ION PARTY BOOM PLUS Manuel utilisateur

User Guide

English

PARTY BOOM™ PLUS

Tap or click

for technical

support.

ionaudio.com/support

ION Audio Party Boom™ Plus User Guide 3

APPENDIX................................................................................ 20

Technical Speciﬁcations...................................................................................... 20

Trademarks & Licenses ..........................................................................................21

ION Audio Party Boom™ Plus User Guide 4

Thank you for purchasing the Party Boom™ Plus Speaker. At ION, your entertainment is as

important to us as it is to you. That’s why we design our products with one thing in mind—to

make your life more fun and more convenient.

Note: Before you ﬁrst use the product, please fully charge the batteries. Your unit was

purposely shipped with a reduced battery charge to ensure safe transit. For optimal charging,

power o the speaker while charging.

Use the included power cable to connect the unit to a power outlet and let it charge for up to

6 hours. This helps ensure the longest life for your battery.

Box Contents

Party Boom™ Plus

IEC (C7) Power Cable (4.9 ft / 150 cm)

Microphone with cable (7.5 ft. / 230 cm)

Quickstart Guide

Support

For the latest information about this product (documentation, technical speciﬁcations, system

requirements, compatibility information, etc.) and product registration, visit ionaudio.com.

For additional product support, visit ionaudio.com/support.

INTRODUCTION

ION Audio Party Boom™ Plus User Guide 5

Charging and Battery Information

For the quickest charging time, power o Party Boom™ Plus and use the included IEC power

cable connected to a power outlet. A full charge can take up to 6 hours.

The lightning bolt icon on the display will light up when Party Boom™ Plus is

connected to a power source and charging. The battery icon will ﬁll to display the

battery life percentage. When charging is complete, the lightning bolt icon will

disappear, and the battery icon will be completely ﬁlled.

Rechargeable lead-acid batteries are the same type used in automobiles. As with your car

battery, how you use this battery has a signiﬁcant impact on its lifespan. With proper use and

treatment, a lead-acid battery can last for years. Here are some recommendations for getting

the longest life from the internal battery.

General

Usage

Fully charge the battery before using it.

Charge the battery completely after each use.

Storage For best product longevity, do not store at exceedingly hot (greater than

90°F/32°C) or exceedingly cold (less than 32°F/0°C) temperatures.

It is acceptable to leave your sound system plugged in. This will not overcharge

the battery.

If you leave the battery level low and do not charge it for 3 months, it may

permanently lose capacity.

Repair If the battery fails to charge, check your fuse near the power cable input. If your

fuse is intact and it still will not charge, contact ION Audio at ionaudio.com.

Disposal Bring the unit to a recycling center or dispose of in accordance with local

ordinances.

SETUP

ION Audio Party Boom™ Plus User Guide 6

Outdoor Use and Care

Though Party Boom™ Plus is water-resistant and able to tolerate splashing water, please

review the tips below to get the best performance from your Party Boom™ Plus:

•Bring Party Boom™ Plus indoors during extreme weather.

•Please do not place Party Boom™ Plus in standing water.

•Please do not connect the power adapter to a Party Boom™ Plus in a wet environment.

Make sure the power input, power adapter, and power outlet are all completely dry before

making any connections.

•WARNING: Keep any non-water-resistant devices (phones, music players, etc.) in a dry

place where they will not be aected by water and cause a risk of electric shock.

ION Audio Party Boom™ Plus User Guide 7

Front Panel

Click a control below to jump to that section.

1. Display

This screen shows information relevant to the current operation on Party Boom™ Plus.

Note: The Display comes with a plastic protector on it. Remove this for optimal viewing.

2.Previous / Next Buttons

In FM mode, press these buttons brieﬂy to go to the previous or next station. Press and

hold these buttons to seek the previous or next strong station.

In Bluetooth and USB modes, press the Previous or Next button to go to the beginning of

the current track or skip to the following track, respectively. Press the Previous button

again within one second to skip to the previous track.

FEATURES

15 8

4 7

110

ION Audio Party Boom™ Plus User Guide 8

3. Play/Pause / Presets Button

Press this button to start and stop Bluetooth or USB audio.

In FM mode, press this button to save and recall radio presets. See Operation > Using the

Radio for more details.

4.Bluetooth® Button

Press this button to enter Bluetooth pairing mode. When connected to a Bluetooth device,

press this button to disconnect a paired device and re-enter pairing mode. Once

disconnected, press this button to re-pair to the last connected device. See Operation >

Pairing a Bluetooth® Device to learn how to connect a Bluetooth device.

Press and hold this button to enable or disable voice prompts.

5.Stereo-Link™ / Repeat Button

Press and hold this button to start stereo-linking to another Party Boom™ Plus. See

Operation > Linking Two Speakers for more details.

In USB mode, press this button to change the playback mode. See Operation > USB Mode

for more details.

6.Source Button

Press this button to cycle between FM, USB, and Aux modes. The current mode will be

shown on the Display.

7.Lights Button

Press this button to cycle through the 10 light modes. See Operation > Light Modes for

more information.

8.BOOM Button™

Press this button to simultaneously enhance the bass EQ and volume and activate a light

show that pulses to the beat of the music.

9.EQ Button

Press this button to cycle through the Low, Mid, and Hi EQ frequencies. Then press the

VOL +/- buttons to adjust the EQ frequency settings from -12 to +12.

10. USB Charge/Playback Port

You can use this port for charging the USB device, such as a tablet or smartphone. To

charge a device that is streaming music via Bluetooth, pause the music ﬁrst and then wait

for it to reconnect after the USB cable (not included) is inserted.

You can also connect a USB ﬂash drive here to play music. See Operation > USB Mode for

more information.

ION Audio Party Boom™ Plus User Guide 9

11. Mic In

Connect a microphone into this into using a 1/4” (6.35 mm) cable. Press the MIC +/-

buttons to control the mic volume.

12. Mic +/- Buttons

Press these buttons to adjust the microphone volume.

13. Aux In

Connect a CD player, MP3 player, or other audio source to this 1/8” (3.5 mm) input.

14. Volume +/- Buttons

Use these buttons to raise and lower the volume of the Bluetooth, USB, radio, or aux input

from 0-30. Press and hold a button to raise or lower the volume quickly.

15. Power Button

Press and hold this button to turn Party Boom™ Plus on and o.

ION Audio Party Boom™ Plus User Guide 10

Rear Panel

Note: Pull the tab on the protective rubber panel to release it and access the rear panel port.

1. Power Input: Connect the included power cable here to charge the speaker.

ION Audio Party Boom™ Plus User Guide 11

Pairing a Bluetooth® Device

1. Turn on your Bluetooth device.

2. Turn on Party Boom™ Plus by holding down the Power button for 2 seconds. When the unit

is ﬁrst turned on, it will automatically enter Bluetooth pairing mode. If necessary, press the

Bluetooth button to select Bluetooth mode. The Bluetooth icon on the display will ﬂash to

indicate the speaker is ready to pair and you will hear “Bluetooth Pairing” if voice prompts are

enabled.

3. Navigate to your device’s Bluetooth setup screen, ﬁnd PARTY BOOM PLUS, and connect.

The Bluetooth icon will appear in the display, and if voice prompts are enabled, you will

hear “Bluetooth Connected”. If after 90 seconds if there is no connection, the speaker will

stop searching for a Bluetooth device and enter AUX mode.

Note: If your Bluetooth device prompts for a pairing code, enter “0000”.

To disconnect a paired device, do any of the following:

•Turn o Bluetooth from your device’s Bluetooth settings. The speaker will enter

Bluetooth pairing mode to make it available for another device.

•Press the Bluetooth button to disconnect and re-enter pairing mode.

Once you have disconnected, you will hear “Bluetooth Disconnected” if voice prompts are

enabled.

Tip: Press and hold the Bluetooth button to turn voice prompts on or o.

OPERATION

PARTY BOOM™ PLUS

1 - PRESS
