INVENTOR WF-60A1 Mode d’emploi
SMART PORT WI-FI FUNCTION
AIR CONDITIONING SYSTEMS
ENGLISH | ΕΛΛΗΝΙΚΑ | ROMANA | DEUTSCH
• USER’S & INSTALLATION MANUAL
• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ & ΕΓΚΑΤΑΣΤΑΣΗΣ
• MANUAL DE UTILIZARE & INSTALLARE
• INSTALLATIONSHANDBUCH BENUTZERHANDBUCH
3
● This manual gives detailed description of the precautions
that should be brought to your attention during operation.
● In order to ensure correct service of the smart port,
please read this manual carefully before using the unit.
● For convenience of future reference, keep this manual
after reading it.
4
CONTENTS
1. SAFETY PRECAUTION............................................................5
2. DOWNLOAD AND INSTALL APP...........................................7
3. INSTALLATION ACCESSORY .................................................8
4. INSTALLATION METHOD......................................................9
5. SPECIFICATION....................................................................15
6. USER REGISTRATION ..........................................................16
7. NETWORK CONFIGURATION. ............................................17
8. HOW TO USE APP ...............................................................29
9. SPECIAL FUNCTIONS...........................................................31
10. APP DECLARATION ...........................................................36
5
1
Read the safety precautions carefully before installing the unit.
Stated below are important safety issues that must be obeyed.
1. SAFETY PRECAUTION
Applicable system: IOS, Android.
APP cannot support all software versions. We will not be
help responsible for any issues occuring as a result of
incompatibility.
Note:
Wireless safety strategy
Smart kit only support WPA-PSK/WPA2-PSK encryption
and none encryption . WPA-PSK/WPA2-PSK encryption
is recommended.
6
2
CAUTION
• Please Check The Service Website For More Information.
• Smart Phone camera needs to be 5 million pixels or above
to make sure scan QR code well.
• Due to different network situation, sometimes, request
time-out could happen, thus, it is necessary to do network
configuration again.
Due to different network situation, control process may
return time-out sometimes. If this situation occurs, the
display between board and App may not be the same,
please do not feel confused.
•
NOTE:Company will not be liable for any issues and
problems caused by Internet, Wi-Fi Router and Smart
Devices. Please contact the original provider to get further
help.
7
3
2. DOWNLOAD AND INSTALL APP
QR Code A QR Code B
Caution: QR Code A and
QR Code B is only available
for downloading APP.
Android Phone users: scan QR Code A or go to google play,
search 'INVmate II' app and download it.
Iphone Users: scan QR Code B or go to App Store, search
'INVmate I
I
' app and download it.
8
4
3. INSTALLATION ACCESSORY
Don‘t install at the place which is covered with heavy oil, vapor
or sulfureted gas, otherwise, this product would be deformed
that would lead to system malfunction.
Select the installation location
Preparation before installation
1.Please confirm that all the following parts have been supplied.
2. Prepare the following assemblies on the site.
The connective wires group-1
1
2
3
4
5
3
1
M4X20 (For Mounting on the Wall)
1
6
3
1
No. Name Qty. Remarks
Smart port
Installation and owner’s manual
For Mounting on the Wall
Wiring Tube(Insulating
Sleeve and Tightening
Screw)
Qty.(embeded
into wall)
Screws
Wall plugs
No. Name Remarks
Specification
(only for reference)
Smart kit
1
1
1
See Fig.4-3
9
Applicable to WF-60A1 only
5
4. INSTALLATION METHOD
Fig 4-1
Fig 4-2
1.Wifi controller structure size figure
2.Wiring Principle Sketch:
red
black
yellow
brown
red
black
yellow
brown
Insert of the
mainboard CN40
Wifi control box Indoor unit mainboard
4-Core Shield Cable, the length
is decided by installation
-----------------------------------
-----------------------------------
-----------------------------------
-----------------------------------
10
4. INSTALLATION METHOD
Fig 4-4
Connect the male joint of the connective wires group-1 to
the mainboard，then connect the other side of the
connective wires group-1 to the 4-core shielding wire of
the smart port.(See Fig.4-3)
If want to extent the wire ,please use extension cord
(purchased separately) . (See Fig.4-3)
Fig 4-3
Mainboard
4-core shielding wire
3.Wiring figure
4.Remove the upper part of the smart port
Extension cord
(purchased separately)
The connective wires group-1
CN40
Slots
Insert a slot screwdriver into the slots in the
lower part of the smart port (2 places), and
remove the upper part of the smart port.
(Fig.4-4)
