Quick Start Guide

Viglen Product description: Intel DQ963GS Motherboard

Viglen Order Code: PMPGS001

Viglen System: Genie (s775)

Viglen Ltd. PMPGS001

-1-

Product Specification

Motherboard Form Factor microATX (243.84 millimetres [9.60 inches] x 243.84 millimetres

[9.60 inches])

Motherboard chipset Intel® Q963 Express Chipset, consisting of:

• Intel® 82Q963 Graphics and Memory Controller Hub (GMCH)

• Intel® 82801HB I/O Controller Hub (ICH8)

CPU connector type (s370,

slot1 etc) LGA 775

Number of CPUs supported 1

If >1 does it require a

terminator? N/A

Supported CPU types (C,

P3 or P4 etc) Support for the following:

• Intel® Core™2 Duo processor with 1066 or 800 MHz system bus

• Intel® Pentium® D processor with 800 or 533 MHz system bus

• Intel® Pentium® 4 processor with 800 or 533 MHz system bus

• Intel® Celeron® D processor with 533 MHz system bus

Supported CPU speeds CPU No. CPU speed FSB L2 cache

E6300- E6400

E6600- E6700 1.86 –2.13GHz

2.40--2.66GHz 1066MHz

1066Mhz

2MB

4MB

805

820

915-960

2.66GhZ

2.80Ghz

2.80GHz-3.60GHz

533MHz

800MHz

2MB

4MB

524

520-551

620-662

3.20GHz

2.80GH – 3.40Ghz

2.80GHz-3.60GHz

533MHz

800MHz

1MB

2MB

320-355

352,356,360 2.40-3.33GHz

3.20,-3.46GHz 533MHz

533MHz 256KB

512KB

Front side bus speed 1066MHz, 800MHz and 533MHz

Number of PCI slots 2

PCI slot speeds 33MHz

Number of PCI-E slots 1 x PCI-e x1

Number of AGP slots 0

Number of AMR slots 0

Additional slots 0

On board video fitted?

Type Intel® GMA 3000 onboard graphics subsystem

Ram size? Shared system Memory (Max 256MB)

Upgradeable? N/A

Onboard audio fitted? Type

6-channel (5.1) onboard subsystem, featuring:

•Intel® High Definition Audio interface

•SigmaTel* STAC9227 audio codec

•HD Audio Link header

Front facing audio header

and type Yes

Audio Upgradeable? Yes via PCI

Onboard network fitted?

Type Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the

Intel® 82566DC Gigabit Ethernet Controller

Number of network 1

Viglen Ltd. PMPGS001

-2-

connections?

Upgradeable? Yes via PCI

Onboard SCSI fitted? Type No

No of channels? N/A

Manufacturer? N/A

Model Number? N/A

Speed? N/A

Number of IDE channels One Parallel ATA IDE interface with UDMA 33, ATA-66/100/133 support

Maximum number of disks 2

Number of SATA Channels Four Serial ATA (SATA) channels (3.0GB/s), via the ICH8, one device

per channel.

Diskette drive Interface 1

2 x USB connectors for 4 additional

USB 2.0 devices 1 x Serial port header

Internal connectors

1 x HD Audio Link Header 1 x Front panel audio header

1 x Parallel Port 1 x RJ045 LAN Port

1 x VGA port 1 x Audio In

6 x USB 2.0 ports 1 x Audio Out

1 x MIC

Rear I/O connectors

2 x PS/2 Ports

Memory type DDR2

Supports:

•Unbuffered, non-registered single or double-sided DIMMs

•Non-ECC memory

•Serial Presence Detect (SPD) memory only

For RIMMs install CRIMM in

empty sockets N/A

Number of memory sockets Four 240-pin DDR2 1.8 V SDRAM Dual Inline memory Module (DIMM)

sockets

Maximum memory support • Support up to 8GB of system memory using DDR2 533 or DDR2 667

DIMMS

Supported memory speed DDR2 533/667 MHz single or Dual channel DDR2 DIMMS

BIOS

• Intel® BIOS (resident in the SPI Flash device)

• Support for Advanced Configuration and Power Interface (ACPI), Plug

and Play,

Instantly

Available PC

Technology

• Support for PCI Local Bus Specification Revision 2.3

• Support for PCI Express Revision 1.0a

• Suspend to RAM support

• Wake on PCI, RS-232, front panel, PS/2 devices, and USB ports

Hardware Monitor

Subsystem

• Intel® Quiet System Technology implemented through ICH8

• Voltage sense to detect out of range power supply voltages

• Thermal sense to detect out of range thermal values

• Three fan headers

• Three fan sense inputs used to monitor fan activity

MTBF 130,087 hours.

Viglen Ltd. PMPGS001

-3-

Supported CPU List in Detail

See the table below for a complete list of supported processors.

Processor Family Processor Number Processor

Speed System Bus

Frequency L2 Cache Size

E6700 2.66 GHz 1066 MHz 4 MB

E6600 2.40 GHz 1066 MHz 4 MB

E6400 2.13 GHz 1066 MHz 2 MB

Intel® Core™2

Duo E6300 1.86 GHz 1066 MHz 2 MB

960 3.60 GHz 800 MHz 2x2 MB

950 3.40 GHz 800 MHz 2x2 MB

945 3.40 GHz 800 MHz 2x2 MB

940 3.20 GHz 800 MHz 2x2 MB

930 3 GHz 800 MHz 2x2 MB

925 3 GHz 800 MHz 2x2 MB

920 2.80 GHz 800 MHz 2x2 MB

915 2.80 GHz 800 MHz 2x2 MB

820 2.80 GHz 800 MHz 2x1 MB

Intel® Pentium® D

805 2.66 GHz 533 MHz 2x1 MB

662 3.60 GHz 800 MHz 2 MB

661 3.60 GHz 800 MHz 2 MB

651 3.40 GHz 800 MHz 2 MB

650 3.40 GHz 800 MHz 2 MB

641 3.20 GHz 800 MHz 2 MB

640 3.20 GHz 800 MHz 2 MB

631 3 GHz 800 MHz 2 MB

630 3 GHz 800 MHz 2 MB

620 2.80 GHz 800 MHz 2 MB

551 3.40 GHz 800 MHz 1 MB

550J 3.40 GHz 800 MHz 1 MB

550 3.40 GHz 800 MHz 1 MB

541 3.20 GHz 800 MHz 1 MB

540J 3.20 GHz 800 MHz 1 MB

540 3.20 GHz 800 MHz 1 MB

531 3 GHz 800 MHz 1 MB

Intel® Pentium® 4

530J 3 GHz 800 MHz 1 MB

Viglen Ltd. PMPGS001

-4-

530 3 GHz 800 MHz 1 MB

521 2.80 GHz 800 MHz 1 MB

520J 2.80 GHz 800 MHz 1 MB

520 2.80 GHz 800 MHz 1 MB

524 3.20 GHz 533 MHz 1 MB

360 3.46 GHz 533 MHz 512 KB

356 3.33 GHz 533 MHz 512 KB

355 3.33 GHz 533 MHz 256 KB

352 3.20 GHz 533 MHz 512 KB

347 3.06 GHz 533 MHz 256 KB

350 3.20 GHz 533 MHz 256 KB

346 3.06 GHz 533 MHz 256 KB

345J 3.06 GHz 533 MHz 256 KB

341 2.93 GHz 533 MHz 256 KB

340J 2.93 GHz 533 MHz 256 KB

336 2.80 GHz 533 MHz 256 KB

335 2.80 GHz 533 MHz 256 KB

330-331 2.66 GHz 533 MHz 256 KB

325-326 2.53 GHz 533 MHz 256 KB

Intel® Celeron® D

320 2.40 GHz 533 MHz 256 KB

Viglen Ltd. PMPGS001

-5-

•System Board Components

Figure 1 - Motherboard Layout & Components

Table 1

Item Description Item Description

A Front panel audio header P Front chassis fan header

B PCI Conventional bus add-in card

connector 1 Q Chassis intrusion header

C PCI Express x1 connector R Intel 82801HO I/O Controller Hub

(ICH8DO)

D Back panel connectors S BIOS Setup configuration jumper block

E Processor core power connector T Auxiliary front panel power LED header

F Rear chassis fan header U Front panel header

G LGA775 processor socket V Serial ATA connectors [4]

H Intel 82Q963 GMCH W Front panel USB header

I Processor fan header X Speaker

J DIMM Channel A sockets Y Front panel USB header

K Serial port header Z Parallel ATE IDE connector

L DIMM Channel B sockets AA PCI Conventional bus add-in card

connector 2

M Diskette drive connector BB High Definition Audio header

N Main Power connector - -

O Battery - -

Viglen Ltd. PMPGS001

-6-

•Back Panel Connectors 5.1 SigmaTel audio STAC9227

The Motherboard external IO connectors are attached to a metallic I/O shield. This shield

serves several purposes:

•It protects the sensitive Motherboard from any external EMC interference.

•It stops the computer from interfering with other electrical devices.

•It allows the Motherboard to be easily upgraded in the future without having to resort to

buying a whole new case. Simply change the I/O shield to match the Motherboard.

The I/O shield provides external access to onboard VGA port, Parallel Port, six USB

connectors as well as one LAN Port and audio connectors.

Figure 2 - Back Panel Connectors

Table 2

Item Description Item Description

A PS/2 Mouse Port F LAN (RJ45)

B PS/2 Keyboard Port G USB 2.0 ports (2)

C Parallel port (Burgundy) H Audio line in/Retasking Jack

[Blue]

D VGA port (blue) I Line out/retasking jack

[Green]

E USB 2.0 ports (4) J Mic in/retasking jack

[Pink]

- -

Viglen Ltd. PMPGS001

-7-

•Internal headers

There are connector headers on the motherboard for Front Panel, Alternative front panel

Power LED, USB1/USB2, HD Audio Link, Audio and Serial connector headers. The location

and or details of these internal headers are shown below (Figure 3).

Figure 3 - Internal Headers

Table 3

Item Description

A Front Panel connectors

B Alternative Front Panel Power LED

C USB1/USB2

D Intel HD Audio Link

E Audio (HD/AC’97)

F Serial Connector

Viglen Ltd. PMPGS001

-8-

•Front Panel connections

The following are all connectors situated along the front edge of the motherboard. They are

often connected to buttons and LED’s situated on the front panel.

Figure 4 – Front Panel Connectors

Table 4

Pin Connector Comments

1-3 HD LED This goes to the Hard Disk L.E.D. on the front

panel, which lights up when the SATA Hard Disk

is in use.

2-4 Power LED This attaches to the power L.E.D on the front

panel, to display if the computer is active or not.

5-7 Reset switch

connector When these pins are shorted, it will cause the

computer to perform a cold reboot.

6-8 Power On/Off When these pins are shorted it turns the

computer on and off.

Viglen Ltd. PMPGS001

-9-

•Memory

The board has four DIMM sockets and supports the following memory features:

•1.8 V (only) DDR2 SDRAM DIMMs with gold-plated contacts

•Unbuffered, single-sided or double-sided DIMMs with the following restriction:

Double-sided DIMMS with x16 organization are not supported.

•8 GB maximum total system memory using DDR2 667 or DDR2 533 DIMMs;

•Minimum total system memory: 512 MB

•Non-ECC DIMMs

•Serial Presence Detect

•DDR2 533 and DDR2 667 MHz SDRAM DIMMs

NOTE: A minimum of 512 MB of system memory is required to fully enable

both the onboard graphics and the manageability engine.

NOTE: To be fully compliant with all applicable DDR SDRAM memory specifications, the

board should be populated with DIMMs that support the Serial Presence Detect (SPD) data

structure. This enables the BIOS to read the SPD data and program the chipset to accurately

configure memory settings for optimum performance. If non-SPD memory is installed, the

BIOS will attempt to correctly configure the memory settings, but performance and reliability

may be impacted or the DIMMs may not function under the determined frequency. Table 5 -

lists the supported DIMM configurations

Table 5. Supported Memory Configuration

DIMM

Type SDRAM

Technology Smallest

usable

DIMM (one x16

Single-sided

DIMM)

Largest usable

DIMM (one x8

Double-sided

DIMM)

Maximum

capacity

with four

identical

x8 Double-

sided

DIMMs

DDR2 533 256 Mbit 128 MB 512 MB 2 GB

DDR2 533 512 Mbit 256 MB 1 GB 4 GB

DDR2 533 1 Gbit 512 MB 2 GB 8 GB

DDR2 667 256 Mbit 128 MB 512 MB 2 GB

DDR2 667 512 Mbit 256 MB 1 GB 4 GB

DDR2 667 1 Gbit 512 MB 2 GB 8 GB

NOTE: Regardless of the DIMM type used, the memory frequency will either be equal to or

less than the processor system bus frequency. For example, if DDR2 667 memories is used

with a 533 MHz system bus frequency processor, the memory will operate at 533 MHz. Table

6 lists the resulting operating memory frequencies based on the combination of DIMMs and

processors.

Table 6- Operating Memory Frequencies

DIMM Type Processor system bus

frequency Resulting memory

frequency

DDR2 533 533 MHz 533 MHz

DDR2 533 800 MHz 533 MHz

DDR2 533 1066 MHz 533 MHz

DDR2 667 533 MHz 533 MHz

DDR2 667 800 MHz 667 MHz

DDR2 667 1066 MHz 667 MHz

Viglen Ltd. PMPGS001

-10-

Table des matières

Autres manuels Intel Carte mère

Intel

Intel D102GGC2 Manuel technique

Intel

Intel RX87Q Manuel utilisateur

Intel

Intel D815EEA2 Guide de référence

Intel

Intel DH61CR Manuel

Intel

Intel D975XBX Guide de configuration

Intel

Intel D848PMB Manuel utilisateur

Intel

Intel BOXDX58SO2 Manuel utilisateur

Intel

Intel IQ80315 Manuel utilisateur

Intel

Intel DH61SA Manuel utilisateur

Intel

Intel Desktop Board D845GLVA Manuel utilisateur

Intel

Intel DH61WW Guide de configuration

Intel

Intel BOXDX58SO Manuel utilisateur

Intel

Intel DG41KR Manuel utilisateur

Intel

Intel D845BG Manuel utilisateur

Intel

Intel D850MVSE Manuel utilisateur

Intel

Intel BLKDG41CN Guide de configuration

Intel

Intel DG965OT - Desktop Board Motherboard Manuel utilisateur

Intel

Intel D945GCCR Manuel utilisateur

Intel

Intel I925XE Manuel utilisateur

Intel

Intel DQ57TM Manuel utilisateur

Intel

Intel D2500HN Manuel utilisateur

Intel

Intel DZ68DB Manuel utilisateur

Intel

Intel D915GMHLK - Desktop Board - Mainboard Manuel utilisateur

Intel

Intel D945PDK Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
