Better throughput for more efficient use of your time.
The INTELLINET NETWORK SOLUTIONS™Gigabit Ethernet ExpressCard is a high-performance PCMCIA-
style network adapter that fits in the new ExpressCard/54 and ExpressCard/34 slots of a computer. It
is an ExpressCard/34 device, and supports the Single PCI Express lane (x1) specifications, operating
at the baseline 2.5 Gbps data rate and providing faster throughput than the current 32- and 64-bit PCI
bus architectures. And there is no need to switch to fiber optic cable — the INTELLINET NETWORK
SOLUTIONS Gigabit Ethernet ExpressCard allows you to run Gigabit speeds over your existing
copper-wire network cable.
Faster Throughput
The Single PCI Express lane (x1) interface supports throughput rates of up to 2 Gbps when running in full duplex mode. This
is ideal for resource-intensive CAD/CAM, client-server databases, multimedia, pre-press, advertising graphics, and server
and mission-critical applications.
Auto-Negotiation
The Gigabit Ethernet ExpressCard will automatically detect the network speed that the LAN switch port is set to and
run at the same speed. The card supports 10Base-T Ethernet, 100Base-TX Fast Ethernet and 1000Base-T Gigabit
Ethernet.
Full Duplex
When running in full duplex mode, the Gigabit Ethernet ExpressCard provides the following throughput rates: 20
Mbps (10Base-T Ethernet), 200 Mbps (100Base-TX Fast Ethernet) and 2 Gbps (1000Base-T Gigabit Ethernet.
Built-In Diagnostics
The Gigabit Ethernet ExpressCard comes standard with crossover detection, auto correction and pair swap/
polarity/skew correction capabilities that make installation and maintenance a snap.
Lifetime Warranty
Strict manufacturing standards ensure the highest quality in all INTELLINET NETWORK SOLUTIONS
products. All items carry a full Lifetime Warranty — the strongest quality commitment anyone can make.
Model
524056
Gigabit
Ethernet ExpressCard
Features
• Supports Gigabit speeds over existing network cable
• Does not require fiber optic cabling to run Gigabit speeds
• ExpressCard/34 device, fits in ExpressCard/54 and
ExpressCard/34 slots
• Single PCI Express lane (x1) 2.5 Gbps interface
• Full duplex speeds (20 Mbps, 200 Mbps, 2000 Mbps)
• Full duplex flow control (IEEE 802.3x)
• Wake-On-LAN (WOL) support
• Supports jumbo frames up to 9 kB
• Realtek chipset
• Compatible with Windows 2000, XP, 2003 Server and Vista
• Lifetime Warranty
Model
524056
INT-524056-DS-0208-01
Copyright © INTELLINET NETWORK SOLUTIONS
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of
the contents herein, are prohibited unless specifically authorized.
For more information on INTELLINET NETWORK SOLUTIONS products,
consult your local dealer or visit
www.intellinet-network.com
.
STANDARDS
• IEEE 802.3 (Twisted Pair Ethernet)
• IEEE 802.3u (Twisted Pair Fast Ethernet)
• IEEE 802.3ab (Twisted Pair Gigabit Ethernet)
• IEEE 802.3x (flow control, for full duplex mode)
GENERAL
• Media support:
- 10Base-T Cat3, 4, 5 UTP/STP RJ-45
- 100Base-TX Cat5 UTP/STP RJ-45
- 1000Base-T Cat5e/6 UTP/STP RJ-45
• Form factor: ExpressCard/34
• Realtek RTL8111C chipset
LEDs
• 100M Link/Activity
• 1000M Link/Activity
ENVIRONMENTAL
• Dimensions: 102.3 (L) x 34 (W) x 14.2 (H) mm (4 x 2.9 x 0.6 in.)
• Weight: 24 g (0.9 oz.)
• Operating temperature: 0 – 57°C (32 – 134°F)
• Operating humidity: 10 – 90% RH, non-condensing
• Storage temperature: -20 – 85°C (-4 – 185°F)
PACKAGE CONTENTS
• Gigabit Ethernet ExpressCard
• Driver CD
• User manual
Specifications
