C4 Training courseware

PRODUCTS INTRODUCTION

OPERATION INSTRUCTIONS

MAINTENANCE INSTRUCTIONS

IMPROVED POINTS INTRODUCTION

01

02

03

04

CONTENT

PRODUCTS INTRODUCTION

OPERATION INSTRUCTIONS

MAINTENANCE INSTRUCTIONS

IMPROVED POINTS INTRODUCTION

01

02

03

04

Product introduction –general introduction

C4 series, supper high speed automatic overlock

machine ,is iterative product of JK-900E，not

only inherit the mechanical advantage of JK-

900E，but only use non-shell hall servo motor 、

integrated control box、three proofing sensor、

needle bar avoiding oil leakage technology、USB

technology and several other new

technology,voice guide，bigger sewing range，

more stable sewing performance，more beautiful

stitch，better machine appearance、novelty、

compact structure ，only need to connect with

power ,then start sewing easily。

C4 - 4 - M 0 3 / 3 3 3

Product introduction-Type plate introduction

Feed dog teeth space distance1.6mm

Feed dog teeth column number

Upper looper stroke6X6

Medium-heavy material

Normal seam

for medium –heavy material

Thread number

Product model

Product Introduction-technical specifications

Type/Name C4 The Fastest Automatic Overlock

Machine

Highest Speed 7000rpm/min

Max Length(mm) 0.8-4.8

Thread Wideth（mm）1.5-8.0

Differential 0.7-2.0

Presser

Foot Height（mm

）

5.0-7.0

Needle Type DCX27

Needle Bar Height （general）10.4mm/12mm（heavy）

Needle Bar Stroke （general）24.5mm/26mm（heavy）

Product Introduction-various models

Parameters of Various models C4

Code Model Needle

Type

Needle

Number

Thread

Type

Gauge

(mm)

Stitch

Wideth

(mm)

Stitch

Length

mm)

Differe

ntial

Presser

Foot

(mm)

Speed

（S.p.m）

pneu

mati

c

KS

1 C4-02×250（Pocket ）14# 2 4 5 24 3.8 0.7-2 5 7000 √

2 C4-3-02/233（general）11# 1 3 —— 4 3.8 0.7-2 5 7000 √√

3 C4-3-12/233（hem）11# 1 3 —— 4 3.8 0.7-2 5.5 7000 √√

4 C4-3-32R2/223（pearl stitch）9# 1 3 —— 1.5 3.8 0.7-2 5 7000 √√

5 C4-3-82/233/P （pneumatic

backstitch）11# 1 3 —— 4 3.8 0.7-2 5 7000

6 C4-4-83/323/P （pneumatic

backstitch）11# 2 4 2 4 4.2 0.7-2 5.5 7000

7 C4-4-M03/333（General）11# 2 4 2 4 4.6 0.7-2 6 7000 √√

8 C4-4-M03/333/H/M（Heavy）11# 2 4 2 4 4.6 0.7-2 6 7000 √√

11 C4-5-53/233（3×5）14# 2 5 3 5 3.8 0.7-2 5 7000 √

12 C4-5-03/233（5×5）14# 2 5 5 5 3.8 0.7-2 5 7000 √√

13 C4-5-03/333（3×4）14# 2 5 3 4 3.8 0.7-2 5 7000 √√

14 C4-5-A04/435（Super heavy）19# 2 5 5 6 5 0.8-1.5 7 7000 √

15 C4-6-03/333（6 thread）11# 3 6 3×2 4 3.8 0.7-2 5 7000 √√

LOREM IPSUM DOLOR

8

Content

Product introduction

Operation instruction

Maintenance instruction

Improved point introduction

01

02

03

04

Improved point introduction

New Outlook Design

New Visual Hammer

New Strip Technology

New Panel

Easy to operate

Integrated control

box, easy to use

USB upgrade

Improved point introduction
