Intercoax ECP-2808RM Manuel utilisateur
Ethernet over Coax / UTP Managed Receiving Switch
ECP-2808RM / ECP-2816RM / EUP-2808RM / EUP-2816RM
User Manual
Version 3.0
Contents
Precaution and Safety Guidelines .................................................................. 4
1. Product Overview ........................................................................................ 5
1.1. Introduction....................................................................................................................5
1.2. Features..........................................................................................................................5
1.3. Package Contents ........................................................................................................5
2. Hardware Installation .................................................................................. 6
2.1. Front Panel.....................................................................................................................6
2.2. Rear Panel ......................................................................................................................7
2.3. LED Indication ...............................................................................................................8
2.4. Conguration Instruction .............................................................................................9
2.4.1. Prepare devices and materials ..................................................................................9
2.4.2. Hardware Installation.................................................................................................9
2.4.2.1. Rackmount Bracket Installation Guide
2.4.2.2. Rack Mount Instructions
2.6. Typical Installation ......................................................................................................12
3. Product Specications.............................................................................. 13
3.1. Technical Specications.............................................................................................13
3.2. Regulatory Certications ...........................................................................................13
4. Management Software Conguration...................................................... 14
4.1. Overview.......................................................................................................................14
4.2. System Requirements.................................................................................................14
4.3. Installing ECP Manager...............................................................................................15
4.4. Setting up ECP Manager.............................................................................................18
4.4.1. Setting up Groups and ECP Units...........................................................................18
4.4.2. Admin Window.........................................................................................................21
4.5. Conguring and Monitoring RM Units in ECP Manager .........................................22
4.5.1. Changing the IP Address.........................................................................................22
4.5.2. Join & Node Control ................................................................................................24
4.5.3. Node Monitor ...........................................................................................................24
4.5.4. Power ......................................................................................................................25
4.5.5. Trac.......................................................................................................................26
4.5.6. Multicast ..................................................................................................................26
4.5.7. Settings....................................................................................................................27
4.6. SNMP ...........................................................................................................................30
4.7. Web GUI .......................................................................................................................33
4.8. SSH ..............................................................................................................................34
5. Warranty Policy.......................................................................................... 40
6. Regulatory and Certicates...................................................................... 40
7. Customer supports.................................................................................... 40
4
Precaution and Safety Guidelines
• Please install the device following the installation guide.
• Read all warnings.
• Warning: Do not touch the device and cable with wet hands.
• Warning: Clean this device only with a dry cloth.
• Warning: Please do not put the device on anything electrically conductive (screwdrivers, coins, iron, etc.)
and do not put them around water.
• Warning: Do not install near any heat sources such as radiators, stoves
or other devices that produce heat.
• Warning: Do not use for other purposes.
• Warning: Do not put the signal lines (Coax, UTP) in the same conduit as high voltage wiring
• Do not apply any sticker or paint onto the device.
• Indoor use only.
• Please use only attachments or accessories specied by the manufacturer.
• Unplug the device during a lightning storm or when the device is not used for a long time.
• Do not connect analog cameras to the BNC connectors (B-Linx Port) on this device (ECP Series only).
• Do not connect any IP devices to the RJ45 connectors (T-Linx Port) on this device (EUP Series only).
• When the unit is not working properly, please contact your supplier or customer service.
• Please do not disassemble the unit by yourself.
• If this device emits smoke, abnormal noise, or a strange odor, please turn o
the power switch, unplug the AC power cord immediately, and contact your supplier or customer service.
The lightning ash with arrowhead symbol within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sucient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
Product Overview — 5
1. Product Overview
1.1. Introduction
The Intercoax ECP/EUP-2808RM/2816RM Series are 19” rack mountable managed Long Distance Ethernet and
PoE over Coax/UTP Receiving Switches.
ECP/EUP-2808RM/2816RM series are capable of connecting 8/16 ECP Transmitters and also support PoE
powered devices such as IP cameras.
Data rates up to 1Gbps are achievable, making these devices the ideal choice in new or legacy installations where
existing Coax/UTP cable is re-deployed as part of an upgrade from analog to IP cameras.
ECP/EUP-2808RM series have built-in 320 Watt power supply and ECP/EUP-2816RM series have built-in 640 Watt
power supply (*Dual power supply of 320W + 320W for power sharing and redundancy)
PoE up to 60W per port is available.
Our browser based GUI manages all connected IEEE1901-HPAV standard devices.
Furthermore, our “Intercoax ECP Manager” software allows managing multiple of the ECP/EUP-2808RM/2816RM
series, remotely from the central management oce.
1.2. Features
• Ethernet & PoE transmission over Coax / UTP cable
• Complies to IEEE1901-HPAV standard
• Extended transmission distance up to 2,400m
• PoE up to 60W (802.3bt) per B-Linx port & T-Linx port
• Management software, “Intercoax ECP Manager", supported
• Remote power on/o and reset of each port
• Real-time monitoring of power consumption for each port
• Multicast Setting with IGMP Query & Report Generator
• SNMP ready
• VLAN ready
• MAC Address Locking on each port for extra secure network connectivity
• Alarm LED & buzzer and notication on ECP Manager
• Scheduled event reporting and alert reporting to designative users
• Back up & Restore of conguration
• Auto Power Short Protection
• B-Linx & T-Linx Smart Device Detection for safe power transmission
• 320W (8 port) / 640W (16 port) Built-in Power Supply
• Built-in crosstalk cancelling technology
• Gigabit SFP and Copper uplink port
• 19-inch(1U) rack mountable design
1.3. Package Contents
ECP-2816RM
(ECP-2808RM / EUP-2808RM / EUP-2816RM)
Bracket Quick Installation
Guide
AC Power cord
Hardware Installation — 6
2. Hardware Installation
2.1. Front Panel
2
4
3
56 7 8
56 7 8
56 7 8
1
2
15 6
3
3
3
4
4
4
7 8
[EUP-2816RM]
[ECP-2816RM]
[EUP-2808RM]
[ECP-2808RM]
No. Description
1
B-Linx Ports (1~8 / 1~16) :
Connect Intercoax ECP Transmitters or IEEE1901-HPAV standard devices by coaxial cable with BNC male
connector.
2
T-Linx Ports (1~8 / 1~16) :
Connect Intercoax ECP Transmitters or IEEE1901-HPAV standard devices by UTP cable with RJ45 male
connector.
3
Smart B-Linx / T-Linx Detection On O :
B–Linx / T-Linx Detection mode On/O switch
- Detection Mode ON: Detects B-Linx & T-Linx devices before supplying power over Coax.
- Detection mode OFF: By-pass detection, classication and power management checks.
[Caution]
Do not connect analog cameras or network devices on BNC or RJ-45 port directly if Smart
B-Linx / T-Linx detection switch is OFF, it may cause serious damage to the device connected.
Hardware Installation — 7
No. Description
5Buzzer On O :
Move the switch left or right to set the buzzer sound on or o.
6
Factory Reset :
The hidden factory reset button.
Press and hold for 10 seconds the reset button to restore to its original IP settings (192.168.4.17/24)
7SFP :
Connect an SFP module for uplink data (1000Base-SX and 1000Base-LX slot).
8Link :
Connect an RJ45 Ethernet cable for uplink data (10/100/1000 Base-T).
2.2. Rear Panel
2 1
No. Description
1Power ON/OFF Switch
2Power Connector
The connector is for 100~240V AC power input 50Hz/60Hz
Hardware Installation — 8
2.3. LED Indication
2
213 4 6
5
3 4 6
5
2
[EUP-2816RM]
[ECP-2816RM]
[EUP-2808RM]
[ECP-2808RM]
213 4 6
5
3 4 6
5
No. LED
Indication On O Blinking
1B-Linx/T-Linx
(1~8 / 1~16)
• ECP/EUP Transmitter is
connected
• Power over coax / UTP
working properly
• No device connected
on B-Linx / T-Linx port
• Short circuit or over current
protection is working
2
Join
(1~4 / 5~8,
9~12, 13~16)
•• Unjoined ECP device is
connected
• ECP/EUP transmitter linked
properly
• Transmitting Data Via
Coax / UTP
3 Alarm • System boot-up
• Alarm is detected • Device in normal operation • Factory reset is progressing
4 SFP Link • Transmitting Data
• SFP Link is down
• No device connected on
SFP port
•
5 LINK • • Uplink (Copper) is down
• Transmitting Data
Green: 10/100 Mbps
Amber: 1000 Mbps
6 PWR • Power ON • Power OFF •
Hardware Installation — 9
2.4. Conguration Instruction
2.4.1. Prepare devices and materials
• Ethernet over Coax /UTP Receiving Switch (ECP-2808RM, EUP-2808RM, ECP-2816RM, EUP-2816RM)
• ECP-Transmitters (ECP-2601, ECP-2701, etc.)
• EUP-Transmitters (EUP-2601T & or ECP Transmitters with BTE-02)
• RJ-45 patch cord
• Coax cables (ECP) or 4 pairs Cat5 or up UTP cables (EUP)
• Network Switch and PC (OS: Window 7 or later)
2.4.2. Hardware Installation
1. Use Coax (ECP) or UTP cables (EUP) to connect the receiving switch and the ECP/EUP-Transmitters.
Hardware Installation — 10
2. Connect ECP-Transmitters to the IP end device (e.g. IP Camera, IP Access Control Unit, VoIP phone, etc.)
(If you want the device to be powered by PoE, Please set the PoE Switch to ‘ON’ on the ECP Transmitter).
Connect the receiving switch to your Network Switch or your PC using the RJ45 Patch cord.
3. Alternatively, use optical SFP Transceiver modules and a ber cable to connect to the SFP uplink port of the
receiving switch to an optical SFP port of your Network Switch. This can be used as standalone connection or
redundant port.
4. Apply power to the receiving switch.
