Jam Woof it Manuel utilisateur
WOOFit JAM
User Manual
1
Thank you!
Thank you for purchasing this WOOFit
JAM speaker from SACKit.
Please read this manual carefully before
use. We are not responsible for any
person or property damage caused by
improper use of this product. We hope
you enjoy the louder, richer sound, and
features from your WOOFit JAM device.
Box Contents
- WOOt JAM speaker
- User manual
- Information USB charging cable
3.5mm
- Stereo cable
UK
Quick Start Guide
1. Charge the WOOFit JAM Speaker
using the included USB charging cable
and adapter for no less than 2 hours
2. Turn on WOOFit JAM
3. Turn on Bluetooth on your device
4. Press “Play/Pause Button” on WOOFit
JAM for 3 seconds
5. Choose WOOFit JAM in the
Bluetooth settings on your device
6. Start playing music from your device
7. Nod your head and dance :-)
2
UK
BLUETOOTH MUSIC RECEIVER
Connect WOOFit JAM to your
pricey Hi-Fi system as a Bluetooth
receiver and revive it with access
to all music available online.
Clever!
GREAT SOUND
You will not believe your own ears
the rst time you listen to WOOFit
JAM! All that sound coming from
such a small speaker? Yes, WOOFit
JAM sounds great!
MICROPHONE
Yes, WOOFit JAM does give out a
great sound, but you can actually
also use it as a microphone.
Connect WOOFit JAM to your
phone via Bluetooth and use it for
being on the phone hands free in
your car.
VOICE ECHO CANCELLATION
WOOFit JAM is great for hands-
free calling! The software voice
echo cancellation enhances the
sound quality and allows you to
make crystal clear hands-free calls.
WOOFit JAM features
3
UK
NFC
Connecting made real easy! Just
touch the speaker with your NFC-
enabled mobile device and you are
ready to play.
RECHARGEABLE
Naturally, WOOFit JAM is
rechargeable so you can take it
anywhere – to the bathroom, the
bed, the boat or Barcelona. Let it
rip for 15 hours for each charge.
STEREO PAIRING
Pair two WOOFit JAM for a HUGE
sound – in stereo! Everything is
connected wirelessly. Get ready
for a great left-and-right stereo
listening experience.
WIRELESS
No strings attached! WOOFit JAM
plays wireless music from all units
via Bluetooth.
4
UK
Power indicator
Connection indicator
Volume down
Button
PREV Button NEXT Button
Play/Pause/
Pairing
Button
M (mode) Button Phone Button
Microphone
Motion
sensor area
Volume up
Button
Power Button
Mini jack
socket
USB socket
AUX IN
socket
- Power indicator
- Connection indicator
- Volume buttons
- PREV/NEXT button
- Play/Pause/Pairing button
- M (mode) button
- Phone button
- Microphone
- Motion sensor area
- Power Button
- AUX IN socket
- USB socket
- Mini jack socket
5
UK
Buttons
Power Button
Long press “Power Button” to turn the
system on/off. The “Power Indicator”
(blue) lights up when the system is
turned on.
Volume Buttons (-/ +)
Adjusts the volume. When WOOFit
JAM is in Bluetooth mode, there will be a
“Beep” sound alert at a maximum volume.
When it is in AUX mode, there is no
“Beep” sound alert.
PREV/NEXT Button
While in Bluetooth mode, press “PREV/
NEXT Button” for previous/next song.
Play/Pause/Pairing Button
While in Bluetooth mode, short press
this button for Play/Pause.
Long press this button for rst use of
Bluetooth Pairing.
M (mode) Button
Press “M Button” for Bluetooth/AUX
mode.
Phone Button
When connected via Bluetooth, phone
calls can be answered simply by pressing
the “Phone Button”. Long press “Phone
Button” to reject the call. During phone
calls pressing the button switches your
call to your phone. Pressing the button
again switches the call back to the
WOOFit JAM. 6
UK
Connections
MINI JACK socket
Connects headphones to the speaker.
When you connect headphones the
sound will reduce immediately, but within
2 seconds, the sound level will increase
gradually to protect against hearing
damages.
AUX IN socket
Connects to the headphone socket of a
computer, portable audio device, etc. or
even your home stereo. If connected to
your home stereos AUX IN, you can play
sound wirelessly from your device (on
your home stereo system).
USB socket
Charges the device by the USB cable.
This socket is used for charging only,
Audio signal, etc. cannot be sent via this
socket.
7
UK
Functionality
Power source
Turn WOOFit JAM on/off
Long press “Power Button” to turn
WOOFit JAM on/off. When turned on
the blue “Power indicator” light is on.
Charge the device
Firmly connect the USB jack on the back
of the device via the USB cable, and
plug the USB cable to your computer or
adaptor. Charging begins automatically,
whether the system is turned on or off.
The charging status is displayed on the
device (the indicator light will show RED.
Once the device is fully charged, the light
will go out). It takes two hours to charge
the speaker.
Motion sensor
When motion is registered in the
“Motion sensor area” all buttons light
up. This makes it possible to operate the
device in darkness/low light.
8
UK
Connect to WOOFit JAM
Bluetooth connection
1. Press “Play/Pause Button” for
3 seconds. When the indicator
light shows fast blue and red ash
alternatively, the WOOFit JAM enters
pairing mode. (Notes: Pairing mode is
cancelled after 3 minutes, along with
a “Beep” sound. If you want to enter
into pairing mode again, start over
from step 1). As soon as your device
is paired with the WOOFit JAM the
indicator light turns ashing blue.
2. Perform the pairing procedure
on the Bluetooth device to detect
the system. A list of detected
devices appears on the display of
the Bluetooth stereo audio source
device. This system is displayed as
“WOOFit JAM”. If “WOOFit JAM”
is not displayed, repeat from step 1.
(Note: When pairing, be sure to keep
both Bluetooth devices within 1 meter
range of each other.)
3. Select “WOOFit JAM” shown in the
display of the Bluetooth device.
4. Option: If Passcode * input is required
on the display of the Bluetooth device,
input “0000”. (Note: Passcode may
be called “Passkey”, “PIN code”, “PIN
number” or “Password”)
5. Start the Bluetooth connection from
the Bluetooth device. The system
remembers the device as the last
connected device. Some Bluetooth
devices may connect with the
system automatically when pairing is
complete.
9
