Interlogix ATSx500A Series Instructions de montage

Advisor Advanced

ATSx500A(-IP) Installation

and Programming Manual

P/N 466-2576 (EN) • REV B • ISS 16SEP16

rights reserved.

Trademarks and

patents

Interlogix, Advisor Advanced ATSx500A(-IP) name and logo are

trademarks of UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

3211 Progress Drive, Lincolnton, NC, 28092, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, Netherlands

Version

This document applies to the following Advisor Advanced firmware

versions:

ATSx500A(-IP): MR_3.0

Certification

EN 50131-1 System requirements

EN 50131-3 Control and indicating equipment

EN 50131-6 Power Supplies

EN 50136-1-1 Alarm systems -Alarm Transmission systems

ATS1500A(-IP): Security Grade 2, Environmental class II

ATS3500A(-IP): Security Grade 3, Environmental class II

ATS4500A-IP: Security Grade 3, Environmental class II

Note: ATS1500A(-IP) is upgradable to Security Grade 3 using the

ATS-MM-TK (MM enclosure) or the ATS-SM-TK (SM enclosure)

tamper kit.

Tested and certified by VdS Schadenverhütung GmbH

Important: To comply with the above standards, it is required to

configure the system according to settings listed in Chapter 8

“Regulations” on page 301 onwards.

This product has not been designed to comply with EN 50134 and

EN 54 norms.

European Union

directives

UTC Fire & Security hereby declares that this device is in

compliance with the applicable requirements and provisions of one

or more of the Directives 2014/30/EU and 2014/35/EU. For more

information see www.utcfireandsecurity.com or www.interlogix.com.

2002/96/EC (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.utcfssecurityproducts.eu/recycle/

Contact information

www.utcfireandsecurity.com or www.interlogix.com

Customer support

www.utcfssecurityproducts.eu

Advisor Advanced ATSx500A(-IP) Installation and Programming Manual i

Content

Important information iii

Chapter 1 Quick installation and programming 1

Quick installation 2

Quick programming 4

Chapter 2 Installation 7

General installation information 8

Maintenance 16

Mounting 18

Earthing 20

Shielding 21

Cabling 22

Configuration 30

Specifications 35

Chapter 3 System functions 41

Function list 43

Zones 45

Areas 50

Set and unset 51

Inhibit and isolate 53

Keys 54

Bus devices 58

Users 60

User groups 62

PIN 66

Outputs 67

Access control 68

Condition filters 74

Triggers 76

Calendar 77

Events 79

Tests and diagnostics 80

Alarm reporting 84

User programmable functions 88

Autoset 91

Wireless device programming 92

Using cameras 98

Engineer reset 102

Timed unset / ATM 103

Chapter 4 Programming 105

The Advisor Advanced menu 106

ii Advisor Advanced ATSx500A(-IP) Installation and Programming Manual

How to program the options 108

Remote access 113

Initial start-up 114

Chapter 5 Menu reference 117

1 Service menu 120

2 Device menu 142

3 User menu 162

4 Zones and areas 171

5 Door menu 196

6 Outputs and filters 217

7 Calendar 225

8 System option menu 232

9 Dialler menu 258

Chapter 6 Software 287

Programming Advisor Advanced via configuration software 288

Upgrading Advisor Advanced firmware 290

Chapter 7 Troubleshooting 295

Recovery procedure 296

Device troubleshooting 297

Chapter 8 Regulations 301

Options affected by EN 50131 regulations 302

Options affected by other regulations 308

Appendix A Advisor Advanced events 311

Appendix B Advisor Advanced reporting codes 327

Glossary 337

Index 343

Programming map 351

Advisor Advanced ATSx500A(-IP) Installation and Programming Manual iii

Important information

This document includes an overview of the product and detailed instructions

explaining how to install your Advisor Advanced system and program it.

To use this document effectively, you should have the following minimum

qualifications:

• Basic knowledge of alarm systems and components

• Basic knowledge of electrical wiring and low-voltage electrical connections

Read these instructions and all ancillary documentation entirely before installing

or operating this product.

Important note

This manual provides information for all Advisor Advanced and Advisor

Advanced-IP control panels in all variations. “Advisor Advanced control panel”

refers to any variant of the Advisor Advanced control panels, unless specifically

stated otherwise.

List of panel variants

Table 1: List of ATSx500A(-IP) panel variants

Model

Enclosure

Dimensions (mm)

Weight (kg)

ATS1500A-MM

Metal

MM, 315 x 388 x 85

5.2

ATS1500A-IP-MM

Metal

MM, 315 x 388 x 85

5.2

ATS1500A-SM

Metal

SM, 250 x 250 x 86

2.8

ATS1500A-IP-SM

Metal

SM, 250 x 250 x 86

2.8

ATS1500A-LP

Plastic

LP, 257 x 400 x 112

2.6

ATS1500A-IP-LP

Plastic

LP, 257 x 400 x 112

2.6

ATS3500A-MM

Metal

MM, 315 x 388 x 85

5.2

ATS3500A-IP-MM

Metal

MM, 315 x 388 x 85

5.2

ATS3500A-LP

Plastic

LP, 257 x 400 x 112

2.6

ATS3500A-IP-LP

Plastic

LP, 257 x 400 x 112

2.6

ATS4500A-IP-MM

Metal

MM+, 315 x 445 x 88

5.4

ATS4500A-IP-LM

Metal

LM, 475 x 460 x 160

10.9

Notes

• Not all variants may be available.

• Weight does not include batteries.

iv Advisor Advanced ATSx500A(-IP) Installation and Programming Manual

Limitation of liability

To the maximum extent permitted by applicable law, in no event will UTCFS be

liable for any lost profits or business opportunities, loss of use, business

interruption, loss of data, or any other indirect, special, incidental, or

consequential damages under any theory of liability, whether based in contract,

tort, negligence, product liability, or otherwise. Because some jurisdictions do not

allow the exclusion or limitation of liability for consequential or incidental

damages the preceding limitation may not apply to you. In any event the total

liability of UTCFS shall not exceed the purchase price of the product. The

foregoing limitation will apply to the maximum extent permitted by applicable law,

regardless of whether UTCFS has been advised of the possibility of such

damages and regardless of whether any remedy fails of its essential purpose.

Installation in accordance with this manual, applicable codes, and the instructions

of the authority having jurisdiction is mandatory.

While every precaution has been taken during the preparation of this manual to

ensure the accuracy of its contents, UTCFS assumes no responsibility for errors

or omissions.

Advisory messages

Advisory messages alert you to conditions or practices that can cause unwanted

results. The advisory messages used in this document are shown and described

below.

WARNING: Warning messages advise you of hazards that could result in injury

or loss of life. They tell you which actions to take or to avoid in order to prevent

the injury or loss of life.

Caution: Caution messages advise you of possible equipment damage. They tell

you which actions to take or to avoid in order to prevent the damage.

Note: Note messages advise you of the possible loss of time or effort. They

describe how to avoid the loss. Notes are also used to point out important

information that you should read.

Safety sign identifies actions or practices that are required by

EN 60950 Safety Standard.

Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 1

Chapter 1

Quick installation and

programming

Summary

The chapter contains basic steps of connection and programming of the Advisor Advanced

control panel and auxiliary devices.

For more detailed description of the installation process, see Chapter 2 “Installation” on page 7.

For details on programming, see Chapter 4 “Programming” on page 105 and Chapter 5 “Menu

reference” on page 117.

Content

Quick installation 2

Quick programming 4

Chapter 1: Quick installation and programming

2 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual

Quick installation

RxTx

SYS

POLL

MI/PANEL

ETHERNET

SIM

GSM

GPRS/3G

DGP Addr

1 2 3 4

SIM

USB

RxTx

USB

CON12

CON13

S4 S5

S1 C

S2 CT C

- - 1 C 2 3 C 4 5 C 6 7 C 8

~~+-

AC BATT LC-OUTPUTS HC-OUTPUTS SIR TMP AUX POWER INPUTS

EARTH

CTD-

D+

+12V COMMS TAMPER

S3 C

CON16

NTC

ATS7700

ATS608ATS624

ATS626

4K7

+12V

Zone

GND

4K74K7

Zone

GND

DC101

DD1012AM

+ -

TDA74xxNG

1K 1K

Off

Isolated fault

contact

3 resistor single

zone

(Terminal 3-10)

JF JT JA

2 2K

4 7K

2 2K

4 7K

5 6K

2 2K

4 7K

5 6K

SW1 - Generic settings

LED ON

Remote OFF

Auto Rem. Test ON

Positive Polarity

LED OFF

Remote ON

Negative Polarity

Range

SW2 - AM/Fault settings

Mask to alarm and

fault relay

Auto reset

Advanced AM sens.

AM Day mode only

Mask to fault relay

only

Authorized reset

Standard AM sens.

AM Day and Night

1 .

( 3 ft )

40 .

( ft )

30 .

( ft )

20 .

( ft )

Auto Rem. Test OFF

10K

Zone

Alarm

GND

+12V

Fault

Alarm

Fault

1 3 4 5

2 6 78 9

Chapter 1: Quick installation and programming

Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 3

D+0V+12V D- IN OUT

EARTH

CTD-

D+

+12V COMMS TAMPER

D+0V+12V D- IN OUT

123

45 6

7 8 9

abc

jkl

tuv

def

ghi

.,’?!

A B C

Address 1

RxTx

SYS

POLL

MI/PANEL

ETHERNET

SIM

GSM

GPRS/3G

DGP Addr

1 2 3 4

SIM

USB

ATS1135 ATS1135

TDA74xxNG

123

45 6

7 8 9

abc

jkl

tuv

def

ghi

.,’?!

A B C

Address 2

Chapter 1: Quick installation and programming

4 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual

Quick programming

Initial start-up

Note: See “The Advisor Advanced menu”

on page 106 for menu explanation. For

more information on editing options, see

“How to program the options” on page 108.

Switch the panel on. The further messages

and menus are listed in the table below.

Display

Instructions

INFO

Inst required

Press Enter to continue.

1>Panel language

Choose English.

2>Defaults

Choose EN 50131 Grade 3.

4>PIN length

Enter 6.

5>Time&date

Set current time and date.

6 Install

>Cancel<

Choose OK

Installer

PIN:127800

Press Enter to continue.

Supervisor

PIN:112200

Press Enter to continue.

The panel restarts.

Auto configuration

Auto Config?

>Yes<

Press Enter to continue.

Rkp 1-16 BUS1

R-?-------------

Exp 1-15 BUS1

-?-------------

Wait until the panel

configures all bus devices

and zones.

Added

R:1 D:0 Z:8

Press Enter to continue.

Enabling service in

UTC F&S

THU 05 Mar 12:21

Press 112200, Menu

1>Zone options

2 Isolate

Go to menu 8.8 Service in

8>Service in

Enable?

Enable Installer in time

Press Cancel, Cancel to log off.

Programming menu entry

UTC F&S

THU 05 Mar 12:21

Press 127800, Menu

Inh reports

>No<

Press Enter to continue.

Inh tampers

Unset areas

1>Service menu

2 Device menu

The installer menu is displayed.

Changing installer PIN

Go to 3.1.n.2.1 Change PIN (see page 163).

1>Change PIN

***********

Press Enter.

New PIN

Enter the new installer PIN.

Configuring zones

Go to 4.1 Zone menu (see page 171).

4>Zones&Areas

Press Enter.

1>Zone menu

Press Enter.

0>Add zone

1 Zone 1

Select a zone.

For each zone used in the system, enter

zone name in 4.1.n.1 Zone name (page

172).

01 Zone name

>1 Zone 1 <

Next, set its zone type in 4.1.n.2 Zone type

(see page 172).

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Interlogix Système de sécurité

Interlogix

Interlogix Simon XT Manuel utilisateur

Interlogix

Interlogix RF-7120-07-1 Instructions de montage

Interlogix

Interlogix Simon 3 Manuel utilisateur

Interlogix

Interlogix advisorone Instructions de montage

Interlogix

Interlogix AS280 Instructions de montage

Interlogix

Interlogix Advent Manuel utilisateur

Interlogix

Interlogix ATS111xA-N Series Instructions de montage

Interlogix

Interlogix ATS111 A Series Instructions de montage

Interlogix

Interlogix ACL800SUW-BSMF Manuel utilisateur

Interlogix

Interlogix ITI Simon Manuel utilisateur

Interlogix

Interlogix AS272 Instructions de montage

Interlogix

Interlogix advisorone Guide de l'utilisateur

Interlogix

Interlogix 60-578 Manuel utilisateur

Interlogix

Interlogix Caddx Manuel utilisateur

Interlogix

Interlogix UltraView UVC-6120-1 Manuel utilisateur

Interlogix

Interlogix ZeroWire Manuel d'instructions

Interlogix

Interlogix DC108 Series Instructions de montage

Interlogix

Interlogix NX-595E Manuel utilisateur

Interlogix

Interlogix NX-595E Manuel utilisateur

Interlogix

Interlogix ATS125 Instructions de montage

Interlogix

Interlogix Simon XT Manuel utilisateur

Interlogix

Interlogix Alliance system Manuel utilisateur

Interlogix

Interlogix ZeroWire ZW-6400H Manuel utilisateur

Interlogix

Interlogix AS620RF Instructions de montage

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
