Intel® Desktop Board

DG41TX

Specification Update

July 2010

Order Number: E92428-002US

The Intel®Desktop Board DG41TX may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DG41TX Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board DG41TX March 2010

-002 Update to the General Information Section July 2010

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board DG41TX may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, the Intel logo, Core, Celeron, and Pentium are registered trademarks of Intel Corporation in the U.S.

and other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board DG41TX Specification Update 3

Contents

Specification Update for the Intel®Desktop Board DG41TX

Terminology ............................................................................................ 5

General Information .................................................................................5

Summary of Changes ............................................................................... 6

4 Intel Desktop Board DG41TX Specification Update

Specification Update for the

Intel®Desktop Board DG41TX

This document is an update to the specifications contained in the Intel®Desktop Board

DG41TX Technical Product Specification (Order Number E89691). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

For specification updates concerning the Intel processor that may apply to this desktop

board, refer to the following:

•Intel®Core™2 Duo Processor E8000 and E7000 Series Specification Update (Order

Number 318733)

•Intel®Core™2 Extreme Processor X6800 and Intel®Core™2 Duo Desktop

Processor E6000 and E4000 Sequence Specification Update (Order Number

313279)

•Intel®Core™2 Extreme Processor QX9000 Series and Intel®Core™2 Quad

Processor Q9000, Q9000S, Q8000 and Q8000S Series Specification Update (Order

Number 318727)

•Intel®Core™2 Extreme Processor QX9000 Series and Intel®Core™2 Quad

Processor Q9000, Q9000S, Q8000 and Q8000S Series Specification Update (Order

Number 318727)

•Intel®Core™2 Extreme Quad-Core Processor QX6000 Sequence and Intel®Core™2

Quad Processor Q6000 Sequence Specification Update (Order Number 315593)

•Intel®Celeron®Processor E3x00 Series Specification Update (Order Number

322568)

•Intel®Celeron®Processor 400 Series Specification Update (Order Number 316964)

•Intel®Pentium Dual-Core Processor E6000 and E5000 Series Specification Update

(Order Number 320468)

•Intel®Pentium®Dual-Core Desktop Processor E2000 Series Specification Update

(Order Number 316982)

Refer to the Intel®4 Series Chipset Family Specification Update (Order Number

319971) for specification updates concerning the 82G41 GMCH Controller and that

may apply to the desktop board DG41TX.Unless otherwise noted in this document, it

should be assumed that any MCH errata for a given stepping are applicable to the

Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®IO Controller Hub7 (ICH7) Family Specification Update (Order

Number 307014) for specification updates concerning the 82801GB I/O Controller Hub

and that may apply to the desktop board DG41TX.Unless otherwise noted in this

document, it should be assumed that any ICH7 errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board DG41TX Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board DG41TX Identification Information

AA Revision BIOS Revision Notes

E78178-301 TXG4110H.86A.0037 1,2

E78178-302 TXG4110H.86A.0037 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The Intel®G41 Express Chipset used on this AA revision consists of the following component:

Device Stepping S-Spec Numbers

G41 A3 SLB8D

ICH7 A1 SL8FX

6 Intel Desktop Board DG41TX Specification Update

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

DG41TX. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Errata

There are no characterized erratum for this product
