PB20

Quick Start Guide

2-Inch Belt Printer

Equipped with a

Bluetooth

Qualified Module

by Socket

Communications

2 PB20 Printer Quick Start Guide

Packing List

Checktoensurethatyoureceivetheseitems:

SIntermecRPB20A0B140 Standard paper or PB20ALB140

Linerless paper model (2-inch Thermal Belt printer equipped

with Bluetooth* a qualified module by Socket Communica-

tions)

SOne roll of paper (in printer)

SBattery (installed)

SCompliance Statement

SWarranty Card

*Bluetooth is a trademark of Bluetooth SIG, Inc., U.S.A.

Common Accessories List

Cable Part Number

Data Cable (Hirose to RJ-45) 226-469-001

Power Adapters Part Number

ACWallCharger(orderpowercordseparately) 851-060-002

Cigarette Lighter Adapter, 2 Amp., 30 volt DC 852-052-001

Supplies Part Number

Replacement Li-Ion 900 mAhr Battery 320-082-021

Thermal paper 105’/roll, 50/case 816-034-022

Standard Paper Printer Cleaning Kit (2-inch printer)

Standard Paper Printer Cleaning Card (2-inch printer)

320-081-014

320-066-013

Linerless Paper (contact Supply Sales 1-800-255-6292)

PB20 Printer Quick Start Guide

Getting Started

Here are the main components of the IntermecRPB20 printer.

Cover Latch

Belt Clip

Computer to Printer Jack

Paper Advance

Charger Jack

Charge LED (red charging;

green complete)

4 PB20 Printer Quick Start Guide

Charging the Lithium Ion Batteries

SThe printer battery charges in about three hours.

LED Battery Indicators

LED State of Charge Action

Solid Red In Progress Waiting for green LED

Green Complete Remove Charger

Slow Red Flashing Low Temperature or

battery is disconnected

Change environment or

connect battery

Fast Red Flashing High Temperature Change environment

Slow Red and Orange

Flashing

Low Voltage Wait for solid red

Fast Red and Orange

Flashing

High Voltage Wait for solid red

Slow Orange Flashing Timeout Restart charge

Fast Orange Flashing Internal Error Remove battery to pow-

er down completely and

reconnect. Or unplug

from charging source,

wait 15-20 seconds, and

reconnect.

Beep Indicator

Number of Beeps Indicates

One Printer has come out of sleep mode

Two Printer is out of paper

Three Battery is low

One long beep No program in printer, only boot code

Determining Current Battery Power

To determine the current charge on the battery pack, print out a

self-test by pressing and holding the red self-test button for four

seconds. If the battery is good, you will see the abbreviation for

the word “GOOD” next to the Battery voltage print out.

This printer has a built in low battery detector. When the print-

er’s battery voltage is low, the printer beeps three times, indicat-

ing a Low Battery Warning. This only happens if the printer is

awake.

PB20 Printer Quick Start Guide

Paper Loading

Out of Paper

The PB20 Printer sounds two quick beeps when it runs out of

paper. If the printer is out of paper, the printer suspends opera-

tion until paper is present and the lever is down. The printer

continues to communicate with the mobile computer as long as

it does not “time out.” Once the printer restarts, it finishes the

rest of the print job from where it left off.

Removing Paper Core from your PB20 Printer

1Unsnap the latch and lift up the cover.

2Wrap your index finger around the empty paper core and pull

up. The paper rod will snap out.

3Remove the empty paper core and discard.

Paper Loading

Standard Paper

If you are using standard paper, you can load the paper auto-

matically or manually. Experiment to find out which method is

best for you.

Liner’ed Labels

If you are using liner’ed paper, it is best to use the manual paper

loading method.

Automatic Paper Loading

1Press the red self-test button to wake the printer.

2With the loose, clean edge of the paper coming from the bot-

tom of the roll, insert the edge of the paper between the roller

and the platen.

3Pushing the button again while the printer is awake causes

the mechanism to feed about one inch of paper.

4Insert the paper into the paper well with it resting on the pa-

per rod clips.

Manual Paper Loading

1Lift up the paper release lever. This takes the pressure off the

platen. Make sure you have a clean edge on the new paper

roll.

6 PB20 Printer Quick Start Guide

2Taketheedgeofthepaperandfoldit45degrees.

3Insert the tip of the paper between the roller and the platen.

4Push on the paper until the tip is peeking out the other side.

(If it seems too tight to insert the tip, lift up the paper release

lever and turn the gear to advance the paper).

5Grab the tip and pull it through until the paper is straight.

6Push down the paper release lever and insert the paper into

the paper well with it resting in the paper rod clips.

7Press the red button while the printer is on and it will feed

paper. You will need about two inches of paper coming out of

the mechanism.

8Lower the cover while placing the extra paper though the tear

bar.

9Close Latch Cover and tear off extra paper.

PB20 Printer Quick Start Guide

Printer Self-Test

Push the red button and hold for about four seconds to print a

self-test. Below is an explanation of the print-out.

Self-Test Print-out Explanation

Test Item Description

F/W Ver The internal software version (4.26 for printer, 1.09

or greater for card reader)

Timeout The seconds between printing and sleep mode.

Baud Rate The speed at which the printer receives data.

Parity Odd, Even, or None

Data Bits Matches with computer sending data to printer.

Handshake The way the printer handles flow control from host.

Burn Adj Amount of heat used to print on the thermal paper.

Beeper May be turned On or Off.

Batt Volt Current voltage of the battery pack.

Batt Temp Temperature of the battery.

Flash/RAM 1Mbor4MbFlash/1Mbor4MbRAM

Boot Version Boot sector firmware.

Prnhd Temp Temperature of print head (between 0 and 50 de-

grees).

Infrared Toggles between On and Off.

Device Name Type of device (i.e. 2t for 2 inch thermal printer)

Device Nickname Shows user name for printer.

Available Fonts “LOC” shows whether a font is Resident (R) or

Downloaded (D). “CPI” shows characters per inch.

“DESCRIPTION” describes the font. “NAMES”

give the “Easy Print” name, the Line Printer name,

and the hexadecimal equivalent of that name.

Available Graphics “LOC” shows whether a font is Resident (R) or

Downloaded (D). “CPI” shows characters per inch.

“DESCRIPTION” describes the graphic.

“NAMES” give the “Easy Print” name, the Line

Printer name, and the hexadecimal equivalent of that

name.

8 PB20 Printer Quick Start Guide

Self-Test Print-out Explanation (continued)

DescriptionTest Item

Available Bar Codes All supported barcodes are displayed. “DE-

SCRIPTION” describes the graphic. “NAMES”

give the “Easy Print” name, the Line Printer name,

and the hexadecimal equivalent of that name.

Card Reader Option Shows the current Card Reader configuration.

Battery Pack Removal

Note:Ensure that you have your ESD wrist strap

connected to the ESD static free mat before placing

yourprinteronthematandbeginremovingthebat-

tery pack.

UseonlythebatterypackdesignedforyourPB20

Printer. Use only the Intermec 900 mAh Li-Ion

battery p/n 320-082-021. Using any other battery

may present a risk of fire or explosion. The

battery used in your PB20 Printer may present a

fire or chemical burn hazard if mistreated. Do not

disassemble, heat above 212°F (100°C), or

incinerate.

1Remove the four screws securing the printer mechanism.

Screws (4)

(two on each side)

PB20 Printer Quick Start Guide

2Lifttheprintermechanismoutofthecase.Onewaytodo

this is to turn the printer case on its side and gently tap

the bottom of the case to remove the board assembly. Be

careful not to pull on the cluster of black wires running

fromtheinsideoftheprintercasetotheprintermecha-

nism assembly.

3Set the printer assembly down to view the underside of

printer mechanism and battery compartment.

Battery pack

compartment

Battery

pack cable

Printer assembly

wire cluster

10 PB20 Printer Quick Start Guide

4Remove the four screws securing the battery cover. Avoid

contact with the printer control board unless the board is

grounded.

Battery cover screws
