This integration guide explains how to integrate the IM11 module

into a computer or other device. It is written for the person who will

be integrating the module into any product that needs to be UHF

RFID-enabled.

Before you install and configure the module, you should be familiar

with Intermec RFID systems and how to implement them. You

should also be familiar with your network and general networking

terms, such as IP address.

Before You Begin

IM11 RFID Reader Module Integration Guide (Confidential) vii

Related Documents

This is a list of related Intermec documents:

•Basic Reader Interface Programmer Reference Manual

•Intermec RFID System Manual

The Intermec website at www.intermec.com contains our documents

(as PDF files) that you can download for free.

To download documents

1Visit the Intermec website at www.intermec.com.

2Click the Products tab.

3Using the Products menu, navigate to your product page. For

example, to find the 70 Series RFID Computer product page, click

Computers > Handheld Computers >70 Series RFID

Computers.

4Click the Manls tab.

If your product does not have its own product page, click Support >

Manls. Use the Product Category, the Product Family, and Product

to find your documentation.

Patent Information

There may be U.S. and foreign patents pending.

Regulatory Information

Note: Regulatory compliance of the end product is the responsibility

of the module integrator. Upon request, Intermec will provide

proprietary module documentation using non-disclosure agreements

(NDAs) or directly to the certifying agency.

Before You Begin

viii IM11 RFID Reader Module Integration Guide (Confidential)

Safety

The module is tested and compliant according to:

•CB Report IEC 60950-01 for international product safety

•FCC OET Bulletin 65, Evaluating Compliance with FCC Guidelines for

Human Exposure to Radio Frequency Electromagnetic Fields, for general

population/uncontrolled exposure when installed per Intermec

instructions using Intermec-approved antennas

•CENELEC EN50364/EN50357, European RF Exposure standard

Electromagnetic Compatibility

This module is certified according to:

•FCC Part 15/Industry Canada ICES-003 Class B digital emissions

•EN 301 489-1 and -3, European transmitter immunity

Radio Frequency Device Approval

By default, the module is configured for FCC transmission.

•EN 302-208 V 1.4.1 Declaration of Conformity

•FCC Part 15.247 (915 MHz band operation) Certification

•RSS-210 (915 MHz band operation) Certification

Recycling

The module incorporates principles for ease of disassembly to

facilitate recovery and recycling of printed circuit board assemblies

and base materials.

Restriction of Hazardous Substances (RoHS) Directive

The module complies with the RoHS Directive.

IM11 RFID Reader Module Integration Guide (Confidential) 9

About the IM11

The Intermec IM11 RFID Reader Module is designed for quick

integration into computers, printers, and any other products that

need to be RFID-enabled. The IM11 includes these features:

•Allows the RFID-enabled product to read and write to tags used in

most worldwide applications:

•The IM11 can comply with the regulatory requirements for

ETSI 4 channels in Europe, USA, Taiwan, Australia, Thailand,

Brazil, Hong Kong, Malaysia, Singapore, China, Philippines,

South Africa,Israel, South Korea, and New Zealand. For the

latest, contact your Intermec sales representative.

•The IM11 cannot comply with regulatory requirements for

Japan.

•Operates across the entire frequency band. The country code

defines the frequency bands of operation, the power levels, the hop

tables, and other country-specific parameters. The default country

code is defined by the location where the module is delivered.

•Covers UHF bands from 865 to 928 MHz. Supports four channel

operation over the 865 to 868 MHz band.

•Supports 50 channels in the FCC band from 902 to 928 MHz.

•Supports the ISO 18000-6c protocol (EPC Class 1, Gen 2)

•Supports the BRI (Basic Reader Interface) host communication

protocol.

10 IM11 RFID Reader Module Integration Guide (Confidential)

Technical Overview

Specifications

Physical Specifications

Specification Values

Physical 50.95 mm long x 30 mm wide x 4.76 mm thick

Weight

Environmental Specifications

Specification Values

Operating

Temperature

-20 °C to +60 °C

Storage

Temperature

-40 °C to +70 °C

Humidity 25 °C to 60 °C, 0% to 95% relative humidity,

non-condensing process

Shock 2000 g, 0.5 ms pulse, 10 times on each axis

Vibration GRMS. 10 to 500 Hz, in 3 axis

ESD Passes CE mark requirements. 4 kV contact discharge and 8

kV air discharge, while unpowered.

Power Supply Specifications

Specification Minimum Typical Maximum Unit Notes

Operating

Voltage

3.15 3.8 5.2 V All internal voltages

regulated on

module

Deep Sleep 100 μA Vbatt current when

enable low powers

Real-Time Clock

Standby

Current

30 mA At 3.8 V, USB

connection in

Suspend mode, no

GPIO loading

Table des matières

Autres manuels Intermec Unité de contrôle

Intermec

Intermec MaxiScan 3010 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
