Intellinet 503358 Manuel utilisateur

PoE

OFFICE

SWITCH

USER

MANUAL

MODEL 503358

INT-503358-UM-1107-01

INTRODUCTION

Thank you for purchasing the INTELLINET NETWORK SOLUTIONS™

PoE Ofce Switch, Model 503358.

This PoE Ofce Switch has eight 10/100 Base-TX ports that support

the 802.3af protocol and is designed to inject up to 19.2 Watts per port.

Any devices that are 802.3af compliant — such as IP phones, wireless

access points and network cameras — can be attached to the switch,

and no additional power will be required to support the attached device.

This eliminates the time and expense of electrical power rewiring, and

minimizes the clutter of power supplies and adapters in awkward places

such as ceilings and walls.

Besides providing 802.3af Power over Ethernet functionality, the PoE

Ofce Switch has some very impressive features as a switch. For

starters, the auto features of this switch make installation Plug and

Play and hassle free: No conguration is required. Auto-MDI/MDI-X

crossover on all ports eliminates the need for crossover cables for

connection to another switch or hub. Auto-Negotiation on each port

senses the link speed of a network device (either 10 or 100) and

intelligently adjusts for compatibility and optimal performance.

Easy-to-follow instructions in this user manual help make installation

of the switch quick and simple, so you’ll also soon be enjoying the

benets of these additional features:

• Store and forward switching architecture

• Full/half duplex operation

• IEEE 802.3x ow control for full duplex

• Zero packet loss back-pressure ow control for half duplex

• Packet ltering/forwarding rates: 148,800 pps (100 Mbps), 14,880 pps

(10 Mbps)

• Supports 4096 MAC address entries

• 128 kBytes buffer memory

• Desktop-size metal case

• LEDs for power, link/activity and PoE

• Lifetime Warranty

FCC Warning

This device has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of FCC Rules. These limits are

designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This

equipment generates, uses and radiates radio frequency energy and,

if not installed and used in accordance with the user manual, may cause

interference, which the user will be required to correct at his own

expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may

cause radio interference, in which case the user may be required to take

adequate measures to correct.

PORTS & INDICATORS

Ports

The eight RJ-45 connections on the front panel (at right in image below)

match workstations, servers or other network devices to 10/100 Mbps

switching ports that sense 10/100M speed and automatically negotiate

full/half duplex mode, allowing you to connect the switch to 10Base-T and

100Base-TX devices. NOTE: The eight ports are also capable of 48 V

power-injector PSE (power source equipment) function (see Connections).

POWER

PoE

LINK/ACT

2 4 6 8

1 3 5 7 1 3 5 7

2 4 6 8

LEDs

The front-panel LEDs (at left in image above) will be on (lighted), off or

blinking/ashing, indicating function status as follows.

POWER On: The switch has power and is ready for use.

Off: The switch has no power.

LINK/ACT On: The port is ready for 10/100 Mbps connection.

Flashing: Data is being transmitted/received at the port.

PoE On: The port is supplying power to connected device.

CONNECTIONS

Power

The AC power outlet and switch are on

the rear panel (as shown at right).

PCs, Servers and Other Network Devices

Use Cat5 straight-through twisted-pair cables

to congure a network environment such

as the one shown at right.

Hubs and Other Switches

Use either straight-through or crossover cable to connect to the uplink port

of a hub or another switch: This device supports Auto-MDIX on all ports.

Powered Devices

Use Cat5 twisted-pair

cable to supply 48 V to a

powered device connected

to any of the eight ports.

NOTE: Any connected

devices should also be

IEEE 802.3af compliant.

OFF

PoE Office Switch

SPECIFICATIONS

Standards

• IEEE 802.3 (10Base-T Ethernet)

• IEEE 802.3u (100Base-TX Fast Ethernet)

• IEEE 802.3x (ow control, full duplex mode)

• IEEE 802.3af (Power over Ethernet)

• IEEE 802.1p (trafc prioritization)

General

• Media support:

- 10Base-T Cat3, 4, 5 UTP/STP RJ-45

- 100Base-TX Cat5 UTP/STP RJ-45

• Ports: 8 RJ-45 10/100 Mbps PoE ports

• Packet lter/forwarding rate: 148,800 pps (100 Mbps); 14,880 pps (10 Mbps)

• Certications: FCC Class A, CE Mark

LEDs

• Power, Link/activity for 10 and 100 Mbps, PoE

Power

• Input: 90 to 260 V AC, 50 to 60 Hz

• Power consumption: 180 Watts (maximum)

Environmental

• Metal housing

• Dimensions: 266 (W) x 160 (L) x 44 (H) mm (10.5 x 6.3 x 1.7 in.)

• Weight: 1.4 kg (3.0 lbs.)

• Operating temperature: 0 – 60°C (32 – 140°F)

• Operating humidity: 10 – 90% RH, non-condensing

• Storage temperature: -20 – 90°C (-4 – 194°F)

Package Contents

• PoE Ofce Switch

• Power cable

• User manual

Are you completely satised with this product?

Please contact your INTELLINET NETWORK SOLUTIONS™ dealer

with comments or questions.

SOLUTIONS

All products mentioned are trademarks or registered trademarks of their respective owners.

www.intellinet-network.com
