the

surround speakers are

enabled.

•Review the operation of

your DVD player and the

jacket of your DVD to make

sure that the DVD features

the desired Dolby Digital or

DTS mode, and that you

have properly selected that

mode using both the DVD

player’s menu and the DVD

disc’s menu.

TROUBLESHOOTING (cont.)
