IOGear GUWH104 Manuel utilisateur

GUWH104

PART NO. M0426

Installation

Installation Guide

Wireless USB Hub

Welcome

Thank you for purchasing one of the most user-friendly Wireless USB devices on the market. IOGEAR’s

Wireless USB Hub is top of the line when it comes to Wireless USB connectivity, implementing the use of

Ultra-Wideband (UWB) to achieve data transfer speeds comparable to USB 2.0 without the need of wires

between peripherals and the computer.

To better serve you, IOGEAR offers an array of additional USB 2.0, USB 1.1, FireWire, KVM, and other

peripheral products. For more information or to purchase additional IOGEAR products, visit us at www.

IOGEAR.com

We hope you enjoy using your IOGEAR Wireless USB Hub, another ﬁrst-rate connectivity solution from

IOGEAR.

Table of Contents

Welcome 3

Introduction 5

Features 6

Requirements 7

Package Contents 8

Device Overview 9

Installation 10

Hardware Preparation 11

Software Installation 12

Driver Installation 16

Frequently Asked Questions 17

Technical Support 20

Limited Warranty 22

Federal Communications Commission

(FCC) Statement

Contact 24

Introduction

IOGEAR’s Wireless USB allows you to connect your USB peripherals and computer with all the ease and

speed of USB 2.0 without the use of USB cables and extenders between the PC and your Wireless USB

Hub. Gain all of the advantages of USB 2.0 without the hassle of wires cluttering up your workspace. Plug

your USB devices into the Wireless USB Hub and within seconds you have wireless access and control

over the devices with no delay, purely plug-and-play.

The Ultra-Wideband Hub provides the ability for in-room Wireless USB connectivity at distances of up to

30 feet. It offers a data transmission speed of up to 480 Mbit/s at distances of up to 3 meters.

Features

Wireless USB 2.0 speed through UWB medium•

Simple hardware interface•

Easy Installation has you connected in minutes•

Solid 3-year limited warranty•

Requirements

Available AC outlets in the room•

Available USB ports•

Software requires Windows and CD-ROM drive•

Package Contents

1 x Wireless USB Hub GUWH104

1 x Wireless USB Hub Antenna

1 x Wireless USB Hub Power Supply

1 x USB Type A to mini-B Cable

1 x Software CD (with Electronic Manual)

Device Overview

Side View:

Top View:

1. Host Selection button

2. Active Host LEDs

3. Power LED

The default and recommended setting is to operate in

Auto Association mode. In this mode, the Wireless USB Hub

will automatically connect to the Wireless USB Host Adapter.

The Host Selection button is used in Manual Association mode.

This mode is only needed if your Wireless USB Hub has already

been successfully associated with more than one Wireless

USB Host Adapter-PC combination. The Wireless USB Hub

can support up to three such associations. Set S2 to Manual

Association mode and then use the Host Selection button to

manually cycle through the three choices for which Wireless

USB Host Adapter-PC combination to connect to. Using this

button, you can force the Wireless USB Hub to connect to one

of three pre-associated PCs of your choosing.

HUB

ASSOC

ASSOC.

WIRED

WIRELESS

MANUAL

AUTO

4 5

4. Switch 1 (S1)

5. Switch 2 (S2)

S1 S2

Wired Wireless

(recommended)

Auto

(recommended)

Manual

Installation

Before we get started, please NOTE:

Do not place Wireless USB devices under direct sunlight or near high heat emitting devices;

Do not place Wireless USB devices near water or wet surfaces to avoid electric hazards;

Do not place Wireless USB devices on any moving or unstable surfaces;
