Interlogix TruVision DVR 41 Manuel utilisateur

TruVision DVR 41 User

Manual

P/N 1072566C-EN • REV 1.0 • ISS 15MAY13

2013 UTC Fire & Security Americas Corporation, Inc.

Interlogix is part of UTC Climate Controls & Security, a unit of United

Technologies Corpora

Trademarks and

patents

The TruVision and Interlogix names and logos are trademarks of United

Technologies.

Other trade names used in this document may be trademarks or registered

trademarks of the manufacturers or vendors of

the respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance

Class B:

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against ha

rmful interference in a

residential installation. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

There is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to corr

ect the interference by one or more of the

following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

European Union

directives

12004/108/EC (EMC directive):

Hereby, UTC Fire & Security declares that this

device is in compliance

or with the essential requirements and other relevant

provisions of Directive 2004/108/EC

2002/96/EC (WEEE directive):

Products marked with this symbol cannot be

disposed of as unsorted municipal waste in the European Union. For proper

recycling, return this product to your local suppl

ier upon the purchase of

equivalent new equipment, or dispose of it at designated collection points. For

more information see: www.recyclethis.info.

2006/66/EC (battery directive):

This product contains a battery that cannot be

disposed of as unsorted

municipal waste in the European Union. See the

product documentation for specific battery information. The battery is marked

with this symbol, which may include lettering to indicate cadmium (Cd), lead

(Pb), or mercury (Hg). For proper recycling, return th

e battery to your supplier or

to a designated collection point. For more information see: www.recyclethis.info.

Contact information

For contact information

, see www.utcfireandsecurity.com or

www.utcfssecurityproducts.eu

TruVision DVR 41 User Manual i

Content

Chapter 1 Product introduction 1

Product overview 1

Chapter 2 Installation 3

Installation environment 3

Unpacking the TVR 41 and its accessories 3

Back panel 4

PTZ dome camera set up 5

Wiring the keypad 10

RS-485 ports 12

RS-232 port 13

Monitor connections 13

Loop through 13

Audio inputs and output 13

Brackets 14

Chapter 3 Getting started 15

Turning on and off the DVR 15

Using the setup wizard 16

Chapter 4 Operating instructions 19

Controlling the TVR 41 19

Using the front panel 19

Using the mouse 21

Using the IR remote control 22

Menu overview 25

Chapter 5 Live view 29

Description of live view 29

Video output 29

Audio output 30

Controlling live view 30

Multiview format 32

Sequencing cameras 33

Accessing frequently used commands 34

Configuring live view 35

Configuring time and date 38

General settings 39

V-stream encoding 42

Chapter 6 Controlling a PTZ camera 43

Configuring PTZ settings 43

Calling up presets, tours and shadow tours 44

Setting and calling up presets 45

ii TruVision DVR 41 User Manual

Setting and calling up preset tours 47

Setting and calling up a shadow tour 48

Chapter 7 Playing back a recording 51

Overview of the playback window 51

Playback pop-up menu 54

Instant playback 54

All-day playback 55

Searching recorded video 56

Playing back recordings by time and video type 57

Playing back recordings by event 58

Creating and playing back bookmarked recordings 59

Slideshow of snapshots 60

Playing back recordings from the system log 61

Playback skip time 61

Motion search 62

Playing back frame-by-frame 63

Digital zoom in playback 63

Chapter 8 Archiving recorded files 64

Archiving files 64

Auto archiving 67

Creating and archiving video clips 68

Archiving snapshots 68

Managing backup devices 69

Playing back archived files on a PC 69

Chapter 9 Using the web browser 71

Windows Vista and 7 users 71

Accessing the web browser 72

Web browser overview 72

Using the web browser to configure the device 74

Searching and playing back recorded video 77

Searching for event logs 79

Dual streaming 80

Controlling a PTZ dome camera in the web browser 81

Capturing text insertions 81

Text overlay 83

Using a network storage system 84

Chapter 10 Recording 87

Initializing recording settings 87

Defining a recording schedule 90

Daily schedules 91

Holiday schedules 92

Manual recording 93

Motion detection schedules 93

External alarm schedules 94

TruVision DVR 41 User Manual iii

Protecting recorded files 94

HDD redundancy 96

Chapter 11 Alarm settings 97

Description of alarm notification types 97

Setting up motion detection 100

Setting up external alarms 102

Triggering or clearing alarm outputs manually 105

Setting up system notifications 105

Detecting video loss 106

Detecting video tampering 107

Chapter 12 Network settings 109

Configuring general network settings 109

Configuring PPPoE 110

Configuring DDNS 111

Configuring an NTP server 112

Configuring e-mail 112

Configuring UPnPTM 113

Configuring SNMP 115

Configuring an FTP server to store snapshots 115

Configuring a remote alarm host 115

Configuring multicast 116

Configuring the server and HTTP ports 116

Configuring the RTSP service port 116

Checking network status 117

Exporting network packet data 118

Bandwidth throttle management 118

Chapter 13 HDD management 121

Initializing HDDs 121

Controlling disk space on the HDD 121

Setting up HDD groups 122

Recording dual streaming 123

Setting the HDD property 123

Checking HDD status 124

Configuring HDD alarms 124

Managing eSATA 125

Checking the S.M.A.R.T. information 125

Searching video using disk analysis 126

Chapter 14 Camera settings 129

Configuring the camera OSD settings 129

Setting up privacy masking 130

Adjusting camera image settings 131

Hiding a camera image from view 131

iv TruVision DVR 41 User Manual

Chapter 15 DVR management 133

Configuring the RS-232 port 133

Updating system firmware 134

Restoring default settings 135

Viewing system information 136

Searching system logs for events 137

Importing and exporting configuration settings 138

Chapter 16 User management 139

Adding a new user 139

Customizing a user’s access privileges 140

Deleting a user 141

Modifying a user 142

Changing the Admin password 142

Chapter 17 iTVRmobile 143

Setup and login 143

Live view 144

Controlling a PTZ camera 145

Device management 146

Favorites 147

Local configuration 148

Change passwords 148

Snapshots 148

Appendix A Specifications 149

Appendix B PTZ protocols 151

Appendix C Port forwarding information 153

Appendix D KTD-405 keypad 155

Supported firmware 155

Wiring the keypad 155

Setting up the keypad to work with the TVR 41 156

Operating the keypad 158

Appendix E Maximum pre-recording times 163

Appendix F Supported PTZ commands 165

Appendix G Default menu settings 167

Index 177

TruVision DVR 41 User Manual 1

Chapter 1

Product introduction

Product overview

This is the TruVision DVR 41(TVR 41) User Manual for models:

Table 1: Product codes

Americas

EMEA

TVR

-4108-2T TVR-4104-1TEA

TVR

-4108-4T TVR-4104-2TEA

TVR

-4116-2T TVR-4108-2TEA

TVR

-4116-4T TVR-4108-4TEA

TVR

-4116-8T TVR-4116-2TEA

TVR

-4116-12T TVR-4116-4TEA

TVR-4116-8TEA

TVR-4116-12TEA

Note: Models are shipped with the power chords for their region.

For regions not listed in Table 1 above, please contact your local supplier.

The TruVision™ DVR 41 (TVR 41) is a versatile, user-friendly embedded digital

video recorder (DVR) allowing end-users to record 4, 8, or 16 analog cameras at

4 CIF in real time (25/30 fps), while providing integration with the UTC portfolio of

security solutions, and offering a seamless product experience within the

TruVision brand.

Its dual streaming functionality allows the user to set up different settings for

recording and streaming video in live view mode.

TruVision DVR 41 can fully integrate with the license-free TruVision Navigator

software, which is ideal for the most commercial applications. TVR 41’s easy and

intuitive-to-use web browser interface enables remote configuration and secure

viewing, searching, and playing back of video from computers connected via the

Internet.

0BChapter 1: Product introduction

2 TruVision DVR 41 User Manual

TruVision DVR 41 User Manual 3

Chapter 2

Installation

This section describes how to install the TVR 41 unit.

Installation environment

When installing your product, consider these factors:

• Ventilation

• Temperature

• Moisture

• Chassis load

Ventilation: Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions. Ensure that the location planned for the installation

of the unit is well ventilated.

Temperature: Consider the unit’s operating temperature (-10 to +55 ºC, 14 to

131 °F) and noncondensing humidity specifications (10 to 90%) before choosing

an installation location. Extremes of heat or cold beyond the specified operating

temperature limits may reduce the life expectancy of the DVR. Do not install the

unit on top of other hot equipment. Leave 44 mm (1.75 in.) of space between

rack-mounted TruVision DVR 41 units.

Moisture: Do not use the unit near water. Moisture can damage the internal

components. To reduce the risk of fire or electric shock, do not expose this unit to

rain or moisture.

Chassis: Equipment weighing less than 15.9 kg (35 lb.) may be placed on top of

the unit.

Unpacking the TVR 41 and its accessories

When you receive the product, check the package and contents for damage, and

verify that all items are included. There is an item list included in the package. If

any of the items are damaged or missing, please contact your local supplier.

1BChapter 2: Installation

4 TruVision DVR 41 User Manual

Items shipped with the product include:

• IR (infrared) remote control

• Two AAA batteries for the remote control

• AC power cords (US, Europe, UK)

• USB mouse

• DVR

• Video loop through cable

• CD with software and manuals

• TruVision DVR 41 Quick Start Guide

• TruVision DVR 41 User Manual (on CD)

Back panel

Figure 1 on page 5 shows the back panel connections and describes each

connector on a typical TVR 41 digital video recorder. Details may vary for specific

models.

Before powering up the DVR, connect the cameras and a main monitor for basic

operation.

Autres manuels pour TruVision DVR 41

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Interlogix DVR

Interlogix

Interlogix TruVision DVR 15HD Manuel utilisateur

Interlogix

Interlogix TruVision DVR 44HD Manuel utilisateur

Interlogix

Interlogix TVR 12HD Manuel utilisateur

Interlogix

Interlogix TruVision DVR 12HD Manuel utilisateur

Interlogix

Interlogix TruVision TVN 21 Manuel utilisateur

Interlogix

Interlogix TVR 45HD Manuel utilisateur

Interlogix

Interlogix TruVision DVR 11 Manuel utilisateur

Interlogix

Interlogix TruVision NVR 70 Manuel utilisateur

Interlogix

Interlogix TruVision Line Manuel utilisateur

Interlogix

Interlogix TruVision DVR 20 Manuel utilisateur

Interlogix

Interlogix MobileView 3000 Manuel utilisateur

Interlogix

Interlogix TruVision DVR 60 Manuel utilisateur

Interlogix

Interlogix TVR-1004-250 Manuel utilisateur

Interlogix

Interlogix TruVision DVR 45HD Manuel utilisateur

Interlogix

Interlogix TruVision DVR 12 Manuel utilisateur

Interlogix

Interlogix TruVision DVR 41 Manuel utilisateur

Interlogix

Interlogix TruVision SVR Manuel utilisateur

Interlogix

Interlogix truVision DVR 31 Manuel utilisateur

Interlogix

Interlogix TruVision NVR 21 Manuel utilisateur

Interlogix

Interlogix TVR 12 Manuel utilisateur

Interlogix

Interlogix TruVision NVR 50 Manuel utilisateur

Interlogix

Interlogix truVision 11c Series Manuel utilisateur

Interlogix

Interlogix TruVision DVR 42 Manuel utilisateur

Interlogix

Interlogix TruVision NVR 21 Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
