JBLColoradoOwner’sManual

TableofContents

Wiringthestereo………………………………………………………………………………………….pg.XX

Mountingthestereo………………………………………………………………………………….…pg.XX

Generalbuttonoperation………………………………………………………………………….…pg.XX

Systemsettings…………………………………………………………………………………………..pg.XX

Radiooperation…………………………………………..……………………………………………….pg.XX

Bluetoothoperation………………………………………………………………………………….…pg.XX

USBoperation…………………………………………………………………………………………..…pg.XX

Specifications……………………………………………………………………………………………….pg.XX

Warnings……………………………………………………………………………………………….........pg.XX





WIRINGTHESTEREO

IMPORTANT:Disconnectthevehicle’snegative(–)batteryterminalbeforebeginningtheinstallation.

1. PlugthevehicleharnessintothereceptacleonthebackoftheColoradostereo.

2. PlugthevehicleantennaharnessintotheantennaportofthebackoftheColoradostereo.



MOUNTINGTHESTEREO

Placethestereoagainstthemountingsurfaceandsecurewithfoursheetmetalscrews.



GENERALBUTTONOPERATION



1. Home/Power:Turnsthestereoonwithashortpressandoffwithalongpress;letsyoureturntothe

sourceyouareplayingfromsettingsmode.

2. VOL–:Lowersthesourcevolume,andletsyouadjustsettingslevels.

3. VOL+:Raisesthesourcevolume,andletsyouadjustsettingslevels.

4. Scan:Letsyoulistento3‐secondsamplesofeachstationacrossaradioband;inUSBmode,letsyou

selectorturnoffRepeatandRandommodes;inBluetoothmode,letsyouquicklydisconnectand

reconnectpairedBluetoothdevices.

5. Play/Pause:Letsyoumutearadiobroadcast,orplay/pauseatrackonUSBorBluetooth.

6. MODE/SEL:Letsyouselectsource(FM/AM/WBD,Bluetooth,USB)withashortpush,andenter

SETTINGSmodewithalongpush.

7. Tune/Trackdown:LetsyouselectradiostationsandBluetooth/USBtracks.

8. Tune/Trackup:LetsyouselectradiostationsandBluetooth/USBtracks.





SYSTEMSETTINGS

PressandholdtheMODE/SELbuttontoenterthesettingsmenu.



1. ShortpresstheMODE/SELbuttontocyclethroughthesettingsoptionslistedbelow.

2. PresstheVOL+andVOL–toadjustthelevelsofeachoption.





BASS‐7dB–+7dB

TREBLE‐7dB–+7dB

BALANCEL10

–

R10

FADERF10–R10

SUBF10–R10

PRESETEQOFF,FLAT,POP,CLASSICAL,ROCK

LOUDNESSON/OFF

BEEPON/OFF

I‐VOL0–45(DEFAULT:20)

AREAUSA/EUA/JAPAN/OTHER

SOFTWAREVERSION





RADIOOPERATION

PresstheMODE/SELbuttontoselectFM/AM/WBD.



Scanstations

1. ShortpressSCANtosample3secondsofpre‐storedradiostations.

2. PressandholdSCANtosample3secondsofallstationsintheFMorAMband.



Mute/Unmute

ShortpressthePlay/Pausebuttontomutetheoutput.Pressagaintounmute.







Tuningstations

1. Autotuningmode:ShortpresstheTuneUp/Downbuttonstoautomaticallytunetoradiostations.

Thisisthedefaultmode.



2. Manualtuningmode:PressandholdtheTuneUp/Downbuttonstoactivatemanualtuning.After

“MANUAL”displaysonthescreen,shortpresstheTuneUp/Downbuttonstotunetofrequencies

onestepatatime.



3. TheColoradowillreturntoAutotuningafter5secondsofnoactivity.



BLUETOOTHOPERATION

PresstheMODE/SELbuttontoselectBTMUSIC.



Pairingadevice

1. WiththeColoradoinBTMUSICmode,select“JBLHMLCD”fromtheBluetoothmenuofyour

streamingdevice.



2. PressandholdtheSCANbuttontodisconnectyourstreamingdevice.ShortpressSCANtoreconnect

it.





Playingmusic

1. PressthePlay/Pausebuttontoplayorpauseatrack.





2. PresstheTrackUp/TrackDownbuttonstoselectthenextorprevioustrack.





USBOPERATION

PresstheMODE/SELbuttontoselectUSB.



Playbackmodes

1. ShortpresstheSCANbuttontoselectplaybackmodesshownbelow.



2. PresstheVOL+buttontoselecttheoptionsineachplaybackmode.





SCANOFF/ON

REPEAT(RPT)OFF/FOLDER/ALL

RANDOM(RDM)OFF/FOLDER/ALL



Playingmusic

1. PressthePlay/Pausebuttontoplayorpauseatrack.





2. PresstheTrackUp/TrackDownbuttonstoselectthenextorprevioustrack.(NOTE:TrackDownwill

selecttheprevioustrackifnomorethan5secondsofacurrenttrackhaveelapsed;after5seconds,

TrackDownwillreturntothestartofthecurrenttrack.PressTrackDownagainquicklytoselectthe

previoustrack.)







SPECIFICATIONS

TunerbandsAM/FM

AMBandforUSA530‐1710kHz(10kHzSTEP)

AMBandforEurope531‐1602kHz(9kHzSTEP)

AMBandforJapan522‐1629KHZ(9kHzSTEP)

FMBandforUSA87.5‐107.9MHz(0.2MHzSTEP)

FMBandforEurope87.50‐108.00MHz(0.05MHzSTEP)

FMBandforJapan76.0‐90.0MHz(0.1MHzSTEP)

Numberofstationpresets18

WeatherBand(NOAA7‐CH)162.400MHz‐ 162.550MHz(25Khzstep)

Bluetoothversion5.0

BluetoothA2DPprotocolYes

BluetoothAVRCPV1.4ornewer

SerialPortProfile(SPP)Yes

SimpleSecurePairing(SSP)Yes

Numberofpairedphones5

BluetoothautoreconnectYes(mostrecentlypairedphone)

CompatiblemediafileformatsMP3,AAC(onAppledevices),WMA,WAV,M4A,FLAC

MaximumnumberoffilesonUSBdevice9999

RMSPowerOutput(WattsxChannel)@4‐ohm25Wx4

FrequencyResponse,+/‐1dB20Hzto20kHz

Signal‐to‐NoiseRatio>75dB

THD+N@4‐ohm(amplifier)10%

THD+N@2.3Vrms(RCAoutputs)1%

Operatingvoltage9V–16V

Quiescentcurrent<0.2mA





1. changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoid

theuser'sauthoritytooperatetheequipment.

2.ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursua

nttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainsthar

mfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofr

equencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful

interferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccu

rinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionre

ception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotry

tocorrecttheinterferencebyoneormoreofthefollowingmeasures:

—Reorientorrelocatethereceivingantenna.

—Increasetheseparationbetweentheequipmentandreceiver.

—

Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnect

ed.

—Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



3.ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanada’slicence‐exempt

RSSs.Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseinterference;and

(2)Thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.



4.RFexposurestatement:TheequipmentcomplieswithFCC&ISEDradiationexposurelimitssetforthfor

anuncontrolledenvironment.

5.Cet appareil est conforme à la licence RSSs de Innovation, Science et développement

économique Canada.L’exploitation est soumise aux deux conditions suivantes:

(1) ce dispositif ne doit pas causer d’interférences;et

(2) ce dispositif doit accepter toute interférence, y compris toute interférence susceptible de

provoquer un fonctionnement indésirable du dispositif.

L’équipement est conforme aux limites d’exposition aux rayonnements isee établies par

Innovation, Science et développement économique Canada pour un environnement non

contrôlé.


