Intermec 6808 Manuel utilisateur

6808CR

40-Column

Printers

Quick Start Guide

6808CR 40- Column Printer Quick Start Guide

Packing List

Check to ensure that you receive these items:

Product Warranty Card

Compliance Statement

IntermecR

R6808CR Printer

p/n 320-081-007

6808CR 40- Column Printer Quick Start Guide

Common Accessories List

Printer Part Number

Swivel Belt Connector 320-081-022

Swivel Belt Connector Lock Male 320-081-023

Swivel Belt Connector Lock Female 320-081-024

Cables Part Number

Data Cable --RJ11F-- (RJ--11 R/A, coiled) 320-080-043

RJ--11F Adapter Cable – Right Angle 320-080-023

4000 Series and 6210 hand-held computer 226-044-001

6300 hand-held computer 216-996-001

RT1700 hand-held computer 216-994-001

Laptop download cable 320-066-032

70x/60x to 680x serial cable (RJ-11) 321-578-001

Power Adapters Part Number

AC Power Adapter (110 volt) 320-066-042

U.K. Power Supply 320-066-043

Europe Power Supply 320-066-044

Australian Power Supply 320-066-045

Cigarette Lighter Adapter, 5 Amp. 6 in. coiled 320-066-031

6808 Single Charger 852-051-001

Supplies Part Number

Replacement Li--Ion 1350mAhr Battery 320-081-021

Thermal Paper 130’/roll, 50/case 320-081-011

6808CR 40- Column Printer Quick Start Guide

Getting Started

Here are the main components of the IntermecR6808CR print-

er.

Charge indicator

Self-Test button

Battery packs

RJ-11 port

DC power jack

IrDA window (side panel)

Paper tear bar

Card reader

Read LED

6808CR Printer Components

Ribbon cartridge

Paper

release lever

6808CR 40- Column Printer Quick Start Guide

Before Using Your Printer For The

First Time

Remove the protective tab strips underneath the batteries.

They are placed there to keep your printer from self-charging

during shipment.

1. Lift the battery up before pulling on the tabs. If you pull

on the protective tabs without lifting the battery, the plas-

tic laminate covering on the tab strips could delaminate

and leave an almost invisible amount of polymer covering

on top of the battery contact pins. This prevents contact

with the battery and no charging occurs.

2. If your printer won’t charge after removing the protective

tabs, remove any residue in the battery pin area.

Printer Self Test

Push the red button and hold for about four seconds to print a

self test. Below is an explanation of the print--out.

Table 1 -1

Print-out Explanations

Self Test Description

F/W Ver The internal software version (4.26 for print-

er, 1.09 or greater for card reader)

Timeout The seconds between printing and sleep

mode.

Baud Rate The speed at which the printer receives

data.

Parity Odd, Even, or None

Data Bits Matches with computer sending data to

printer.

Handshake The way the printer handles flow control

from host.

Burn Adj Amount of heat used to print on the thermal

paper.

6808CR 40- Column Printer Quick Start Guide

Table 1-1(continued)

Print-out Explanations

Self Test Description

Paper 1or2ply

Beeper May be turned On or Off.

Batt Volt Current voltage of the battery pack.

Batt Temp Temperature of the battery.

Flash/RAM 1 Meg or 4 Meg Flash/ 1 Meg or 4 Meg RAM

Boot Ver-

sion

Boot sector firmware.

Prnhd

Tmp

Temperature of print head (between 0 and

50 degrees).

Infrared Set by the user to “Off”, “IrDA”, “ASK”,

“ASK/CRC”, “Direct”, “Direct CRC”,

“PULSE”, or “PULSE--CRC”

Device

Name

Shows type of device (i.e. 6808CR)

Device

Nickname

Shows user name for printer.

IrDA* Ver The 1.0 refers to the IrDA standard in use.

ThenexttwodigitsrefertoanyIRmodifica-

tions made to the configuration.

Available

Fonts

“LOC” shows whether a font is Resident (R)

or Downloaded (D). “CPI” shows characters

per inch. “DESCRIPTION” describes the

font. “NAMES” give the “Easy Print” name,

the Line Printer name, and the hexadecimal

equivalent of that name.

6808CR 40- Column Printer Quick Start Guide

Table 1-1(continued)

Print-out Explanations

Self Test Description

Available

Graphics

“LOC” shows whether a font is Resident (R)

or Downloaded (D). “CPI” shows characters

per inch. “DESCRIPTION” describes the

graphic. “NAMES” give the “Easy Print”

name, the Line Printer name, and the hexa-

decimal equivalent of that name.

Available

Bar Codes

All supported barcodes are displayed. “DE-

SCRIPTION” describes the graphic.

“NAMES” give the “Easy Print” name, the

Line Printer name, and the hexadecimal

equivalent of that name.

Card Read-

er Option

Shows the current Card Reader configura-

tion.

IrDA is a term that refers to the wireless standard of commu-

nication developed by the Infrared Data Association. Data is

transferred between devices using light; unseen infrared light.

To work properly, the IrDA ports on each device must be facing

each other and be no more than 36 inches away from each oth-

er. This allows the light signals to be properly sent and re-

ceived. Intermec portable printers are IrDA compliant. Devices

which are IrDA compliant provide quick and reliable wireless

communication. Any IrDA compliant computer can communi-

cate with any IrDA compliant printer, regardless of the other

features that each device offers.

Intermec printers come from the factory with the IrDA trans-

mission speed rate set at 38.4 kbits and no wait. This is the

recommended setting and allows the printer to receive and

print data at the same time. Using the Intermec configurator

(available from the Intermec Technical Support

1-800-755-5505), you can change the rates, but 38.4 kbits and

no wait are highly recommended transfer rate standards. Oth-

er speeds/settings are not as reliable.

6808CR 40- Column Printer Quick Start Guide

Charging the Lithium Ion Batteries

"The printer battery charges in about 3 hours.

"The charger only charges the printer battery and does not

charge the mobile computer’s battery..

Table 1 -2

LED Battery Indicators

LED State of Charge Action

Solid Red In Progress Waiting for green LED

Green Complete Remove Charger

Table 1 -3

Beep Indicators

Number of Beeps Indicates

One Printer has come out of sleep mode

Two Printer is out of paper

Three Battery is low

One long beep No program in printer, only boot code

Determining Current Battery Power

To determine the current charge on the battery pack, print out

a self test by pressing and holding the red self--test button for

four seconds. If the battery is good, you will see the abbrevi-

ation for the word “GOOD” next to the Battery voltage print

out. The 6808CR uses one or two batteries (VBATT1 and

VBATT2).

This printer has a built in low battery detector. When the

printer’s battery voltage is low, the printer beeps three times,

indicating a Low Battery Warning. This only happens if the

printer is awake.

Replacing the Battery

1. Open the cover and gently push the battery lock tabs

away while lifting the battery up.

6808CR 40- Column Printer Quick Start Guide

2. Insert the new battery by putting the non contact area of

the battery in first towards the center.

3. Push down on the battery near the battery lock tabs.

4. Charge the new battery.

Paper Loading

OutofPaper

The 6808CR Printer sounds two quick beeps when it runs out

of paper. If the printer is out of paper, the printer suspends op-

eration until paper is present and the lever is down. The print-

er continues to communicate with the mobile computer as long

as it does not “time out.” Once the printer restarts, it finishes

the rest of the print job from where it left off.

Removing Paper Core from your 6808 Printer

1. Unsnap the latch and lift up the cover.

2. Wrap your index finger around the empty paper core and

pull up. The paper rod will snap out.

3. Remove the empty paper core and discard.

Paper Loading

Standard Paper

If you are using standard paper, you can load the paper auto-

matically or manually. Experiment to find out which method is

best for you.

Linerless Labels

If you are using linerless paper, it is best to use the manual pa-

per loading method.

Automatic Paper Loading

1. With the loose, clean edge of the paper coming from the

bottom of the roll, insert the edge of the paper between

the roller and the platen.

2. Press the red self test button to wake the printer.

3. Push the button again while the printer is awake causes

the mechanism to feed about 1” of paper.

4. Insert the paper into the paper well with it resting on the

paper rod clips.

6808CR 40- Column Printer Quick Start Guide

Manual Paper Loading

1. Lift up the paper release lever. This takes the pressure off

the platen. Make sure you have a clean edge on the new

paper roll.

2. Take the edge of the paper and fold it 45 degrees.

3. Insert the tip of the paper between the roller and the plat-

en.

4. Push on the paper until the tip is peeking out the other

side. (If it seems too tight to insert the tip, lift up the pa-

per release lever and turn the gear to advance the paper).

5. Grab the tip and pull it through until the paper is

straight.

Paper Loading

6. Push down the paper release lever and insert the paper

into the paper well with it resting in the paper rod clips.

7. Press the red button while the printer is on and it will

feed paper. You will need about 2 inches of paper coming

out of the mechanism.
