Chapter 1 Introduction
Note:
It is better for you to keep the carton and the packing material in case you
might need them for packing or moving in the future.
1-1 Description
Jarltech’s 8670 Terminal is an excellent tool designed for small foot-print
display applications. 8670 Terminal offers an onboard NS Geode
GX1-233/300 processor, plus support for Ethernet network functions onboard
features include TFT LCD, a 128M Compact-Flash™ card. With the 586-level
NS Geode processor mounted directly on board, upgrade and system
configuration is much more convenient as is the benefits of fan less operation
in temperatures up to 60° C (140° F). This teminal is a feature-packed,
586-level, hassle-free solution for space critical applications.
The 8670 Terminal complies with the "Green Function" standard and
supports three types of power saving features: Normal, Doze, and Sleep
modes. The display type configuration is done through software. A single
Flash chip holds the system BIOS and the VGA BIOS. This minimizes the
number of chips and eases configuration. You can change the display BIOS
simply by programming the Flash chip. If you need any additional functions,
8670 Terminal has a PC/104 connector for future upgrades.
And The 8670 terminal has a 8-wire resistor touch screen. It made the input
operation more flexible coordinate with special software.
1-2 Hardware Descriptions
1-2-1 Mainboard Jarltech industry level main-board
Display chip onboard: NS –CX5530A ,1-4M shared
system memory ,Set in BIOS
Ethernet chip onboard: Realtech 8139C PCI PnP
10/100 Base-T Ethernet
Bundled with popular software drivers, the Ethernet
interface allows great flexibility to work with all major
networking operating systems including Novell
NetWare v2.x, v3.x, v4.x, Microsoft LAN Manager,
Win3.1, Win NT, Win95, IBM LAN Server, SCO UNIX
or other ODI, NDIS and Packet drive compliant
operating
Audio chip onboard: AC 97 codec with surround
sound,Microsoft direct Sound 3D audio supported
32-bit sound blaster TM and sound blaster
TM pro compatible
Full duplex operation for simultaneous record and
playback
Internal MIC-in,LINE-in ,Speaker-out interface
reserved
1-2-2 CPU
Onboard Gx-1 233MHz or Gx-1 300MHz,Supports
windows NT ,windows98/95,Linux,MS-DOS
operations environment
1-2-3 System memory:
128M standard
Onboard 144Pin SODIMM socket .support to
16M,32M,64M,128M,Max256M modules
1-2-4 Main store device:
128M Compact Flash card
It also supports IDE interface Compact Flash Card
1-2-5 Display specifications:
Display •10.4" TFT LCD display
Resolution •SVGA 800 x 600
Display Area •211.2 (H) x 158.4 (V) mm
Display Color •262K
Contrast Ratio •250 : 1 (Typical )
Brightness •150 cd/m2
V
iewing Angle •@CR=10:1(R/L/U/D): 45 / 45 / 15 / 35
Stand Angle Adjustable •from 45 degree to 90 degree
Input Signal •R.G.B Analog 0.7Vp-p / 75 ohm
Control Button •Screen On/Off, “A”(Programming),
“M”(Save Brightness) , LCD Bright Up,
Down, Reset1/Reset2
Power Consumption •25W( Max.) / Standby 4W
Environmental
•Temperature 0~40℃
•Humidity :Less than 85%
1-2-6 Physical Features
Physical Dimension Including stand 27 ( L ) x 18.5 (W) x 27 ( H )
cm
Weight 3.5 Kgs
1-2-7 Satety and EMI
Safety & EMI FCC-B, CE
1-2-8 Integrated Options
Built-in 10.4” 8 wire resistor Touch screen mouse
Built-in ISO standard all track keyboard wedge magnetic stripe
reader
Built-in smart keyboard wedge ibutton key reader with Dallas
Ibutton key
Chapter2 Installation
2-1. Before unpacking
It’s very important to locate the 8670 terminal in suitable environment.
The surface for placing the 8670 terminal should be stable and level.
Make sure the place has good ventilation, is out of direct sunlight, away from
source of excessive dust, dirt, heat, water, moisture and vibration.
Convenience for connecting the 8670 terminal to the related facilities should be
well considered too.
2-2.Checking package
There are the following parts in the package:
a: 1 piece main 8670 terminal
b: 1 piece power
c: 1 piece extend power cable
d: 1 piece V cable with mouse and keyboard adapter
e: 1 piece driver CD
If the five parts are ready you may start connecting your teminal.
2-3. Connecting the 8670 terminal
2-3-1 know the parts
at first please know the parts. It make you avoid possible mistake
a: figture1 is the power
figture 1
b: figture 2 is the power cable
figture 2
c: figture 3 is the mouse and keyboard V type cable
figture 3
d: figture 4 is the main 8670 terminal front and flank view :
MSR
Card Reader
iBUTTON
figture 4
figture 5
e: figture 5 is the back view of 8670 without the card reader and ibutton
2-4 know the connect ports
The figture6 show all the ports at the hind of the 8670 terminal
CO
M1
CO
M2
US
B
CO
M
3
Power
Ethernet Mouse and Keyboard
2-5 Link all the parts together
Link all the parts as figture 7
