Itec C31DUALKVMDOCKPD Manuel utilisateur

USB-C KVM Dual Display Docking Station

with Power Delivery

2x USB-C 3.2 Gen. 1 / 1x USB-A 3.0 Gen. 1 (BC 1.2) / 2x USB-A 3. Gen. 1

1x HDMI / 1x DisplayPort / 1x Gigabit LAN / 1x Audio/Mic Jack

User guide • Gebrauchsanweisung • Mode d’emploi

Manual de instrucciones • Manuale • Uživatelská příručka

Instrukcje obsługi • Užívateľská príručka • Vartotojo vadovas

Handleiding

P/N: C31DUALKVMDOCKPD

Please read the entire instruction manual carefully. Detailed

manual is available on our website www.i-tec.pro/en/ in the

tab „Manuals, drivers“. In case of any issues, please contact

our technical support at: [email protected]om

Bitte lesen Sie das gesamte Handbuch sorgfältig durch.

Die ausführliche Gebrauchsanweisung ist auch auf unserer

Webseite www.i-tec.pro/de/ unter „Benutzerhandbücher,

Treiber“ bei diesem Produkt zu nden. Wenn Sie Probleme

haben, kontaktieren Sie bitte unser Support-Team unter:

[email protected]

Veuillez lire attentivement le manuel dans son intégralité. Un

manuel détaillé est disponible sur notre site

www.i-tec.pro/fr/ sous l’onglet «Manuels, pilotes». Si vous

avez des problèmes, veuillez contacter notre équipe support

à [email protected]

Por favor, lea atentamente todo el manual. El manual

detallado está disponible en nuestro sitio web,

www.i-tec.pro/es/ bajo la pestaña “Manuales y

controladores” de este producto. Si tiene algún problema,

póngase en contacto con nuestro equipo de soporte en

[email protected]

Leggere attentamente tutto il Libretto d’uso. Il Libretto d’uso

è a disposizione anche sulla scheda “Manuali e strumenti”

del nostro sito web: www.i-tec.pro/it/. In caso di problemi

rivolgersi al supporto tecnico: [email protected]

Prosíme o pečlivé přečtení celého manuálu. Podrobný

manuál je k dispozici na našem webu www.i-tec.pro v záložce

„Manuály, ovladače“ u tohoto produktu. V případě problémů

se můžete obrátit na naši technickou podporu:

[email protected]

Upewnij się, że uważnie przeczytałeś instrukcji obsługi.

Szczegółowy podręcznik jest dostępny na naszej stronie

internetowej www.i-tec.pro/pl/ w zakładce “Instrukcje,

sterowniki”. W razie jakichkolwiek problemów, skontaktuj się

z naszym serwisem pod adresem:

[email protected]

Prosíme o dôkladné prečítanie celého manuálu. Podrobný

manuál je k dispozícii tiež na našom webe www.i-tec.pro

v záložke „Manuály, ovladače“ pri tomto produkte. V prípade

problémov sa môžete obrátiť na našu technickú podporu:

[email protected]

Prašome įdėmiai perskaityti visą vadovą. Išsamų vadovą

galite rasti mūsų svetainėje www.i-tec.pro/en/ šio produkto

skyrelyje „Manuals, drivers“. Iškilus problemoms galite

susisiekti su mūsų technine pagalba:

[email protected]

Wij vragen u vriendelijk om de volledige handleiding zorgvuldig

door te lezen. Een gedetailleerde handleiding van dit product

is beschikbaar op onze website www.i-tec.pro/nl/ onder

het tabblad “Handleidingen en drivers”. Mochten er zich

problemen voordoen kunt u contact opnemen met ons

supportcenter via [email protected].

ENGLISH.........................................................06–23

DEUTSCH........................................................24–41

FRANÇAIS.......................................................42–59

ESPAÑOL................................................... .....60–77

ITALIANO.........................................................78–95

ČESKY........................................................ ...96–113

POLSKI........................................................114–131

SLOVENSKY................................................132–149

LIETUVOS.................................................. .150–167

NEDERLANDS.............................................168–185

WEEE...........................................................186–187

Declaration of Conformity..........................188–189

FCC.......................................................................190

USB-C Dual Display Docking Station

with Power Delivery

www.i-tec.pro/en

6 |

i-tec USB-C Dual DP Display Dock with PD 65W/100W

ENGLISH

GLOSSARY OF TERMS

• Interface / port / connector / input / slot - the place where two devic-

es are physically connected.

• Controller - a semiconductor component (called a chipset) in

a notebook/tablet that ensures the operation of one of the ports.

•USB-C / USB Type-C - is a new symmetrical connector and stand-

ard introduced by USB-IF in its USB 3.1 specication. Windows 10

(Microsoft), macOS X (Apple) and Chrome OS and Android

(Google) introduced native support for this connector. It enables fast-

er charging, power, so-called dual-role (not only host but also guest),

support for so-called alternative modes - Alt Mode (DisplayPort, MHL,

Thunderbolt 3, Power Delivery) and error notication via the device

Billboard.

•USB 3.2/USB 3.1/3.0/2.0 - standard for USB interface/port for con-

necting various USB devices. Various USB devices can be connected

to the docking station or adapter using the USB Type-A interface.

The USB Type B port is used to connect the dock or adapter to

a laptop/tablet.

•HDMI/Display Port - A standard for a digital graphics interface/port

used to connect monitors and other graphic display devices.

• LAN (Local Area Network) - local computer network, now the most

common is the so-called Ethernet, which reaches a theoretical trans-

fer rate of up to 1 Gbit/s at the docking station - the designation

GLAN / RJ-45.

•Audio - a term for an audio input (microphone) or output device

(headphones/speakers).

• Switch Jack- Designation of the port/jack for connecting a special

button.

Quick Start

| 7

ENGLISH

CONNECTING A SPECIAL BUTTON TO THE DOCKING STATION:

• Connect the 3.5mm jack to the 3.5mm port on the back of the dock

IN CASE OF A PROBLEM WITH THE BUTTON CONNECTION:

• Make sure the button is connected correctly (don‘t be afraid to use

a lot of force, the button must be pushed in to the stop)

• In some cases it is necessary to rotate the jack to the correct position.

• If the button is inserted correctly, the input can be changed with this

button, or the docking station can be switched off and on with this

button.

DOCKING STATION SPECIAL BUTTON FUNCTION:

An external button connected to the rear 3.5mm switch port/jack can be

used to:

1. To turn the docking station off and on (by long pressing the button).

2. Switching between inputs PC1 and PC2 (by short press of a button).

THE FUNCTION BUTTON ON THE TOP OF THE DOCKING STATION:

The button on the top of the docking station can be used to:

1. To turn the docking station off and on (by long pressing the button).

2. Switching between inputs PC1 and PC2 (by short press of a button).

SPECIFICATIONS

• 2x USB-C port for connection to a laptop or device with USB-C, USB4

or ThunderboltTM 3/4

• Power: PC1 port - up to 100W (additional USB-C power adapter is

required to power through this port)

• PC2 port - up to 65W

• Docking station technology: USB-C (MST)

• Video ports: 1x DisplayPort, 1x HDMI

8 |

i-tec USB-C Dual DP Display Dock with PD 65W/100W

ENGLISH

Resolution :

• USB-C/USB4/Thunderbolt™ 3/4 with DisplayPort 1.4 support without

DSC support

• 1 monitor - 1x DP or 1x HDMI - up to 4K/60Hz

• 2 monitors - 1x DP + 1x HDMI - up to 2x 2560×1440/60Hz

• USB-C/USB4/Thunderbolt™ 3/4 with DisplayPort 1.2 support

• 1 monitor - 1x DP or 1x HDMI - up to 4K/30Hz

• 2 monitors - 1x DP + 1x HDMI - up to 2x 1920×1080/60Hz

• 2x USB 3.2 Gen 1 (5Gbps)

• 1x USB 3.2 Gen 1 (5Gbps) with fast charging support (BC 1.2)

• 1x USB-C power only (power pass-through for PC1 port)

• 2x USB-C 3.2 Gen 1 (5Gbps) with fast charging support (BC 1.2)

• 1x Ethernet GLAN RJ-45 port (ASIX AX88179)

• 1x 3.5mm audio combo jack

• 1x 3.5mm switch jack to connect a special external switch (this button

can be used to turn the docking station on and off and to switch the

input between PC1 and PC2)

• 1x power input (20V/6A)

• Power button to turn the docking station on/off and switch between

inputs

• LED indication (indicating active input and docking station power on)

• Kensington lock support

• USB-C cable (100 cm)

• OS: Windows 10, 11, macOS, Android, Chrome OS, Linux and iPadOS

• Product dimensions 185 x 79 x 28 mm

• Product weight: 265g

Quick Start

| 9

ENGLISH

DESCRIPTION

Front panel:

13.5mm combo jack

22x USB-C 3.2 Gen 1

3USB 3.2 Gen 1 with fast charging support (BC 1.2)

4Led indication

5Button to turn the docking station on and off or to switch between

PC1 and PC2 inputs

10 |

i-tec USB-C Dual DP Display Dock with PD 65W/100W

ENGLISH

Back panel:

6. Kensington lock

7. Power input (20V/6A)

8. 2x USB-C port for connection to laptops or devices with USB-C,

USB4 or ThunderboltTM 3/4

9. 3.5mm switch jack to connect a special external switch (this

button can be used to turn the docking station on and off and to

switch the input between PC1 and PC2)

10. 1x DisplayPort

11. 1x HDMI

12. GLAN RJ-45 Port (ASIX AX88179)

13. 2x USB 3.2 Gen 1

14. USB-C Power delivery passthrough port to power the connected

device in the PC1 port

6910 11 12 13 14
