ION PRO GLOW EXPRESS Manuel utilisateur

Tap or click

for technical

support.

ionaudio.com/support

User Guide

English

PRO GLOW

™

EXPRESS

ION Audio Pro Glow™ Express User Guide 3

Thank you for purchasing the Pro Glow™ Express. At ION, your entertainment is as important

to us as it is to you. That’s why we design our products with one thing in mind—to make your

life more fun and more convenient.

Box Contents

Pro Glow™ Express

IEC320 C13 Power Cable (5 ft / 150 cm)

Microphone with cable (8.2 ft / 250 cm)

Quickstart Guide

Support

For the latest information about this product (documentation, technical speciﬁcations, system

requirements, compatibility information, etc.) and product registration, visit

ionaudio.com

For additional product support, visit

ionaudio.com/support

Quick Start

1. Make sure all items listed in the Introduction > Box Contents

are included in the box.

2. Read the Safety & Warranty Manual before using the product.

3. Study the Setup > Connection Diagram

4. Make sure all input devices (e.g. microphones, CD players, or digital media players) are

turned o with their volume settings set to “zero.”

5. Connect all devices as hown in the Connection Diagram.

6. Switch everything on in the following order:

a. Audio input devices (e.g. microphone, instruments, CD players)

b. Pro Glow™ Express

7. When you are ﬁnished using Pro Glow™ Express, switch everything o in the following order:

a. Pro Glow™ Express

b. Audio input devices

INTRODUCTION

ION Audio Pro Glow™ Express User Guide 4

Stand Mounting

Note: Speaker stand not included, sold separately.

1. Fully extend the speaker stand tripod legs on a ﬂat, stable surface.

2. Raise the mounting pole up to the appropriate height needed and tighten the side

adjustment knob.

3. Insert the pin into the bottom pin-hole so the mounting pole stays at your set height.

4. On the Pro Glow™ Express, adjust the bottom knob counter-clockwise so the screw is not

blocking the opening.

5. Line up the Pro Glow™ Express mounting hole with the speaker stand pole and place on

the pole.

6. Tighten the mounting knob clockwise on Pro Glow™ Express to secure it to the pole.

SETUP

235

ION Audio Pro Glow™ Express User Guide 5

Connection Diagram

Tablet, etc.

USB drive

Smartphone

(charging)

Power

Microphone

POWER

OFF

AUX IN CLIPPWR

MIC IN

PUSH TO SELECT

POWER

OFF

ION Audio Pro Glow™ Express User Guide 6

Rear Panel

Click a control below to jump to that section.

1. Display

This screen shows information relevant to the current operation on Pro Glow™ Express.

Note: The Display comes with a plastic protector on it. Remove this for optimal viewing.

FEATURES

POWER

OFF

AUX IN CLIPPWR

MIC IN

PUSH TO SELECT

POWER

OFF

ION Audio Pro Glow™ Express User Guide 7

2. Control Knob

Push this knob to cycle between the following controls, as indicated on the Display, and

then turn the knob to adjust the selected control:

•VOL: Adjusts the overall main volume of the loudspeaker (0–30).

•MIC: Adjusts the microphone input volume, independently of the other channels (0–

30).

•SOURCE: Adjusts the source volume (Bluetooth, AUX, or USB), independently of the

Mic channel (0–30).

•ECHO: Adjusts the amount of echo eect on the microphone (0–10).

•LOW: Increases or decreases the low frequency EQ for all channels (-12 – 0 – 12).

•HIGH: Increases or decreases the high frequency EQ for all channels (-12 – 0 – 12).

If the Control Knob is not moved for ﬁve seconds, the function will return to VOL.

Press and hold the Control Knob for ﬁve seconds to restore the default settings.

Note: For the best sound quality, set your input source volume to 100% and use the Source

and Main Volume control of the speaker to adjust the volume.

See Operation > Using the Control Knob for more information.

3.Previous Button

Press this button to return to the start of the current Bluetooth or USB track. Press the

button again within one second to skip to the previous track.

4.Next Button

Press this button to skip to the next Bluetooth or USB track.

5.Play/Pause Button

Press this button to start and stop Bluetooth or USB audio.

Press and hold this button to enable or disable the voice prompts.

6.Stereo-Link™ / Repeat Button

Press and hold this button to start stereo-linking to another Pro Glow™ Express. See

Operation > Linking Two Speakers for more information.

In USB mode, press this button to change the playback mode. See Operation > USB Mode

for more information.

7.Source Button

Press this button to cycle between Bluetooth, Aux, and USB modes. The current mode will

be shown on the Display.

ION Audio Pro Glow™ Express User Guide 8

8. Lights Button

Press this button to cycle between the ﬁve light modes, or to turn the lights o. See

Operation > Light Modes for more information.

9.USB Charge/Playback Port

You can use this port for charging the USB device, such as a tablet or smartphone. To

charge a device that is streaming music via Bluetooth, pause the music ﬁrst and then wait

for it to reconnect after the USB cable (not included) is inserted.

You can also connect a USB ﬂash drive here to play music. See Operation > USB Mode for

more information.

10. Mic In

Connect the included microphone to this input using the 1/4" (6.35 mm) cable.

11. Aux In

Connect a CD player, MP3 player, or other audio source to this 1/8” (3.5 mm) input.

12. Power LED

This LED will be lit when the unit is powered on.

13. Clip LED

This LED will ﬂash red if the signal from the input jacks or audio source is clipping

(distortion from an overly loud signal). If this happens, decrease the main volume or the

source volume for the Aux or Mic Inputs (if a loud device is plugged into either) using the

Control Knob.

14. Power Switch

Turns Pro Glow™ Express on or o. When the power is on, the Power LED will be lit green.

15. Power Cable Input

Connect the included power cable here to power the unit.

ION Audio Pro Glow™ Express User Guide 9

Using the Control Knob

The Control Knob defaults to controlling the Main Volume for all channels. Press the Control

Knob to toggle through dierent functions. Rotate the Control Knob to change the selected

setting:

Press Control Rotate

1x MIC Adjust mic volume

2x SOURCE Adjust source (AUX, Bluetooth, USB) volume

3x ECHO Adjust mic echo

QEwoltsujdAWOLx4

QEhgihtsujdAHGIHx5

6x VOL Adjust main volume

If there is no activity on the Control Knob for 5 seconds, the function will go back to main

volume.

To factory reset the speaker to default settings, hold down the Control Knob for 5 seconds.

The speaker will power cycle and the reset will be successful.

OPERATION

1 2

ION Audio Pro Glow™ Express User Guide 10

Pairing a Bluetooth® Device

1. Turn on your Bluetooth device.

2. Power on Pro Glow™ Express. When the unit is ﬁrst turned on, it will automatically enter

Bluetooth pairing mode. If necessary, press the Source button to select Bluetooth mode. If

voice prompts are enabled, you will hear “Bluetooth Pairing.”

3. Navigate to your Bluetooth device’s setup screen, ﬁnd “PRO GLOW EXPRESS” and

connect. If voice prompts are enabled, you will hear “Bluetooth Connected.”

Note: If your Bluetooth device prompts for a pairing code, enter “0000”.

To disconnect the paired Bluetooth device, turn o or disconnect from your Bluetooth

device.

Tip: If you would like to disable (or enable) the voice prompts, press and hold the Play / Pause

button for ﬁve seconds.

PRO GLOW™ EXPRESS

1 - PRESS 2

ION Audio Pro Glow™ Express User Guide 11

Linking Two Speakers

If you would like to play music from a Bluetooth device, you can ﬁrst “link” two Pro Glow™

Express speakers together in order to listen to your music in stereo. One Pro Glow™ Express

will serve as the left speaker and the other will serve as the right speaker.

To link two Pro Glow™ Express speakers together:

1. Press and hold the Stereo-LinkTM / Repeat button on both speakers to enter Stereo-Link™

mode. You will hear a tone, and the word LINK will ﬂash on each speaker’s Display while

they search for each other. Once a link has been established, the word LINK will remain on

the Display.

Note: The linking process can take up to a minute to complete. The closer the two speakers

are to each other, the quicker the link is established.

2. Once the two speakers are linked, press and release the Source button on either speaker

to select Bluetooth mode and begin the Bluetooth pairing process. The speaker you use

for Bluetooth pairing will serve as the primary speaker. On its Display screen, the Bluetooth

icon will ﬂash to indicate that Bluetooth pairing is in process.

3. Navigate to your Bluetooth device’s setup screen, ﬁnd Pro Glow™ Express and connect.

When your Bluetooth device is connected, the Bluetooth icon will be lit solid on the primary

speaker’s Display, and you will be able to play audio from the Bluetooth device through

your two linked speakers.

To disconnect two speakers or cancel linking between the two, double press the Stereo-

LinkTM / Repeat button on either speaker.

Note: Pro Glow™ Express is not wireless link compatible with previous ION Audio Pro Glow™

models.

1 - PRESS & HOLD

(speaker 1)

2 - PRESS & HOLD

(speaker 2)
