Intermec 9189 Manuel utilisateur
9189 900MHz RF Gateway
User’s
Manual
P/N 066164-001
IntermecCorporation
6001 36th Avenue West
P.O. Box 4280
Everett, WA 98203-9280
U.S. service and technical support: 1-800-755-5505
U.S. media supplies ordering information: 1-800-227-9947
Canadian service and technical support: 1-800-688-7043
Canadian media supplies ordering information: 1-800-268-6936
Outside U.S. and Canada: Contact your local Intermec service supplier.
The information contained herein is proprietary and is provided solely for the purpose of allowing
customers to operate and/or service Intermec manufactured equipment and is not to be released,
reproduced, or used for any other purpose without written permission of Intermec.
Information and specifications in this manual are subject to change without notice.
1997 by Intermec Corporation
All Rights Reserved
The word Intermec, the Intermec logo, JANUS, IRL, TRAKKER, Antares, Adara, Duratherm,
Precision Print, PrintSet, Virtual Wedge, and CrossBar are either trademarks or registered
trademarks of Intermec Corporation.
Throughout this manual, trademarked names may be used. Rather than put a trademark (or )
symbol in every occurrence of a trademarked name, we state that we are using the names only in an
editorial fashion, and to the benefit of the trademark owner, with no intention of infringement.
Contents
iii
Contents
Before You Begin v
Warranty Information v
Safety Summary v
Warnings and Cautions vi
About This Manual vii
Other Intermec Manuals viii
9189 RF Gateway
Learning About the 9189 RF Gateway 1-3
Understanding the Gateway Components 1-4
Understanding the Gateway Status LEDs 1-5
About the RS-232 Port Interface 1-6
Supplying Power for the Gateway 1-6
Installing the Internal Battery Pack 1-6
Connecting the External Power Supply 1-7
About the Accessories 1-8
Carrying Case 1-8
Cables 1-9
Configuring the Gateway 1-10
Setting the RF Channels 1-11
Understanding the DIP Switches 1-12
Setting the DIP Switches 1-12
Restoring the Default Configuration 1-13
RF Channel 1-14
Baud Rate 1-14
Protocol 1-14
Data Bits 1-14
Address 1-15
Setting the Software Parameters 1-18
Using a Data Collection Device 1-18
Using Configuration Command Strings 1-19
Formatting Command Strings 1-19
Entering Command Strings 1-20
1
9189 900 MHz RF Gateway User’s Manual
iv
About 9189 Commands 1-21
Entering Configuration Mode 1-21
Exiting Configuration Mode 1-21
Default Configuration 1-21
Resetting Software Drivers 1-22
Listing the Current Configuration 1-22
Acknowledgment Delay 1-23
Channel Select 1-24
Downline POL/SEL Delay 1-25
Channel Search 1-26
Duty Cycle Percent 1-28
Duty Cycle Period 1-29
Loopback 1-29
Network ID 1-30
Repeat Count 1-31
Retry Limit 1-32
RFNC/BRU Address 1-33
RFPC Error Reporting Mode 1-35
Time Broadcast Receipt 1-36
Appendix A
ASCII Bar Code Labels A-3
Control Characters A-4
Symbols A-5
Numbers A-6
Uppercase Letters A-7
Lowercase Letters A-8
A
Before You Begin
v
Before You Begin
This section introduces you to standard warranty provisions, safety
precautions, warnings and cautions, document formatting conventions, and
sources of additional product information.
Warranty Information
To receive a copy of the standard warranty provision for this product, contact
your local Intermec sales organization. In the U.S. call (800) 755-5505, and in
Canada call (800) 688-7043. Otherwise, refer to the Worldwide Sales & Service
list that comes with this manual for the address and telephone number of your
Intermec sales organization.
Safety Summary
Your safety is extremely important. Read and follow all warnings and cautions
in this book before handling and operating Intermec equipment. You can be
seriously injured, and equipment and data can be damaged if you do not
follow the safety warnings and cautions.
Do not repair or adjust alone Do not repair or adjust energized equipment alone
under any circumstances. Someone capable of providing first aid must always
be present for your safety.
First aid Always obtain first aid or medical attention immediately after an
injury. Never neglect an injury, no matter how slight it seems.
Resuscitation Begin resuscitation immediately if someone is injured and stops
breathing. Any delay could result in death. To work on or near high voltage,
you should be familiar with approved industrial first aid methods.
Energized equipment Never work on energized equipment unless authorized
by a responsible authority. Energized electrical equipment is dangerous.
Electrical shock from energized equipment can cause death. If you must
perform authorized emergency work on energized equipment, be sure that you
comply strictly with approved safety regulations.
9189 900 MHz RF Gateway User’s Manual
vi
Warnings and Cautions
The warnings and cautions in this manual use the following format.
Warning
A warning alerts you of an operating procedure, practice, condition, or
statement that must be strictly observed to avoid death or serious injury to
the persons working on the equipment.
Avertissement
Un avertissement vous alerte d’une procédure de fonctionnement, d’une
méthode, d’un état ou d’un rapport qui doit être strictement respecté pour
éviter l’occurrence de mort ou de blessures graves aux personnes manupulant
l’équipement.
Caution
A caution alerts you to an operating procedure, practice, condition, or
statement that must be strictly observed to prevent equipment damage or
destruction, or corruption or loss of data.
Conseil
Une précaution vous avertit d’une procédure de fonctionnement, d’une
méthode, d’un état ou d’un rapport qui doit être strictement respecté pour
empêcher l’endommagement ou la destruction de l’équipement, ou l’altération
ou la perte de données.
Notes: Notes are statements that either provide extra information about a topic or
contain special instructions for handling a particular condition or set of circumstances.
Before You Begin
vii
About This Manual
All the information you need to install, configure, maintain, and troubleshoot
the 9189 RF Gateway is in this manual. This manual is written for the person
who will be installing and configuring this equipment. Many of the parameters
need to be set by the network administrator. This manual assumes that you are
familiar with your network and data communications.
Terms
•The Model 200 Controller is usually referred to as “the controller.”
•“JANUS devices” refers to all the readers and vehicle-mount computers
(VMC) in the JANUS family of data collection computers.
•“Data collection devices” refers to all the Intermec products including
JANUS devices that can communicate through a controller.
Conventions
This manual uses these conventions to explain how to input data from a bar
code and understand the special conventions for commands.
Input From a Data Collection Device Keypad
When you need to press keys on the data collection devices, they are illustrated
with icons that resemble the keys. For example, “press
e
” means you press
the key labeled “Enter” on the device keypad.
Input From a Bar Code
You can scan the bar codes listed in this manual to enter data or perform a
command. The bar code labels in this manual are printed in the Code 39
symbology. Each bar code includes the name and human-readable
interpretation. For example:
*$+*
Change Configuration
*$+*
Name
Bar Code (Code 39)
Human-readable
Interpretation
2020-50a
The asterisks (*) at the beginning and end of the human-readable interpretation
are the start and stop codes for a Code 39 bar code label. If you are creating bar
code labels with a bar code utility, it may automatically supply the asterisks as
the start and stop code, so that you only need to type the actual text of the
command. You can also create and print configuration labels and reader
command labels in Code 93, which has its own start and stop codes.
9189 900 MHz RF Gateway User’s Manual
viii
Commands
Command syntax is shown in the text as it should be entered. For example, to
see a list of directories on the JANUS device, type this command:
dir
If a command line includes both required and optional parameters, optional
parameters are enclosed in braces [ ].
Configuration commands use the convention data to indicate variables. Replace
the term data with one of the options listed with the command syntax. For
example, the configuration command for beep volume is BVdata where data can
be a number from 0 through 4.
Other Intermec Manuals
You may need additional information for working with the 9189 RF Gateway
in an Intermec data collection network. This list contains only some of the
manuals for Intermec’s more recent products that can communicate with this
Intermec 900 MHz equipment. To order manuals, contact your local Intermec
representative.
Manual Intermec Part No.
Data Communications Reference Manual 044737
Model 200 Controller System Manual 063439
Model 200 Controller Technical Reference Manual 064398
RF System/9180 Controller User’s Manual 054292
RF System/9185 Controller User’s Manual 056543
9181 and 9183 User’s Manual 066163
JANUS 2010 Hand-Held Computer User’s Manual 058426
JANUS 2020 Hand-Held Computer User’s Manual 059951
JANUS 2050 Vehicle Mount Computer User’s Manual 062874
