INT-IPEX1000 Installation Guide
Important notice:
• Do not attempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all
source and destination equipment must be powered off during installation.
• Do not connect the device to a telecommunication outlet wired to unrelated equipment.
Doing so may damage the unit or any connected equipment. Ensure all connected twisted pair
cabling is straight-through (point-to-point).
• Allow proper ventilation to reduce the risk of thermal failure.
The Intelix INT-IPEX1000 series extenders are designed to distribute an HDMI
formatted video signal from a single source to multiple displays, such as a
digital signage environment. These extenders use parts of the link layer and
network layer of the OSI model to distribute the video signal.
The INT-IPEX1001 is an HDMI video to M-JPEG encoder which broadcasts the
video via multicast packets through the LAN output to the entire network.
The INT-IPEX1001 has a built-in EDID of 1080p/30 with 2 channel audio. The
INT-IPEX1002 receives the multicast packet stream on the LAN input and
decodes the M-JPEG video back to an HDMI formatted video stream.
While the INT-IPEX1000 series extenders use Ethernet switches to distribute a
video signal to multiple displays, these devices must be installed on their own
dedicated network infrastructure.
INT-IPEX1001 Connections
INT-IPEX1002 Connections
LED States
123 4 5
CDEA B
1. Power LED
2. Power Input
3. HDMI Input
4. LAN Port with Data and Link LEDs
5. Reset Button
1. LAN Port with Data and Link LEDs
2. Reset Button
3. Power LED
4. Power Input
5. HDMI Output
When a connection is detected, the green (left) and amber (right) LEDs on the
LAN port will light. The green Link LED will be lit solid. The amber Data LED
will flash once a second if no HDMI source signal is present. The amber Data
LED will flash quickly when an active HDMI signal is connected.
Instructions
While the INT-IPEX1000 series extenders use Ethernet switches to distribute a
video signal to multiple displays, these devices must be installed on their own
dedicated network infrastructure.
1. Verify all components included with the extenders are present before installation.
2. If the extender will be sitting on a shelf, attach the supplied rubber feet to the
bottom of the product.
3. If the extender will be secured to a surface, attach the included mounting brackets
with the supplied screws to the center screw point on the side of the extender.
Secure the extender to the surface.
4. For a point to point installation, connect Category 5e or greater twisted pair cable
with RJ45 connectors between the extenders. TIA/EIA-568B straight-through
wiring connections are highly recommended to limit potential interference.
5. For a video distribution installation, connect Category 5e or greater twisted pair
cable with RJ45 connectors between the extenders and Ethernet switch. TIA/
EIA-568B straight-through wiring connections are highly recommended to limit
potential interference.
6. Connect an HDMI cable between the display and the decoder
(INT-IPEX1002).
7. Connect an HDMI cable between the source and the encoder
(INT-IPEX1001).
8. If the extenders are connected to a network switch with PoE, such as the
INT-IPSW1100 series,power supplies are not required for use. Plug the optional
power supplies (PS-5D-10) into the power input port of the extenders and lock the
power supply to the power connector by twisting the locking collar clockwise. The
red Power LED will light when receiving power.
9. Power on attached audio/video devices.
Point-to-Point Video Distribution
IPEX1101 IPEX1102 IPEX1101
IPEX1102
IPEX1102
Network Switch
8001 Terrace Ave, Ste 201
Middleton, WI 53562
608-831-0880
supportlibav@libav.com rev 150611
Technical Specifications
Input/Output Connections
LAN port One (1) 8P8C-F
HDMI Input (INT-IPEX1001) One (1) HDMI Type A Receptacle
HDMI Output (INT-IPEX1002) One (1) HDMI Type A Receptacle
5vDC Input One (1) Threaded Locking Barrel (5.5 mm OD; 2.6 mm ID)
Supported Audio and Video
Maximum Video Compatibility 24 Bit at 1080p
Video Compliance HDMI 1.3 and HDCP 1.3
Embedded Audio PCM 2-channel, 44.1 and 48 KHz
Ethernet Signal Characteristics
Maximum Distance 100m
Cable Requirements Solid core Category 5e, Category 6 or greater with TIA/EIA-568B
crimp pattern
Ethernet Standards IEEE 802.3/802.3u/802.3x/802.1p/802.1q
PoE Standards IEEE 802.3af/at (Type 1)
Transcoder Compression Motion JPEG
Transmission Method Multicast streaming on Link and Network layers of OSI model
Chassis and Environmental
Enclosure Material Galvanized Steel
Enclosure Dimensions (H x W x D) 21.5 mm x 120 mm x 60 mm (0.85 in x 4.72 in x 2.36 in)
Shipping Weight 0.18 kg (0.40 lbs)
Operating Temperature 0° to +55° C (+32° to +131° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -40° to +85° C (-40° to +185° F)
Storage Humidity 10% to 85%, Non-condensing
Power and Regulatory
Power Consumption (INT-IPEX1001) 4.2 watts
Power Consumption (INT-IPEX1002) 3.5 watts
ESD Protection ±15 kV
Product Regulatory CE, FCC, RoHS
Other
Warranty 2 years
Diagnostic Indicators Power, Link, Data
Power Supply (sold separately) PS-5D-10
Included Accessories Installation Guide, Rubber feet (4 ea), Mounting brackets (2 ea)
with screws
Distances and picture quality may be affected by cable grade, cable quality, source and destination
equipment, RF and electrical interference, and cable patches.
